Model # CTA9090980.ES

Internet #202065072

Industrial Air 9 Gal. Portable Wheelbarrow Air Compressor with 9 HP Electric Start Honda Gas Engine
0846212004074

Industrial Air

9 Gal. Portable Wheelbarrow Air Compressor with 9 HP Electric Start Honda Gas Engine

$152910 /each
store icon Loading Buying Options...
package icon Loading Buying Options...
Sorry, but we ran into issues loading these options. Please try refreshing.

Frequently Bought Together

Product Overview

Industrial Air Contractor 9 Gal. compressor delivers up to 18 SCFM at 90 PSI for excellent tool performance. The twin-tank, wheelbarrow design is equipped with 2 turf-treads, semi-pneumatic tires for easy mobility. It is designed with an enhanced structural support underneath the platform to transfer vibrations into the ground.

  • 9 HP, electric-start, Honda engine features an OHV design, 3-Amp charging system, automotive-style air cleaner, 6-liter fuel tank and meets EPA and CARB emission requirements.
  • 155 maximum PSI
  • Delivers 18 SCFM at 90 PSI
  • Wheelbarrow, twin-tank design
  • 3-cylinder pump has 1-piece cast-iron crankcase, stainless steel flex leaf valves, oil level sight glass, easily accessible oil fill and drain, 16 in. cast-iron balanced flywheel and large intake filter/silencers
  • Low-oil shutoff
  • 2 center-mount, turf-tread, semi-pneumatic tires
  • Structural support under platform transfers vibrations to the ground
  • Equipped with 1/2 in. unregulated, high-pressure port for an additional air line
  • Integrated battery tray compartment to secure cable connection for electric start
  • A 12 volt battery (maximum dimensions = 8” L x 4.5" W x 7.5” H), 18" battery hold strap, and 32" (4 gauge) battery cables are not included and must be purchased separately.
  • Need help? CLICK HERE to view our Air Compressor Buying Guide

Info & Guides

You will need Adobe® Acrobat® Reader to view PDF documents.  Download a free copy from the Adobe Web site.

Specifications

Dimensions

Product Depth (in.)
48.5
Product Height (in.)
33
Product Width (in.)
24.5

Details

Air Delivery SCFM @ 40PSI
20.6
Air Delivery SCFM @ 90PSI
18.1
Application Use
Air Brushing,Blow Cleaning,Bolting/Wrenching,Brad Nailing/Stapling,Finish Nailing,Framing Nailing,HVLP Painting,Hobby Nailing,Hobby Painting,Inflation,Roof Nailing,Spraying
Compressor Tank Capacity (Gallons)
9
Compressor Type
Framing & Roofing
Compressor/Air Tool Features
Handle,Tank Pressure Gauge
Decibel Rating (Outdoor)
90 dBA
Fuel Tank Capacity (gallons)
1
Horsepower (hp)
9
Included
No additional components or accessories are included
Lubrication Type
Oil-Lubricated
Maximum Pressure (psi)
155
Portable
Yes
Power Source
Gas
Product Weight (lb.)
360lb
Reconditioned
No
Returnable
30-Day
Stage Count
Single Stage
Tank Material
Steel
Tank Style
Wheelbarrow
Tools Product Type
Air Compressor

Warranty / Certifications

Certifications and Listings
CARB Compliant,EPA Approved
Manufacturer Warranty
2 year limited

More Products With These Features

Search

Customer Questions & Answers

Does it come with a battery and cables

Asked by: todd
Cables yes but no battery.
Answered by: mike
Date published: 2016-10-22

Where this unit made in

Asked by: 242H
  • y_2017, m_8, d_18, h_10CST
  • bvseo_bulk, prod_bvqa, vn_bulk_1.0.0-hotfix-1
  • cp_1, bvpage1
  • co_hasquestionsanswers, tq_2
  • loc_, sid_202065072, prod, sort_[SortEntry(order=NUM_ANSWERS, direction=DESCENDING), SortEntry(order=SUBMISSION_TIME, direction=DESCENDING), SortEntry(order=LAST_APPROVED_ANSWER_SUBMISSION_TIME, direction=DESCENDING), SortEntry(order=LAST_APPROVED_ANSWER_SUBMISSION_TIME, direction=DESCENDING), SortEntry(order=BEST_ANSWER_FEEDBACK_COUNT, direction=DESCENDING), SortEntry(order=POSITIVE_ANSWER_FEEDBACK_COUNT, direction=DESCENDING), SortEntry(order=NUM_ANSWERS, direction=DESCENDING)]
  • clientName_homedepot
  • bvseo_sdk, java_sdk, bvseo-3.1.1
  • CLOUD, getContent, 95ms
  • QUESTIONS, PRODUCT

Customer Reviews

9 Gal. Portable Wheelbarrow Air Compressor with 9 HP Electric Start Honda Gas Engine is rated 3.0 out of 5 by 6.
Rated 1 out of 5 by from Worst compressor I cannot recommend this product as it only works for 3 months of use before seizing up. Then then company can't send the right parts so plan on being down for three to 4 weeks in the middle of the busy season. So much for industrial for contractors.
Date published: 2017-08-02
Rated 1 out of 5 by from One of the two compressors I purchased came without parts.... One of the two compressors I purchased came without parts. I have spoke with the service department and supplied pictures, I still have not received the parts.
Date published: 2017-05-09
Rated 5 out of 5 by from 5 Star Review Rating provided by a verified purchaser
Date published: 2017-04-21
Rated 3 out of 5 by from Requires alignment I had read other reviews stating that the unit arrived with the pulleys misaligned. I had the same experience. The belt was frayed along the edges apparently from when the unit was test run in assembly. Alignment was off by almost a full inch. You have to adjust the motor mounts and pulley yourself. How do these leave the factory in this condition? Once aligned, the unit runs and performs great. I still recommend it but rate it 3 stars because misalignment is not an isolated incident.
Date published: 2016-10-11
Rated 5 out of 5 by from No problems after almost a year. It's been almost a year since we picked this compressor up and we haven't had one problem out of it. We use it probably once a week. It is heavy two guys can't pick it up takes two guys just to move it around. It does NOT come with a battery but does have all the wires to hook one up. We haven't got a battery yet because with the Honda engines it only takes one pull to start.
Date published: 2016-10-22
Rated 3 out of 5 by from Read the fine print Item stated electric start in description it fails to add battery and cabels not included. An hour of running around and $60 later, i had an electric start.
Date published: 2016-10-25
