Model # RH1014

Internet #100089770

Store SO SKU #563642

Arrow Red Barn 10 ft. x 14 ft. Metal Storage Building
0026862104953

Arrow

Red Barn 10 ft. x 14 ft. Metal Storage Building

$77599 /each

Product Overview

Store your riding lawn mower, power equipment and other seasonal items in the Arrow Red Barn 10 ft. x 14 ft. Metal Storage Building. Featuring horizontal wall panels that simply drop into place for easy assembly, the building has 2 sliding doors with a large opening that accommodates most tractor mowers. The building's 8 ft. tall interior height offers expanded headroom and its 952 cu. ft. capacity helps you store a large number of items.
store icon Loading Buying Options...
package icon Loading Buying Options...
Sorry, but we ran into issues loading these options. Please try refreshing.

Frequently Bought Together

Product Overview

Store your riding lawn mower, power equipment and other seasonal items in the Arrow Red Barn 10 ft. x 14 ft. Metal Storage Building. Featuring horizontal wall panels that simply drop into place for easy assembly, the building has 2 sliding doors with a large opening that accommodates most tractor mowers. The building's 8 ft. tall interior height offers expanded headroom and its 952 cu. ft. capacity helps you store a large number of items.
  • Assembled dimension: 123.25 in. W x 162.75 in. D x 97.13 in. H
  • 952 cu. ft. storage capacity helps you store a large number of items
  • Horizontal panels drop in place for fast assembly
  • Barn-style roof for lots of headroom
  • 8 ft. tall interior height creates a large work/storage area
  • 2 doors give you easy access to your stored items
  • Wide door opening accommodates tractor mowers
  • Door lock enhances the safety of your stored items
  • Attractive red panels give the look of an old barn
  • Eggshell-colored doors and roof for an appealing look
  • Metal siding is sturdy
  • Click to find out more about buying outdoor storage sheds

Product Overview

Model #: RH1014
Internet #: 100089770

Store your riding lawn mower, power equipment and other seasonal items in the Arrow Red Barn 10 ft. x 14 ft. Metal Storage Building. Featuring horizontal wall panels that simply drop into place for easy assembly, the building has 2 sliding doors with a large opening that accommodates most tractor mowers. The building's 8 ft. tall interior height offers expanded headroom and its 952 cu. ft. capacity helps you store a large number of items.

  • Assembled dimension: 123.25 in. W x 162.75 in. D x 97.13 in. H
  • 952 cu. ft. storage capacity helps you store a large number of items
  • Horizontal panels drop in place for fast assembly
  • Barn-style roof for lots of headroom
  • 8 ft. tall interior height creates a large work/storage area
  • 2 doors give you easy access to your stored items
  • Wide door opening accommodates tractor mowers
  • Door lock enhances the safety of your stored items
  • Attractive red panels give the look of an old barn
  • Eggshell-colored doors and roof for an appealing look
  • Metal siding is sturdy
  • Click to find out more about buying outdoor storage sheds

Info & Guides

You will need Adobe® Acrobat® Reader to view PDF documents. Download a free copy from the Adobe Web site.

Specifications

Dimensions

Approximate Depth (ft.)
14
Approximate Width (ft.)
10
Assembled Depth (in.)
162.75 in
Assembled Height (in.)
97.13 in
Assembled Width (in.)
123.25 in
Coverage Area (sq. ft.)
129
Door Opening Height (In.)
69.25
Door Opening Width (In.)
55.5
Door Opening Width (ft.)
4
Exact Width x Depth
10 ft 3.25 in x 13 ft 6.75 in
Sidewall Height (in.)
71.25

Details

Assembly Required
Yes
Capacity (cu. ft.) - Total
952
Color Family
Reds / Pinks
Floor Options
Without Floor
Foundation
Foundation Not Included
Manufacturers Recommended Assembly Time (hours)
8
Manufacturers Recommended Tools needed for Assembly
safety glasses, Phillips screwdriver, gloves, ladder, utility knife, pliers, level, tape measure
Maximum Roof Load (lb./ sq. ft.)
0
Maximum Wind Resistance (mph)
0
Number of Doors
2
Number of People Recommended by Manufacturer to Assemble
2
Number of Windows
0
Product Weight (lb.)
346lb
Returnable
90-Day
Roof Color Family
White
Roof Material
Metal
Roof Pitch
1.9:12 Upper Section of Roof 9.4:12 Lower Secion of Roof
Roof Shape
Gambrel
Shed Door Type
Sliding
Shed Features
Door Latch,Double Door,Lockable Door
Shed Included
No Additional Items Included
Shed Style
Barn
Shed Type
Metal
Siding Color Family
Red
Storage Capacity (cu. ft.)
952

