Model # arlington_1220df

Internet #203431841

Best Barns Arlington 12 ft. x 20 ft. Wood Storage Shed Kit with Floor Including 4 x 4 Runners
0609788086758

Best Barns

Arlington 12 ft. x 20 ft. Wood Storage Shed Kit with Floor Including 4 x 4 Runners

  • High sidewalls and a large loft provides plenty of storage
  • Windows provide both ventilation and light (included)
  • Ready to paint any color. Purchase shingles to match your home
$699500 /each
store icon Loading Buying Options...
package icon Loading Buying Options...
Sorry, but we ran into issues loading these options. Please try refreshing.

Frequently Bought Together

Product Overview

  • High sidewalls and a large loft provides plenty of storage
  • Windows provide both ventilation and light (included)
  • Ready to paint any color. Purchase shingles to match your home
The Arlington by Best Barns offers a spacious interior and large loft area for all your storage needs. Featuring a second floor loft with 4 ft. - 3 in. headroom that provides enough space for a sleeping area if you are looking for a cabin or a significant amount of storage area. 2 (two) Dormers and a gable window with sunburst provide additional light and ventilation. The first floor, with it's high side walls, has plenty of room to add shelving for even more versatile storage. Included are double pocket doors, 1 (one) 32 in. x 80 in. 9 lite walk-in door, 2 (two) 18 in. x 36 in. windows with vinyl shutters, 1 (one) gable window with sunburst and 2 (two) dormers with windows. Floor included. Check with your local permit authority before placing order. Shingles purchased by homeowner. Building is shipped directly to you via curbside delivery. This kit requires customer to hand unload 12 ft. long 2 x 4's (approximately 30) when kit is delivered.
  • Assembled dimensions: 144 in. W x 240 in. D x 158 in. H
  • Sturdy-built truss system provides for 40 lb. snow load and 130 MPH wind load
  • Select grade pre-cut white pine trim
  • Premium LP smart side paneling grooved 8 in. O.C. treated to resist fungal decay and insect infestation carries a 50-year limited warranty, siding is primed ready to paint
  • Pre-assembled, 6 ft. - 6 in. high x 5 ft. - 5 in. wide pocket doors with cross buck door design
  • Deluxe floor with 3/4 in. plywood floor sheathing and treated 2 x 4 floor joist 16 in. O.C. and 4 x 4 runners included
  • Premium grade 2 x 4 imported from Sweden, wall studs are placed 24 in. O.C.
  • All required nails, hardware, glue are provided along with detailed easy to follow step-by-step instructions
  • Assembly required, some cutting required during assembly
  • 18 in. x 36 in. windows with vinyl shutters, gable and dormer windows include lower screen for ventilation
  • 15-year limited warranty
  • Free curbside delivery included
  • Check with your local permit office before purchasing
  • Click to find out more about buying outdoor storage sheds

Product Overview

  • High sidewalls and a large loft provides plenty of storage
  • Windows provide both ventilation and light (included)
  • Ready to paint any color. Purchase shingles to match your home
Model #: arlington_1220df
Internet #: 203431841

The Arlington by Best Barns offers a spacious interior and large loft area for all your storage needs. Featuring a second floor loft with 4 ft. - 3 in. headroom that provides enough space for a sleeping area if you are looking for a cabin or a significant amount of storage area. 2 (two) Dormers and a gable window with sunburst provide additional light and ventilation. The first floor, with it's high side walls, has plenty of room to add shelving for even more versatile storage. Included are double pocket doors, 1 (one) 32 in. x 80 in. 9 lite walk-in door, 2 (two) 18 in. x 36 in. windows with vinyl shutters, 1 (one) gable window with sunburst and 2 (two) dormers with windows. Floor included. Check with your local permit authority before placing order. Shingles purchased by homeowner. Building is shipped directly to you via curbside delivery. This kit requires customer to hand unload 12 ft. long 2 x 4's (approximately 30) when kit is delivered.

  • Assembled dimensions: 144 in. W x 240 in. D x 158 in. H
  • Sturdy-built truss system provides for 40 lb. snow load and 130 MPH wind load
  • Select grade pre-cut white pine trim
  • Premium LP smart side paneling grooved 8 in. O.C. treated to resist fungal decay and insect infestation carries a 50-year limited warranty, siding is primed ready to paint
  • Pre-assembled, 6 ft. - 6 in. high x 5 ft. - 5 in. wide pocket doors with cross buck door design
  • Deluxe floor with 3/4 in. plywood floor sheathing and treated 2 x 4 floor joist 16 in. O.C. and 4 x 4 runners included
  • Premium grade 2 x 4 imported from Sweden, wall studs are placed 24 in. O.C.
  • All required nails, hardware, glue are provided along with detailed easy to follow step-by-step instructions
  • Assembly required, some cutting required during assembly
  • 18 in. x 36 in. windows with vinyl shutters, gable and dormer windows include lower screen for ventilation
  • 15-year limited warranty
  • Free curbside delivery included
  • Check with your local permit office before purchasing
  • Click to find out more about buying outdoor storage sheds

Info & Guides

You will need Adobe® Acrobat® Reader to view PDF documents. Download a free copy from the Adobe Web site.

