American Standard H2Option 2-piece 1.6/1.0 GPF Dual Flush Right Height Elongated Toilet in White-2886.216.020 - The Home Depot

American Standard

Model # 2886.216.020

Internet # 202045569

H2Option 2-piece 1.6/1.0 GPF Dual Flush Right Height Elongated Toilet in White

American Standard H2Option 2-piece 1.6/1.0 GPF Dual Flush Right Height Elongated Toilet in White

This item has been discontinued.
The Home Depot no longer carries this specific product.
Please select another option below.

$292.50 / each


Model # 2886.216.020

Internet # 202045569

Store SO SKU # 285746

With the H2Option Siphonic toilet, you choose your water use and save up to 25% more water than standard toilets with every flush. Choose a 1.0 gpf flush for liquid or light flush and 1.6 gpf flush for solids or heavy flush. Maximum performance rating of 1,000g bulk removal on 1.6 gpf and 400g on 1.0 gpf. Also, our exclusive patented PowerWash Rim Technology that completely scours the bowl with each flush and siphonic action ensure complete evacuation of bowl contents produces a cleaner flush.

  • 2-piece design features a separate tank and bowl
  • Seat sold separately
  • Elongated bowl for greater comfort
  • ComfortHeight design features a height comparable to that of a standard chair to make sitting down and standing up easier for people of all ages
  • WaterSense certified high-efficiency design uses 1.28 gpf for significant water savings
  • Constructed with durable vitreous china for cleaner, long-lasting use
  • Fully glazed 2 in. trap way
  • 5-year warranty

Info & Guides

You will need Adobe® Acrobat® Reader to view PDF documents. Download a free copy from the Adobe Web site.


Assembled Depth (in.)  28.75 in  Assembled Height (in.)  29.5 in
Assembled Width (in.)  15 in  Bowl Height (in.)  16.5
Bowl Rim Height  16.5  Flush Valve Size (in.)
Product Depth (in.)  28.75  Product Height (in.)  29.5
Product Width (in.)  15
Bowl Height  Standard  Bowl Shape  Elongated
Color Family  White  Color/Finish  White
Commercial / Residential  Residential  Dual Flush  Yes
Flush Performance Category  Best 8-10  Flushing System  Gravity Fed
Gallons Per Flush  1.28 gal (US)  MaP Performance Rating  1000
Material  Vitreous China  Mount Location  Floor Mount
Product Weight (lb.)  75 lb  Returnable  90-Day
Rough In Size  12  Toilet Features  Dual Flush
Toilet Included Components  Handle,Seat  Trip Lever Location  Top Actuator
Warranty / Certifications
Certifications and Listings  ADA Compliant  Manufacturer Warranty  Limited 5-year


Rated 4.5 out of 5 by 115 reviewers.
Rated 4.0 out of 5.0 by Nice replacement I got this toilet to replace an older 1.6 GPF unit since I'm on a septic system and am trying to reduce the amount of waste water. It arrived very well packaged - it was double boxed and padded. It's attractive and functional. I noticed that the tank refill is quieter than my old unit. From the floor to the top of the bowl is 16.75". Despite the high-tech dual-flush mechanism, the toilet itself seems pretty basic. No seat or wax ring were included. The tool supplied to tighten the tank nuts was a piece of metal tubing with a hex shape in one end with a hole for a screwdriver in the other end. I used two shims to level the bowl. I can't vouch for whether the floor is really level, but the unit I took out didn't have any shims. The flush button has to be held down for a couple of seconds to get a complete flush. This might be an advantage since I have cats that will be walking over the tank top. There is a full page of adjustment instructions in the installation guide, including how to adjust the flush buttons and how to adjust the flush valve. I couldn't make sense of the flush valve adjustment instructions, but it worked OK without any additional adjustments. I was concerned about access to the flush valve adjustments but it turns you can just twist the flush valve and pull it out for adjustment or replacement. January 11, 2014
Rated 4.0 out of 5.0 by Easy to Install and Works Great! We decided to replace a toilet in our house that was using way too much water per flush. This toilet has a great water saving feature with the dual flush mechanism on the tank lid. This shipped to my house in 2 large over-boxes. 1 box for the tank and 1 box for the toilet. Inside each box there actual product was encased in blue packing bags to fill out the void. the product arrived in great condition with no issues. In the end it took longer to break down the packaging for recycling than it did to remove old toilet and install the new one. It took me about 10 minutes to remove the old toilet and clean the old wax seal and replace the flange bolts. It took about another 10 minutes to un-box and place the new toilet. you will need to buy a wax seal and toilet seat for this product (which is why I only gave it 4 stars) to assemble you bolt this to the floor with 2 bolts. bolt the tank to the toilet with 2 bolts and gaskets. put the seal between the tank and toilet, hook up the water line and you're done. you just need a toilet seat. December 24, 2013
Rated 5.0 out of 5.0 by Great all round This was shipped to me and it was very well packed. No damage at all. The tank is made in Mexico and the toilet is made in China. The quality of all materials look fine. The set does not include closet bolts but I was able to use the existing bolts from the toilet I was replacing without any problem. You do need to buy a wax ring and have some caulking on hand too. You will also need a toilet seat. We have the SmartBidet Electric Bidet Seat for Elongated Toilets anyway so this was no problem. You also need a flexible water supply pipe of an appropriate length to go from your water supply to the underside of the tank. HD carries a range of lengths - this is not something that the toilet manufacturer can supply because they don’t know what length you may need. Remember also that if you are replacing an older toilet, there may be unpainted wall behind the tank that needs to be painted before you install the new one. The tank on this set is 15” wide - somewhat narrower than our old tank. Installation was very easy and the instructions are well written. The tank includes all the connection bolts to bolt the two parts together plus a small tube wrench to hand tighten the bolts. Flushing: There are two flush modes - operated by buttons at the top of the tank. This is great for saving water for those #1 occasions. We have not encountered any issue with flushing at all. The tank did not seem to need any water level adjustment. Flushing is quick and much quieter than our old toilet. I am especially pleased with the better height of the toilet. A nice touch is a sticker on the underside of the tank lid that lists the part numbers for the tank. January 3, 2014
Rated 4.0 out of 5.0 by Serves its purpose well It's a toilet, it works. I've learned to appreciate the height of it. I wish it had come with a seat. I wish the difference between the two flush modes was greater. But I guess even the big flush uses comparatively little water. January 22, 2014
Rated 5.0 out of 5.0 by Works great, quiet Dual flush works great, have not had one clog yet. The pressurized flush definitely helps and is no louder than a regular toilet. Quick and easy to install. March 25, 2015
Rated 3.0 out of 5.0 by Good not great! Very easy to install and comfortable probably not for kids. But states cleans easily - not really, probably needs a little more water on the sides to flush properly or, some way to deliver a little more pressure. I got it at the store & was on sale and a little cheaper than the 'net so therefore, as far as value was better. With a little larger water surface would perform better but would take more water to flush - not a bad idea. I don't know how that compares to the 2+ flushes it takes to clean it. All in all, its a maybe not a resounding yes so - its OK. February 19, 2015
Rated 5.0 out of 5.0 by Fantastic Best toilet in the world - PERIOD. Wanna save water and not worry about backing up a toilet? This is the one!! Dual flush, one for liquid (1 gallon flush) and one for solids (1.6 gallon flush). I weigh 240 lbs and I can't clog it. Nuff said September 18, 2012
Rated 5.0 out of 5.0 by Great Toilet Installation Purchased this toilet as a replacement for an old toilet that wasn't working so good. Very easy to install and works like a champ. October 22, 2014
