Model # 2104S24-AFC

Internet #205015282

Store SKU #368980

AFC Cable Systems 12/2 x 50 ft. Solid MC Lite Cable
0077680273734

AFC Cable Systems

12/2 x 50 ft. Solid MC Lite Cable

  • Meets all applicable OSHA and HUD Requirements
  • Maximum Voltage Rating of 600V
  • Aluminum armored cables are RoHS Compliant
$32.77 /each

Frequently Bought Together

Product Overview

The AFC Cable Systems 50 ft. 12/2-Gauge MC Lite Cable protects the inner THHN/THWN Solid conductors with an aluminum interlocking armored jacket. The armor features phase/circuit stripes for easy identification. UL listed for through-wall penetrations.

  • Designed for use with commercial, industrial and multi-residential branch circuits and feeder wiring
  • Use for power, lighting, control and signal circuits
  • Can be fished, surface mounted, embedded in plaster and used in environmental air-handling spaces
  • 50 ft. L
  • 12-Gauge
  • Interlocking galvanized aluminum armor provides durability
  • Phase/circuit stripes for easy identification
  • Solid copper ground
  • Copper conductor material
  • UL listed
  • Click to learn the factors you must consider when wiring your home

Specifications

Dimensions

Details

Warranty / Certifications

More Products With These Features

Search

Customer Questions & Answers

Can this cable be used outdoors?

Asked by: Asker
1. Answer #1: According to NEC 330.12 which states Type MC Cable shall not be used under either of the following conditions: • Where subject to physical damage • Where exposed to any of the destructive corrosive conditions, unless the metallic armor is resistant to conditions or is protected by material resistant to the conditions i.e. a PVC jacket, which in this case with this product does not have. So, no this product may not be used outdoors.
Answered by: AFCSupport
Date published: 2016-07-22

If I want to run a 220-volt, 20-amp circuit in an unfinished garage (for a table saw), do I need to use MC cable?

Asked by: Bean
Yes, use armored wherever the cable is exposed, to prevent accidental damage to it. But it cannot be used where it can get wet. In that case the wires needs to be in conduit.
Answered by: Handy2
Date published: 2016-02-28

How do I cut this cable to create proper lengths between boxes

Example: I have looked at the manual and can't figure out what I did wrong.
Asked by: OldSarge
You would use an armored cable cutter such as this Klein Tool: http://www.homedepot.com/p/Klein-Tools-BX-and-Armored-Cable-Cutter-53725/203872308
Answered by: AFCSupport
Date published: 2016-12-07

This is 12/2 with a green ground wire correct?

Asked by: Odyknuck
Yes, that is correct.
Answered by: CommunityAnswer
Date published: 2016-11-18
  • y_2017, m_3, d_27, h_3CST
  • bvseo_bulk, prod_bvqa, vn_bulk_1.0.0
  • cp_1, bvpage1
  • co_hasquestionsanswers, tq_6
  • loc_, sid_205015282, prod, sort_[SortEntry(order=NUM_ANSWERS, direction=DESCENDING), SortEntry(order=SUBMISSION_TIME, direction=DESCENDING), SortEntry(order=LAST_APPROVED_ANSWER_SUBMISSION_TIME, direction=DESCENDING), SortEntry(order=LAST_APPROVED_ANSWER_SUBMISSION_TIME, direction=DESCENDING), SortEntry(order=BEST_ANSWER_FEEDBACK_COUNT, direction=DESCENDING), SortEntry(order=POSITIVE_ANSWER_FEEDBACK_COUNT, direction=DESCENDING), SortEntry(order=NUM_ANSWERS, direction=DESCENDING)]
  • clientName_homedepot
  • bvseo_sdk, java_sdk, bvseo-3.1.1
  • CLOUD, getContent, 42ms
  • QUESTIONS, PRODUCT

Customer Reviews

12/2 x 50 ft. Solid MC Lite Cable is rated 5.0 out of 5 by 1.
Rated 5 out of 5 by from Great cable. Had a sub panel installed in my garage for the tools in my wood shop and used this ... Great cable. Had a sub panel installed in my garage for the tools in my wood shop and used this to run a few 20amp circuits from the sub panel. Just the quickest way to make safe and clean electric runs externally on the walls in my garage. Its a fairly clean look with out having to hang PVC and snake wire through.
Date published: 2016-11-03
