Master Flow 8 in. x 25 ft. Insulated Flexible Duct R8 Silver Jacket
0050206029244

Master Flow

8 in. x 25 ft. Insulated Flexible Duct R8 Silver Jacket

$4695 /each

Product Overview

The Master Flow 8 in. x 25 ft. Insulated Flexible Duct R8 Silver Jacket is used in standard Heating and Air Conditioning (HVAC) systems and some venting applications. The duct has R8 insulation which contains 50% more insulation than the standard R4.2 product. This additional insulation provides greater thermal efficiency to save energy. The product is also covered in a heavy duty, silver jacket for durability. The duct is ETL listed, meeting the UL181 standard.
store icon Loading Buying Options...
package icon Loading Buying Options...
Sorry, but we ran into issues loading these options. Please try refreshing.

Frequently Bought Together

Product Overview

The Master Flow 8 in. x 25 ft. Insulated Flexible Duct R8 Silver Jacket is used in standard Heating and Air Conditioning (HVAC) systems and some venting applications. The duct has R8 insulation which contains 50% more insulation than the standard R4.2 product. This additional insulation provides greater thermal efficiency to save energy. The product is also covered in a heavy duty, silver jacket for durability. The duct is ETL listed, meeting the UL181 standard.
  • R8 fiberglass insulation for greater insulating power
  • Flexible duct is convenient for use in multiple applications including heating and A/C systems and some venting
  • Oversized core to connect quickly and easily to standard sheet metal fitting
  • Galvanized core wire for greater corrosion resistance vs. non-galvanized wire
  • Duct can be cut to length as needed
  • Insulated duct features a maximum temperature rating of 200°F
  • Always install per instructions and seal using approved mastic or sealant (or approved tape)

Product Overview

Model #: F8IFD8X300
Sku #: 812305
Internet #: 202562741

The Master Flow 8 in. x 25 ft. Insulated Flexible Duct R8 Silver Jacket is used in standard Heating and Air Conditioning (HVAC) systems and some venting applications. The duct has R8 insulation which contains 50% more insulation than the standard R4.2 product. This additional insulation provides greater thermal efficiency to save energy. The product is also covered in a heavy duty, silver jacket for durability. The duct is ETL listed, meeting the UL181 standard.

  • R8 fiberglass insulation for greater insulating power
  • Flexible duct is convenient for use in multiple applications including heating and A/C systems and some venting
  • Oversized core to connect quickly and easily to standard sheet metal fitting
  • Galvanized core wire for greater corrosion resistance vs. non-galvanized wire
  • Duct can be cut to length as needed
  • Insulated duct features a maximum temperature rating of 200°F
  • Always install per instructions and seal using approved mastic or sealant (or approved tape)

Info & Guides

You will need Adobe® Acrobat® Reader to view PDF documents. Download a free copy from the Adobe Web site.

Specifications

Dimensions

Product Depth (in.)
300
Product Diameter (in.)
8.0 in
Product Height (in.)
12
Product Length (in.)
300 in
Product Width (in.)
12

Details

Color
Silver Jacket
Insulated
Yes
Insulation R-Value
8
Insulator material
Other
Material
Fiberglass
Maximum air flow (CFM)
200.0
Returnable
90-Day

Warranty / Certifications

Certifications and Listings
2-UL Recognized,ETL Listed

Specifications

Dimensions

Product Depth (in.)
300
Product Diameter (in.)
8.0 in
Product Height (in.)
12
Product Length (in.)
300 in
Product Width (in.)
12

Details

Color
Silver Jacket
Insulated
Yes
Insulation R-Value
8
Insulator material
Other
Material
Fiberglass
Maximum air flow (CFM)
200.0
Returnable
90-Day

Warranty / Certifications

Certifications and Listings
2-UL Recognized,ETL Listed

Questions & Answers

Installation over existing hard duct

Can this product be safely installed over existing hard ductwork? I am wanting to use it to insulate an existing duct in a crawlspace.
Asked by: Patrick
I haven't tried it for a long length but the insulation sleeve easily fit over the section of duct that I pulled it over. I think that it can work if you just take out the core.
Answered by: debuda
Date published: 2016-04-16

What is the vapor transmission rating of this product?

