Model # DIYKIT

Internet #205377486

Store SKU #1000091526

Kreg DIY Project Kit
0647096805142

Kreg

DIY Project Kit

  • Rip-cut works with most circular saws
  • Jig pocket hole system for pocket holes in various materials
  • Shelf-pin jig for 5 mm holes for adjustable shelf pins
$79.00 /each

Frequently Bought Together

Product Overview

Get multiple tools from one Kreg DIY Project Kit. You can attach the rip-cut circular saw guide to almost any circular saw to easily cut large sheet goods. The jig pocket hole system makes project assembly simple using a drill and strong, simple pocket-hole joinery. The shelf pin makes evenly spaced, consistent holes for pins that hold adjustable shelves.

  • Rip-cut works with most circular saws and cuts sheet goods up to 24 in. wide
  • Jig pocket hole system creates pocket holes in materials from 1/2 to 11/2 in. thick
  • Shelf-pin jig creates 5 mm holes for adjustable shelf pins and has a removable dual-position fence
  • Comes with 10 free downloadable step-by-step project plans

Specifications

Dimensions

Details

More Products With These Features

Search

Customer Questions & Answers

4 Questions12 Answers

Customer Questions & Answers

DIY Project Kit
DIY Project Kit

Ask your questions. Share your answers.



Clear Search Term


Sort By:
This question is from DIY Project Kit

3 answers

does this include the clamp for the pocket hole jig

This question is from DIY Project Kit
Asked by
Read all my Q&A
December 4, 2015
0points
0out of 0found this question helpful.
Was this helpful?helpful0unhelpful0

Answers (3)

Asked by
Savage, Mn
Read all my Q&A
May 31, 2016
Answer:
No clamp is included.
0points
0out of 0found this answer helpful.
Was this helpful?helpful0unhelpful0

Asked by
Read all my Q&A
January 5, 2016
Answer:
No,that would be nice. I am planning on buying one.
+2points
2out of 2found this answer helpful.
Was this helpful?helpful2unhelpful0

Asked by
Boulder, Colorado
Read all my Q&A
December 29, 2015
Answer:
No it does not. But your standard clamp should suffice to hold the jig in place.
+2points
2out of 2found this answer helpful.
Was this helpful?helpful2unhelpful0
This question is from DIY Project Kit

3 answers

What circular saw brands can I use with the kid?

This question is from DIY Project Kit
Asked by
Read all my Q&A
November 17, 2015
0points
0out of 0found this question helpful.
Was this helpful?helpful0unhelpful0

Answers (3)

Asked by
Savage, Mn
Read all my Q&A
May 31, 2016
Answer:
It adjust to almost all the popular brands, and probably all if you know what your doing.
0points
0out of 0found this answer helpful.
Was this helpful?helpful0unhelpful0

Asked by
Arizona
Read all my Q&A
Home Improvement Profile: DIYer
February 6, 2016
Answer:
I use it with a Ryobi cordless 5-3/8-inch circular saw and it works great on both 3/4-inch plywood and cross-cutting 2x6's. I leave the saw attached to the Kreg base and for cross-cutting, I just run the base against my 12-inch framing square.
+1point
1out of 1found this answer helpful.
Was this helpful?helpful1unhelpful0

Asked by
Denton, TX
Read all my Q&A
Home Improvement Profile: Professional
December 9, 2015
Answer:
You can use any as far as I know, I used it with a Craftsman. It clamps to the saw and as far as I can tell it is universal. I am not sure about the worm gear style saw though.
+2points
2out of 2found this answer helpful.
Was this helpful?helpful2unhelpful0
This question is from DIY Project Kit

3 answers

What are the 3 parts?

This question is from DIY Project Kit
Asked by
Read all my Q&A
September 22, 2015
It says the kit combines 3 must-haves, but I'm unsure what they are. The circular saw, drill and what - a drill guide?
0points
0out of 0found this question helpful.
Was this helpful?helpful0unhelpful0

Answers (3)

Asked by
Savage, Mn
Read all my Q&A
May 31, 2016
Answer:
There's a small Kreg screw joining set (with some starter screws, practice on some scrap wood first!), a shelf peg jig for drilling perfectly aligned shelf peg holes, and a skill saw guide that screws to the saw to rip perfect straight lines (up to 24" across).
0points
0out of 0found this answer helpful.
Was this helpful?helpful0unhelpful0

Asked by
Arizona
Read all my Q&A
Home Improvement Profile: DIYer
February 6, 2016
Answer:
The three parts are:
(1) Kreg Pocket Hole Jig Kit (includes adjustable pocket hole guide, Kreg drill bit, long #2 square drive for driving Kreg screws, stop collar for drill bit, Allen wrench for tightening stop collar set screw, and small assortment of Kreg screws and a plasttic case to hold everything..
(2) Kreg Shelf Pin Guide (includes the shelf pin hole drilling guide, 1/4" and 5 mm indexing pin,
Read More
The three parts are:
(1) Kreg Pocket Hole Jig Kit (includes adjustable pocket hole guide, Kreg drill bit, long #2 square drive for driving Kreg screws, stop collar for drill bit, Allen wrench for tightening stop collar set screw, and small assortment of Kreg screws and a plasttic case to hold everything..
(2) Kreg Shelf Pin Guide (includes the shelf pin hole drilling guide, 1/4" and 5 mm indexing pin, and the 5 mm drill bit with 1/4" shank. The bit and indexing pin fit neatly into slots in the bottom of the drilling guide.
(3) Kreg Rip Cut Saw Guide (includes the 30-inch aluminum guide bar and the saw mounting base. There is some minor assembly required that's all spelled out clearly in the user manual.
Read Less
+1point
1out of 1found this answer helpful.
Was this helpful?helpful1unhelpful0

Asked by
Read all my Q&A
October 21, 2015
Answer:
There is no saw or drill, these are guides for those tools, from the description, the three tools are:
Kreg rip-cut: works with most circular saws, cuts sheet goods up to 24 in. wide
Kreg jig R3: creates pocket holes in materials from 1/2 in. to 11/2 in. thick
Shelf-pin jig: creates 5 mm holes for adjustable-shelf pins, removable dual-position fence
+4points
4out of 4found this answer helpful.
Was this helpful?helpful4unhelpful0
This question is from DIY Project Kit

3 answers

What type of screws?