Specifications

Dimensions

Approximate Depth (ft.)
20
Approximate Width (ft.)
12
Assembled Depth (in.)
240 in
Assembled Height (in.)
163 in
Assembled Width (in.)
144 in
Coverage Area (sq. ft.)
240
Door Opening Height (In.)
78
Door Opening Width (In.)
65
Door Opening Width (ft.)
5
Exact Width x Depth
12 ft x 20 ft
Sidewall Height (in.)
97.0

Details

Assembly Required
Yes
Capacity (cu. ft.) - Total
2400
Color Family
Clear
Floor Options
With Floor and Runners
Foundation
Foundation Included
Manufacturers Recommended Assembly Time (hours)
96
Manufacturers Recommended Tools needed for Assembly
Safety Glasses, Hammer, Screwdriver, Level, Ladders, Tape Measure, Square, Drill, Circular Saw
Maximum Roof Load (lb./ sq. ft.)
40
Maximum Wind Resistance (mph)
130
Number of Doors
2
Number of People Recommended by Manufacturer to Assemble
3
Number of Windows
5
Product Weight (lb.)
2400lb
Returnable
90-Day
Roof Color Family
Clear
Roof Material
Wood
Roof Pitch
10/12
Roof Shape
Peak
Shed Door Type
Double
Shed Features
Door Latch,Double Door,Lockable Door,Loft,Shutters,Single Door,Windows
Shed Included
Floor
Shed Style
Ranch
Shed Type
Wood
Siding Color Family
Gray
Storage Capacity (cu. ft.)
2400

Warranty / Certifications

Manufacturer Warranty
15 Year Limited Warranty

Specifications

Dimensions

Approximate Depth (ft.)
20
Approximate Width (ft.)
12
Assembled Depth (in.)
240 in
Assembled Height (in.)
163 in
Assembled Width (in.)
144 in
Coverage Area (sq. ft.)
240
Door Opening Height (In.)
78
Door Opening Width (In.)
65
Door Opening Width (ft.)
5
Exact Width x Depth
12 ft x 20 ft
Sidewall Height (in.)
97.0

Details

Assembly Required
Yes
Capacity (cu. ft.) - Total
2400
Color Family
Clear
Floor Options
With Floor and Runners
Foundation
Foundation Included
Manufacturers Recommended Assembly Time (hours)
96
Manufacturers Recommended Tools needed for Assembly
Safety Glasses, Hammer, Screwdriver, Level, Ladders, Tape Measure, Square, Drill, Circular Saw
Maximum Roof Load (lb./ sq. ft.)
40
Maximum Wind Resistance (mph)
130
Number of Doors
2
Number of People Recommended by Manufacturer to Assemble
3
Number of Windows
5
Product Weight (lb.)
2400lb
Returnable
90-Day
Roof Color Family
Clear
Roof Material
Wood
Roof Pitch
10/12
Roof Shape
Peak
Shed Door Type
Double
Shed Features
Door Latch,Double Door,Lockable Door,Loft,Shutters,Single Door,Windows
Shed Included
Floor
Shed Style
Ranch
Shed Type
Wood
Siding Color Family
Gray
Storage Capacity (cu. ft.)
2400

Warranty / Certifications

Manufacturer Warranty
15 Year Limited Warranty

Questions & Answers

From the ceiling to the peak of the house, what’s the measurement in feet?

Asked by: Bbaby
The Arlington is not a house but is designed for use as a storage shed. Not counting the foundation the shed is 13 ft - 7 in tall. Please review elevations under "Info & Guides". Richard Best Barns
Answered by: Best Barns Support
Date published: 2017-09-25

can the barn door be placed on other side ?

can the barn door be placed on other side ?
Asked by: lori
Lori, You may orient wall, window and door placement as you desire. If you require the sliding doors on the opposite gable end simple set that wall in that position when erecting the structure. Richard Best Barns
Answered by: Best Barns Support
Date published: 2017-04-03

Can you disassemble the shed if need be?

Can you disassemble the shed if need be?
Asked by: Sarah
No, you can not disassemble the shed if need be.
Answered by: CommunityAnswer
Date published: 2017-02-16

Does this barn have up stairs

Asked by: Kat
Kat, The Best Barns Arlington has a loft area 8' wide running the length of the building. Richard Best Barns
Answered by: Best Barns Support
Date published: 2017-09-25
  • y_2017, m_10, d_16, h_24CST
  • bvseo_bulk, prod_bvqa, vn_bulk_2.0.3
  • cp_1, bvpage1
  • co_hasquestionsanswers, tq_16
  • loc_, sid_203431841, prod, sort_[SortEntry(order=NUM_ANSWERS, direction=DESCENDING), SortEntry(order=SUBMISSION_TIME, direction=DESCENDING), SortEntry(order=LAST_APPROVED_ANSWER_SUBMISSION_TIME, direction=DESCENDING), SortEntry(order=LAST_APPROVED_ANSWER_SUBMISSION_TIME, direction=DESCENDING), SortEntry(order=BEST_ANSWER_FEEDBACK_COUNT, direction=DESCENDING), SortEntry(order=POSITIVE_ANSWER_FEEDBACK_COUNT, direction=DESCENDING), SortEntry(order=NUM_ANSWERS, direction=DESCENDING)]
  • clientName_homedepot
  • bvseo_sdk, java_sdk, bvseo-3.1.1
  • CLOUD, getContent, 96ms
  • QUESTIONS, PRODUCT

Customer Reviews

Arlington 12 ft. x 20 ft. Wood Storage Shed Kit with Floor Including 4 x 4 Runners is rated 5.0 out of 5 by 1.
Rated 5 out of 5 by from 5 stars for the finished product, but.... First of all, let me start by saying I absolutely LOVE this building. We bought it for the purpose of making this a playhouse (future tiny house) for our twin girls. It is perfect for them, and the loft space doubles its square footage. We look forward to finishing out the interior. Here are the not so nice things I have to say about purchasing the building. The instructions are lacking LOTS of information for a DIYer. It says that this is for anyone who wants to diy, but the instructions assume that you know way more than u do. Because of this, we incurred many more costs than anticipated. Needless to say, the instructions could offer more detailed information and assume less that the buyer knows what I believe the manufacturer thinks is "understood."
Date published: 2016-12-27