Warranty / Certifications

Manufacturer Warranty
10 year limited

Specifications

Dimensions

Approximate Depth (ft.)
14
Approximate Width (ft.)
10
Assembled Depth (in.)
162.75 in
Assembled Height (in.)
97.13 in
Assembled Width (in.)
123.25 in
Coverage Area (sq. ft.)
129
Door Opening Height (In.)
69.25
Door Opening Width (In.)
55.5
Door Opening Width (ft.)
4
Exact Width x Depth
10 ft 3.25 in x 13 ft 6.75 in
Sidewall Height (in.)
71.25

Details

Assembly Required
Yes
Capacity (cu. ft.) - Total
952
Color Family
Reds / Pinks
Floor Options
Without Floor
Foundation
Foundation Not Included
Manufacturers Recommended Assembly Time (hours)
8
Manufacturers Recommended Tools needed for Assembly
safety glasses, Phillips screwdriver, gloves, ladder, utility knife, pliers, level, tape measure
Maximum Roof Load (lb./ sq. ft.)
0
Maximum Wind Resistance (mph)
0
Number of Doors
2
Number of People Recommended by Manufacturer to Assemble
2
Number of Windows
0
Product Weight (lb.)
346lb
Returnable
90-Day
Roof Color Family
White
Roof Material
Metal
Roof Pitch
1.9:12 Upper Section of Roof 9.4:12 Lower Secion of Roof
Roof Shape
Gambrel
Shed Door Type
Sliding
Shed Features
Door Latch,Double Door,Lockable Door
Shed Included
No Additional Items Included
Shed Style
Barn
Shed Type
Metal
Siding Color Family
Red
Storage Capacity (cu. ft.)
952

Warranty / Certifications

Manufacturer Warranty
10 year limited

Questions & Answers

dose this shed come with floor ?

Asked by: joedog
no
Answered by: Rgarcia
Date published: 2016-06-11

Can windows be added and what is the price to install it and the cost of 2 windows can be added

Asked by: Btooksey
No, I am sorry but windows cannot be added to this unit.
Answered by: Arrowsheds
Date published: 2017-10-03

What is the door size opening And does it come with the framing for the floor

Asked by: BCF
The door opening size is 55 1/2 inches Wide x 69 1/4 inches Tall. This unit does NOT come with a floor kit included.
Answered by: Arrowsheds
Date published: 2017-09-05

DO I NEED A CITY PERMITION TO INSTAL THIS SHED ?

DO I NEED A CITY PERMITION TO INSTAL THIS SHED ?
Asked by: FRANK
This is a question you would need to ask at your local code office Thank You
Answered by: Arrowsheds
Date published: 2016-12-06
  • y_2017, m_10, d_21, h_20CST
  • bvseo_bulk, prod_bvqa, vn_bulk_2.0.3
  • cp_1, bvpage1
  • co_hasquestionsanswers, tq_25
  • loc_, sid_100089770, prod, sort_[SortEntry(order=NUM_ANSWERS, direction=DESCENDING), SortEntry(order=SUBMISSION_TIME, direction=DESCENDING), SortEntry(order=LAST_APPROVED_ANSWER_SUBMISSION_TIME, direction=DESCENDING), SortEntry(order=LAST_APPROVED_ANSWER_SUBMISSION_TIME, direction=DESCENDING), SortEntry(order=BEST_ANSWER_FEEDBACK_COUNT, direction=DESCENDING), SortEntry(order=POSITIVE_ANSWER_FEEDBACK_COUNT, direction=DESCENDING), SortEntry(order=NUM_ANSWERS, direction=DESCENDING)]
  • clientName_homedepot
  • bvseo_sdk, java_sdk, bvseo-3.1.1
  • CLOUD, getContent, 95ms
  • QUESTIONS, PRODUCT