This question is from DIY Project Kit
Asked by
Read all my Q&A
September 3, 2015
Do I have to purchase a special type of screw to use this kit? If not; what type do I need when working with 3/4 inch to sheets of wood? What thickness wood is recommended for drawers?
0points
0out of 0found this question helpful.
Was this helpful?helpful0unhelpful0

Answers (3)

Asked by
Savage, Mn
Read all my Q&A
May 31, 2016
Answer:
You should use special joining screws made for the different types of woods (plywood, solid wood...) They are readily available at most hardware stores. There are instructions is the kit that explain what you should use (or google Kreg for the info)
0points
0out of 0found this answer helpful.
Was this helpful?helpful0unhelpful0

Asked by
Boulder, Colorado
Read all my Q&A
December 29, 2015
Answer:
You'll need the Kreg Pocket Hole screws. It comes with an assortment but not enough to finish a project. You can buy them along with your jigs. Just make sure you get the coarse or fine ones, depending on whether you're working in soft or hard word, respectively; as well as the proper length. I believe the kit includes instructions on the length of the screw to use depending on the width of the boards Read More
You'll need the Kreg Pocket Hole screws. It comes with an assortment but not enough to finish a project. You can buy them along with your jigs. Just make sure you get the coarse or fine ones, depending on whether you're working in soft or hard word, respectively; as well as the proper length. I believe the kit includes instructions on the length of the screw to use depending on the width of the boards being joined. You can probably also find that online or in your project plans.
http://www.homedepot.com/p/Kreg-2-in-Coarse-Zinc-Plated-Steel-Square-Head-Pocket-Screw-50-Pack-SML-C2-50/205377484 Read Less
+3points
3out of 3found this answer helpful.
Was this helpful?helpful3unhelpful0

Asked by
Anonymous
Orange, Ca.
Home Improvement Profile: Other
September 3, 2015
Answer:
Hi Chiris, this kit is designed for you to use pocket hole screws.
Here is a link to show you the different sizes and threads.
http://www.homedepot.com/s/kreg%2520screws?NCNI-5
+3points
3out of 3found this answer helpful.
Was this helpful?helpful3unhelpful0
1 of 1
  • 2016-10-31 T01:48:18.671-05:00
  • bvseo_lps, prod_bvqa, vn_prr_5.6
  • cp-1, bvpage1
  • co_hasquestionsanswers
  • loc_en_US, sid_205377486, prod, sort_default
1 of 1
  • bvseo_sdk, java_sdk, bvseo-3.1.1
  • CLOUD, getContent, 45ms
  • QUESTIONS, PRODUCT

Customer Reviews

DIY Project Kit is rated 4.8 out of 5 by 31.
Rated 4 out of 5 by from pocket hole system works great but rip cut jig doesn't Pocket hole system works great and pleased with the ease of use. I'm disappointed with the rip cut jig. When I went to attach the plastic rail to the metal saw guide I noticed that they don't form a 90 degree angle. The holes were misaligned and didn't allow for straight cuts which pretty much defeats the purpose of the product. I haven't used the shelf jig.
Date published: 2016-08-02
Rated 5 out of 5 by from Bought as a present I bought this for my husband as a gift. He had looked at it in the store but didn't get it and then they quit carrying it in the store. I kept the info then ordered it online for Christmas. He was thrilled! He hasn't used it yet but has several probjects in mind when the weather is better. I'm very happy with the purchase!
Date published: 2017-01-10
Rated 5 out of 5 by from I really like the pocket hole drill jig. This system works very well. Very good holding power and... I really like the pocket hole drill jig. This system works very well. Very good holding power and easy to use. I may stop using glue......I haven't used the shelf hole jig yet. The saw guide was shorter than I thought but worked well. Great DIY tool.
Date published: 2017-01-04
Rated 5 out of 5 by from Good Tools Have only used each part of the kit a couple of times so far. For what I do (amateur woodworker), they work fine for me. Will definitely use them on my future projects.
Date published: 2017-01-03
Rated 5 out of 5 by from DIY Project Kit It makes the jobs very clean and efficient to accomplish.
Date published: 2017-01-03
Rated 4 out of 5 by from Practical and easy to use Convenient and useful for non complicated joining needs.
Date published: 2016-08-09
Rated 5 out of 5 by from Very handy versatile system I used this system to build a custom desk. The pocket jig is a genius system that holds very well and makes quick work of joinery. The shelf pin works great and is easier and more reliable than using a peg board template. The rip cut is a nice help for making long straight cuts. I used it to rip a sheet of plywood in half, which was very nice. If you plan on doing small DIY projects, this is a good kit to pick up.
Date published: 2014-11-05
Rated 5 out of 5 by from My love for woodwork has come back again This pocket hole kit has renewed my love in woodworking. I dreaded using biscuits/dowels and leaving a clamp on some glue for joints overnight, it was headache. With this kit, I was able to assemble a beautiful coffee table in 40 minutes at best! I can't wait to use it when I get to my sisters house, she needs some renovation!!! What a great kit!!!
Date published: 2015-02-03