What is the vapor transmission rating of this product?
Asked by: Ben
GAF doesn't seem to publish a WVTR for this product. I am not sure what your critical application is that would warrant needing that number. I suspect it is something like 0.1 but that is a guess and you would be better off contacting GAF Technical Support if it is a critical parameter for your application. Typically that number is more important to pharmaceutical companies and food companies when it comes to packaging.
Answered by: engr4you
Date published: 2017-09-15

Does this product meet California / San diego building code

Asked by: Woody
This product meets all of the national and state codes. Individual city codes will have to investigated individually. Please call Technical Services at 800-211-9612, M-F 8A-5P EDT, for additional information.
Answered by: Master Flow
Date published: 2016-06-17

How much dose this bag of flex weigh?

Asked by: gr
one box of 8" flex weighs approximately 18 pounds. Please call MasterFlow Customer Care at 800-755-9392, M-F 8A-5P ET for any additional information.
Answered by: Master Flow
Date published: 2016-01-27
  • y_2017, m_10, d_19, h_24CST
  • bvseo_bulk, prod_bvqa, vn_bulk_2.0.3
  • cp_1, bvpage1
  • co_hasquestionsanswers, tq_5
  • loc_, sid_202562741, prod, sort_[SortEntry(order=NUM_ANSWERS, direction=DESCENDING), SortEntry(order=SUBMISSION_TIME, direction=DESCENDING), SortEntry(order=LAST_APPROVED_ANSWER_SUBMISSION_TIME, direction=DESCENDING), SortEntry(order=LAST_APPROVED_ANSWER_SUBMISSION_TIME, direction=DESCENDING), SortEntry(order=BEST_ANSWER_FEEDBACK_COUNT, direction=DESCENDING), SortEntry(order=POSITIVE_ANSWER_FEEDBACK_COUNT, direction=DESCENDING), SortEntry(order=NUM_ANSWERS, direction=DESCENDING)]
  • clientName_homedepot
  • bvseo_sdk, java_sdk, bvseo-3.1.1
  • CLOUD, getContent, 26ms
  • QUESTIONS, PRODUCT

Customer Reviews

8 in. x 25 ft. Insulated Flexible Duct R8 Silver Jacket is rated 4.9 out of 5 by 9.
Rated 5 out of 5 by from Works just fine to replace thirty year old duct that... Works just fine to replace thirty year old duct that was falling apart.
Date published: 2017-09-26
Rated 5 out of 5 by from Good product... Good product
Date published: 2017-05-16
Rated 4 out of 5 by from It's Insulated Duct. What can you say about insulated duct? It is used in homes starting at the furnace plenum. Wish that weren't true. In many cases it doesn't need to be insulated since basements are often finished.In my opinion, the length should be limited to 15 feet by code in conditioned spaces but no one seems to have a clue about hard piped duct anymore in residential and not all the pieces needed are sold by the Home Depot to do that kind of work properly.. One big negative is that people crush the insulated flex duct to get around some clearance issue where rectangular hard duct would solve the problem. Then they wonder why the room gets hot or cold. So the product is okay and the insulation seems to be good quality (and is now thicker and more effective in attics). No reason not to buy it. Make sure you connect it properly with tie wraps in addition to foil tape and also one or two screws through the tie wrap to make it even better. That is what folks do in commercial work. And consider "saddles" and the correct strapping to prevent restrictions where the duct sags.
Date published: 2015-03-24
Rated 5 out of 5 by from great product and easy to use Recently bought this and it was easy to install. Before using this product there was an aluminuim pipe and as soon as I installed this in the attic for a return vent, the HVAC unit was working less and the tempreture inside the house was dropping mich faster. Worth spending the extra $16 to get the R8 silver jacket.
Date published: 2016-06-06
Rated 5 out of 5 by from Home Owner DIY Product arrived quickliy via UPS and was relatively simple to intall as a non-contractor DIY fix.
Date published: 2016-05-22
Rated 5 out of 5 by from Exactly as expected Great ductwork, exterior sheath is very strong, and stood up to prodding into place with a broom stick no problem. Used this along with airtec / rectorseal diffusers to install jump ducts to solve an hvac pressure relief issue in the master bedroom. Didn't want to undercut the door due to privacy. This ductwork & those diffusers made it a diy project & saved me hundreds over the quotes I got.
Date published: 2012-03-27
Rated 5 out of 5 by from great insulation Came in ahead of time.looks like a quality product
Date published: 2011-11-22
Rated 5 out of 5 by from works great Works great keeps a great air flow from one room to the next.
Date published: 2014-06-18
