Model # TM1210CCUG2K

Internet #202046229

Store SKU #186429

GE PowerMark Gold 100 Amp 12-Space 22-Circuit Indoor Main Breaker Value Kit Includes Select Circuit Breaker
0043481052991

GE

PowerMark Gold 100 Amp 12-Space 22-Circuit Indoor Main Breaker Value Kit Includes Select Circuit Breaker

$57.75 /each

Frequently Bought Together

Product Overview

This value kit includes 3 20 Amp Single-Pole THQL 1 in. Circuit Breakers and a Ground Bar. The load center includes a sturdy tin-plated copper buss bar and a galvanized box for increased durability and reliability. The one-piece interior removes and re-installs easily. Indoor NEMA 1 enclosure with combination surface/flush front. This load center is UL listed and ANSI Certified.

  • For use as a main breaker load center
  • Galvanized box for rust resistance
  • Self-adjusting dead-front cover can be flush or surface mounted
  • Copper buss for excellent conductivity
  • Factory-installed main breaker
  • Full-length neutral bars for fast and easy wiring
  • 100% split neutral holes on each side are rated for #14-4 wire
  • Top or bottom feed
  • Single phase
  • 3 wire
  • 120/240-Volt
  • 22,000 AIC rating
  • For indoor use
  • Compatible with GFCI, AFCI, standard GE circuit breakers and GE 1/2 THQP
  • ANSI certified and UL listed
  • Includes three 20 Amp single-pole (THQL-1120) circuit breakers and 1 TGK24CP ground bar kit
  • Learn More About Electrical Panels Here in our Buying Guide.
  • Click here for more information on Electronic Recycling Programs

Info & Guides

You will need Adobe® Acrobat® Reader to view PDF documents.  Download a free copy from the Adobe Web site.

Specifications

Dimensions

Details

Warranty / Certifications

More Products With These Features

Search

Customer Questions & Answers

4 Questions3 Answers

Customer Questions & Answers

PowerMark Gold 100 Amp 12-Space 22-Circuit Indoor Main Breaker Value Kit Includes Select Circuit Breaker
PowerMark Gold 100 Amp 12-Space 22-Circuit Indoor Main Breaker Value Kit Includes Select Circuit Breaker

Ask your questions. Share your answers.



Clear Search Term


Sort By:

1 answer

looking at the picture of this 12 space panel I see three 20amp breakers but does the one in slot 2 and 4 100 amp included?

This question is from PowerMark Gold 100 Amp 12-Space 22-Circuit Indoor Main Breaker Value Kit Includes Select Circuit Breaker
Asked by
Read all my Q&A
December 6, 2015
0points
0out of 0found this question helpful.
Was this helpful?helpful0unhelpful0

Answer (1)

Asked by
St Louis, MO
Read all my Q&A
Home Improvement Profile: DIYer
December 19, 2015
Answer:
Yes, it does include the 100 amp main breaker that is pictured.
+1point
1out of 1found this answer helpful.
Was this helpful?helpful1unhelpful0

1 answer

Will this also except a THQP115 breaker

This question is from PowerMark Gold 100 Amp 12-Space 22-Circuit Indoor Main Breaker Value Kit Includes Select Circuit Breaker
Asked by
Wilm.,De.
Read all my Q&A
August 5, 2015
0points
0out of 0found this question helpful.
Was this helpful?helpful0unhelpful0

Answer (1)

Asked by
Jersey City, NJ
Read all my Q&A
Home Improvement Profile: DIYer
September 27, 2015
Answer:
I have this box. The product overview above correctly says this panel takes the THQP ("Q") breakers. The letter P designates the thin 1/2" thickness breakers. All acceptable breakers are listed on the back of the GE panel carton so at the store, you never have to try out the shelf breaker for fit.
However these thinner 1/2" breakers can only fit in lower 20 slots, not at the spaces left of the 100A Main Read More
I have this box. The product overview above correctly says this panel takes the THQP ("Q") breakers. The letter P designates the thin 1/2" thickness breakers. All acceptable breakers are listed on the back of the GE panel carton so at the store, you never have to try out the shelf breaker for fit.
However these thinner 1/2" breakers can only fit in lower 20 slots, not at the spaces left of the 100A Main Breaker. Those 2 spaces only take the "QL" or 1" breakers. Therefore 20 thin + 2 thick = 22 = max circuit capacity as correctly stated in Home Depo's Specification page.
Internally, The 2 neutral busses are not connected for versatility (unless you use the supplied ground screw as instructed). Read Less
+1point
1out of 1found this answer helpful.
Was this helpful?helpful1unhelpful0

1 answer

Why can't I buy this anywhere in Michigan or South Carolina?

This question is from PowerMark Gold 100 Amp 12-Space 22-Circuit Indoor Main Breaker Value Kit Includes Select Circuit Breaker
Asked by
Tom
May 20, 2011
0points
0out of 0found this question helpful.
Was this helpful?helpful0unhelpful0

Answer (1)

Asked by
THDCustomerService
Atlanta, GA
June 6, 2011
Answer:
Hi Tom - this is Bethany from Home Depot. You are able to order this product online from homedepot.com or you can order through your local store as a special order. If you do visit your store, bring with you the model number which is: TM1210CCUG2K. Hope this helps!
-2points
0out of 2found this answer helpful.
Was this helpful?helpful0unhelpful2

0 answers

what are the dimensions of the box? Not the cover but the box only for this item

This question is from PowerMark Gold 100 Amp 12-Space 22-Circuit Indoor Main Breaker Value Kit Includes Select Circuit Breaker
Asked by
Boston
Read all my Q&A
September 20, 2016
0points
0out of 0found this question helpful.
Was this helpful?helpful0unhelpful0
