General Tools 14-in-1 Data Logging Thermo-Hygrometer/Moisture Meter
0681035016206

General Tools

14-in-1 Data Logging Thermo-Hygrometer/Moisture Meter

  • Reads surface temp, moisture and atmospheric pressure
  • Pin-type probe included for absolute moisture level readings
  • Settable alarms for high and low moisture level alerts
$30526 /each
store icon Loading Buying Options...
package icon Loading Buying Options...
Sorry, but we ran into issues loading these options. Please try refreshing.

Frequently Bought Together

Product Overview

The RHMG700DL appeals to HVAC/R system installers and technicians, facility maintenance professionals and water damage restoration contractors. This instrument measures ambient temperature, relative humidity (RH), absolute humidity (AH, in mg/L or g/cubic meter), GPP (mixing ratio in grains per pound or g/kg), relative moisture level using painless sensor, absolute moisture level using included pin-type probe, dew point, wet bulb temperature, surface temperature (requires optional K type thermocouple probe), condensation temperature (requires optional K type thermocouple probe), atmospheric pressure and vapor pressure. It stores 20 pairs of readings and features a large LCD screen for easy visibility.

California residents: see   Proposition 65 information

  • Stores/recalls 20 pairs of readings in/from on-board nonvolatile memory
  • Logs up to 8000 data points internally for later download and display as excel-formatted graph or table on Windows PC using included software, driver and USB cable
  • Settable high and low alarms for RH, relative moisture level and absolute moisture level
  • Minimum/maximum, data hold and 30 minute auto power off functions
  • Field calibratable in pinless moisture level mode
  • Absolute humidity range: 0.5 to 240mg/L
  • GPP range: 0 to 999 GPP
  • Relative absolute moisture level range: 0 to 99.9%
  • Pinless moisture measurement depth: 0.75 in.
  • Dew point range: -76 Degree to 140 Degrees F
  • Atmospheric pressure range: 30 to 120 kPA
  • Vapor pressure range: 0 to 20.0 kPA
  • Surface temperature measurement range: -148 Degrees to 1832 Degrees F
  • Backlit LCD with 3-digit primary readout plus 4-digit secondary readout
  • Includes pin-type moisture probe, sensor protection cap, PC interface/data logging program and driver on mini-disc, USB cable, user's manual

Info & Guides

You will need Adobe® Acrobat® Reader to view PDF documents.  Download a free copy from the Adobe Web site.

Compare Similar

Price
$305.26 /each
Add to Cart to See Price Add to Cart to See Price
$599.06 /each
Name 14-in-1 Data Logging Thermo-Hygrometer/Moisture Meter Pinless Moisture Meter/IR with Data Logging Pinless Moisture Meter with Bluetooth Wireless Moisture Meter, Pinless
Brand General Tools Extech Instruments Extech Instruments Extech Instruments
Ratings (0) (0) (0) (0)
View Product View Product View Product View Product

Specifications

Dimensions

Product Depth (in.)
1.4
Product Height (in.)
7.3
Product Width (in.)
2.8

Details

Battery Power Type
Alkaline
Battery Size
9-volt
Display Type
LCD
External Electrode
Included
Features
Audible Alert,Backlit,Data Hold,Data Log/Record,Interchangeable Pins/Probes
Maximum Moisture Reading (%)
99
Maximum Sense Depth (in.)
0.75
Measureable Materials
Wood, Building Materials
Minimum moisture reading (%)
0
Number of Batteries Required
1
Product Weight (lb.)
0.39lb
Returnable
90-Day
Test Meter Type
Moisture Meter
Tools Product Type
Test Meter

Warranty / Certifications

Manufacturer Warranty
1 Year

More Products With These Features

Search

Customer Questions & Answers

Will this unit read ambient moisture indoors accurately? I need to check this and wanted to know the coverage area

Asked by: DJT
This will measure the humidity.
Answered by: CommunityAnswer
Date published: 2016-09-19

could you it on fiberglass

i have humidity and moisture in the hull of my boat
Asked by: christophe
YES IT WILL READ THE TEMP BUT NOT THE MOISTURE
Answered by: Diane Hewitt
Date published: 2016-07-02

Can you find moisture problem inside walls

Asked by: DE
NO IT WILL ONLY WORK ON THE SURFACE
Answered by: Diane Hewitt
Date published: 2016-06-24

Does this read Dew Points? are the prongs the only way you can get the readings or is that a sen...

Does this read Dew Points? are the prongs the only way you can get the readings or is that a sensor for air readings on the top?