Customer Reviews

Red Barn 10 ft. x 14 ft. Metal Storage Building is rated 3.3 out of 5 by 28.
Rated 1 out of 5 by from Poor directions, long side panels were a real struggle to... Poor directions, long side panels were a real struggle to slide into place, roof holes on one side did not match up , every hole on that side had to be re-drilled. Lining up the doors took way too much time. A mistake to purchase.
Date published: 2017-09-05
Rated 5 out of 5 by from 5 Star Review Rating provided by a verified purchaser
Date published: 2017-09-08
Rated 5 out of 5 by from you get your monies worth purchased this unit over 25 years ago and is still standing (minus the doors). it was installed by my self and my teenage daughter while my husband was on another project. i had elected to make a 6" deep concrete pad with gravel under it for my rear yard has streams. every sq. ft. of this unit was used even the metal rafter was for overhead storage without reinforcement. i am now going to replace it with the same. we used portable shelves along with stationary for the many types of machinery and tools etc. we anchored it down with tie out dog cables at the time and they are still holding the shed in place, but then we were only girls being creative. this time we are extending the pad over the existing and pouring concrete columns, to incorporate a lean to for the firewood and additional oversize equipment. i highly recommend this product due to how it has stood up to the weather and the snow did not even dent the gable roof, the doors eventually came off because of the constant use.
Date published: 2012-05-29
Rated 3 out of 5 by from Big red barn My husband put this together, I helped when he got to the roof, it took him about a week. The metal is very thin and if it's windy you will have issues with it blowing around and bending while putting it together. He built a treated wood floor and screwed the shed to the floor but only when everything was finished, very important it is level or you will have issues making sides and roof line up. Some of the screw holes did not match up so he had to drill new ones. Once everything is assembled it seemed a little more solid but we haven't had a huge wind storm lately. It does leak so we will have to do something with the roof to seal it up before we start filling it up with our valuables. You should read the directions a few times to clearly understand as my husband had to redo a few things because directions leave out important information. If I had to do this all over again, I would buy a wood shed, something more stable. You get what you pay for.
Date published: 2016-07-26
Rated 5 out of 5 by from Arrow Red Barn Gambrel Shed This Arrow Red Barn Storage Shed is great quality and very sturdy. My neighbor influenced my buying decision when he informed me that his Arrow shed had been installed over 25 years ago and is still standing and doesn't leak. I bought this shed and glad I did. It took me and my wife approx. 6 hours and it was well worth it. I loaded it up with all my tools, riding lawnmower, pool supplies and some odds and ends. I priced other comparable dealers online like originalshelters.com and found that the value and price at Home Depot far exceeded my expectations. I would wholeheartedly recommend this Arrow Red Barn Shed to anyone needing to add some extra space around the garden or patio area. There are a lot of parts and it can seem overwhelming at first look. However, the detailed assembly instructions make it easy to set up. Thank you Arrow Sheds for such a great storage shed and your prices are second to none.
Date published: 2014-10-02
Rated 1 out of 5 by from Worst metal building ever Worst metal building ever, poorly designed, useless plans cheapest materiel, screws, nuts and bolts useless. Leaks like crazy, after one month, starts to rust, your company ought to be ashamed of itself. Don't look for any purchases from me.
Date published: 2016-01-22
Rated 4 out of 5 by from Storage Shed I am quite happy with this product. We needed extra storage that this has provided. We put a few freestanding shelves inside to better utilize the space. It only took a weekend to assemble.
Date published: 2010-06-08
Rated 4 out of 5 by from Pretty awesome for a metal shed It took 2 full days with me (semi-knowledgeable & skilled) and a friend (expert) to assemble this shed. Okay, he assembled it, I helped out a little. Anyway - I needed his expertise to be able to set up a level & square foundation, and his tools to make it go faster. Otherwise, the directions were mostly clear, with only a few areas that made us scratch our heads. Many of the parts did not have part numbers on them & a few of the parts arrived with damage to the exterior coating which was a disappointment. The biggest challenge was the roof; the center panels of the roof require you to stand very near the top of a 6' ladder and from there be able to reach across the 3' panels, with a power screwdriver in hand, to secure them. It was not easy - especially since I'm only 5'5" & he's not much taller than I am. My suggested improvements would be: 1. Number ALL the parts &/or number the bags that contain them. 2. Make the roof panels narrower even if that means you have to have one more. 3. Update the description of the item on your website - it describes a totally different item. and finally: 4. Include a little bottle of touch-up paint in both the red & the white so that any minor dings & scratches can be treated immediately, and 5. We would have loved to been able to choose this structure in a different color.
Date published: 2013-07-09
