Model # 48-20-5035

Internet #203176105

Store SO SKU #1000470343

Milwaukee 2 in. x 2-13/16 in. Thin Wall SDS-Plus Core Bit
0045242105304

Milwaukee

2 in. x 2-13/16 in. Thin Wall SDS-Plus Core Bit

$9527 /each
store icon Loading Buying Options...
package icon Loading Buying Options...
Sorry, but we ran into issues loading these options. Please try refreshing.

Frequently Bought Together

Product Overview

Milwaukee's Carbide Tipped Core Bits are ideal for drilling large holes where the depth is relatively shallow. The Core Bit cuts a kerf only. The usable depth of Thin Wall Core Bits ranges from 2-13/16 in. to 3-3/16 in. The Thin Wall construction is ideal for smaller hammers and newer concrete. The inside core must be removed by the operator before deeper drilling can be accomplished. Multiple extensions and adapters are available to allow for deeper holes to be drilled. The appropriate drive shank must be used to drive the Core Bit. Use of Center Pin and Guide Plate is recommended for positioning and starting a 1-1/4 in. hole and larger. Use of Center Pin and Guide Plate is not recommended for positioning and starting a 1-1/8 in. hole or smaller. Milwaukee Carbide Tipped Core Bits are available from 1 in. to 6 in. Dias. Includes Core Bit Centering Pin and Guide Plate.

  • 2 in. Dia
  • Usable cutting depth 3 in.
  • Thin wall
  • Use with SDS core bit shank 48-03-3555 (8 in.) or 48-03-3561 (12 in.)

Info & Guides

You will need Adobe® Acrobat® Reader to view PDF documents.  Download a free copy from the Adobe Web site.

Specifications

Dimensions

Assembled Depth (in.)
2.65 in
Assembled Height (in.)
7.44 in
Assembled Width (in.)
2.65 in
Bit Diameter
2 in
Bit Length (in.)
7
Shank Diameter
3/4 in

Details

Bit Material
Carbide
Connection End Type
1 1/4 in. - 7 in.
Drill Bit Type
Coring Bit
Drill Bit Type(s) Included
Coring Bit
Individual/Set
Individual
Material Application
Brick,Concrete
Returnable
90-Day
Self-Feeding
No
Shank Style
SDS Plus
Shank Style
SDS Plus
Tools Product Type
Power Tool

More Products With These Features

Search

Customer Questions & Answers

  • bvseo_sdk, java_sdk, bvseo-3.1.1
  • CLOUD, getContent, 144ms
  • QUESTIONS, PRODUCT
  • bvseo-msg: The resource to the URL or file is currently unavailable.;

Customer Reviews

2 in. x 2-13/16 in. Thin Wall SDS-Plus Core Bit is rated 5.0 out of 5 by 2.
Rated 5 out of 5 by from Through Concrete floor Great Product,I only buy Milwaukee when possible. HOME DEPOT website site works great and ships fast. Unfortunately they did not sell the shaft made by Milwaukee only the hilti version. I purchased the shaft off Amazon. HOME DEPOT should sell ALL Milwaukee tools.
Date published: 2016-11-08
Rated 5 out of 5 by from drill bit great!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!
Date published: 2015-09-08
