0046878554610

Orbit

Model # 55461

Internet # 202257142

Store SKU # 840958

Voyager Gear Drive (2-Pack)

$18.97 /each

FREQUENTLY BOUGHT TOGETHER

PRODUCT OVERVIEW

Model # 55461

Internet # 202257142

Store SKU # 840958

Ideal for medium to large lawn areas, the Voyager Gear-Drive Sprinkler Heads (2-Pack) help ensure uniform watering for a lush, green lawn. These 4 in. pop-up sprinkler heads can be adjusted with a screwdriver and provide water coverage from a 20 ft. up to a 40 ft. radius in a part- to full-circle spray pattern.

  • 3/4 in. female threaded inlet
  • No special key needed for adjustments, only a flat-head screwdriver
  • Covers areas from a 20 ft. up to a 40 ft. radius in a part to full-circle spray pattern
  • For use on medium to large lawn areas
  • Gear-drive rotor helps ensure even and complete water coverage
  • 4 in. pop-up sprinkler head
  • Pack of 2
  • For outdoor use and cold water only
  • For irrigation applications only

SPECIFICATIONS

Dimensions
Assembled Depth (in.)
2.75 in
Assembled Height (in.)
7.25 in
Assembled Width (in.)
5.5 in
Product Diameter (in.)
2 in
Details
Color Family
Blacks
Irrigated
Yes
Irrigation System Component
Sprinkler
Maximum Coverage Area (sq ft.)
6362
Maximum Spray Distance (ft.)
45
Pressure Rating
120
Returnable
90-Day
Riser Required
Yes
Sprinkler Location
Below ground
Sprinkler Type
Pop-Up
Warranty / Certifications
Manufacturer Warranty
6 years

MORE PRODUCTS WITH THESE FEATURES

Sprinkler Type: Pop-Up
Sprinkler Location: Below ground
Price: $10 - $20
Brand: Orbit
Review Rating: 4 & Up
Search
6 Questions14 Answers

Customer Questions & Answers

Voyager Gear Drive (2-Pack)
Voyager Gear Drive (2-Pack)

Ask your questions. Share your answers.



Clear Search Term


Sort By:
This question is from Voyager Gear Drive (2-Pack)

5 answers

how to adjust rotation

This question is from Voyager Gear Drive (2-Pack)
Asked by
dja
April 28, 2012
0points
0out of 0found this question helpful.
Was this helpful?helpful0unhelpful0

Answers (5)

Asked by
VA
Read all my Q&A
Home Improvement Profile: DIYer
September 4, 2014
Answer:
I used a screwdriver to change the sprinkler spray radius in the small slit a the top of the head.
+2points
2out of 2found this answer helpful.
Was this helpful?helpful2unhelpful0

Asked by
Wilmington, NC
Read all my Q&A
July 16, 2014
Answer:
Twist Rotating Gear Head all the way to the right. That specific location is adjusted by a slight rotation with the entire body as screwed on to the water source. Once set,, rotate the head to the left and that location, amount or turn, is adjusted with the flat screw driver on the Voyager. The Nozzle is also adjusted to provide the amount of spray desired.
-1point
0out of 1found this answer helpful.
Was this helpful?helpful0unhelpful1

Asked by
sparky1
Read all my Q&A
May 27, 2014
Answer:
Read the instructions. Turn the GREEN colored head all the way counter-clockwise then full clockwise. This is the starting point for the rotation counter-clockwise (to the left). Adjust the (-) or (+) screw to make the arc less (-) or more (+), as needed.
+2points
2out of 2found this answer helpful.
Was this helpful?helpful2unhelpful0

Asked by
Waxahachie, TX, USA
Read all my Q&A
April 30, 2014
Answer:
There is an adjustment key that came with your head. Incert in top of head key hole when system is on turn all the way right then left to clear then bring back to your range desired
-1point
1out of 3found this answer helpful.
Was this helpful?helpful1unhelpful2

Asked by
HD 116
www.community.homedepot.com
May 1, 2012
Answer:
Greetings,
My name is Tom, also known as HD116 at Home Depot's How to Community. I am here today answering a few product questions and saw yours.
The adjustments do not require any special tools only a flat head screwdriver. Here is what the manual says;
The Voyager can be set to rotate
between 40° and 360° (preset at
180°)
1. Turn the top of the head all the
way to the left until it stops and
then
Read More
Greetings,
My name is Tom, also known as HD116 at Home Depot's How to Community. I am here today answering a few product questions and saw yours.
The adjustments do not require any special tools only a flat head screwdriver. Here is what the manual says;
The Voyager can be set to rotate
between 40° and 360° (preset at
180°)
1. Turn the top of the head all the
way to the left until it stops and
then all the way to the right.
This is the starting point for the
rotation (Figure 1).
2. Insert a flat bladed screwdriver
into the pattern adjustment
screw (Figure 2).
3. Turn clockwise to increase
rotation; counterclockwise
to decrease rotation. Each
full turn increases/decreases
rotation by 90˚.
Thank you for your question, and I hope that helps. Read Less
+5points
7out of 9found this answer helpful.
Was this helpful?helpful7unhelpful2
This question is from Voyager Gear Drive (2-Pack)

4 answers

how do you reset sprinkler to factory specs after not proprly installing the first time

This question is from Voyager Gear Drive (2-Pack)
Asked by
RayBray
Fayetteville NC
May 11, 2013
0points
0out of 0found this question helpful.
Was this helpful?helpful0unhelpful0

Answers (4)

Asked by
Pensacola, Florida
Read all my Q&A
November 11, 2014
Answer:
Easy fix, flat head screwdriver to plus or minus slot on splinkler head...........three seconds and it's a done deal
0points
0out of 0found this answer helpful.
Was this helpful?helpful0unhelpful0

Asked by
Waxahachie, TX, USA
Read all my Q&A
April 30, 2014
Answer:
Remove battery and disconnect power from outlet
Ten seconds
Then reset date time and program zones
-1point
0out of 1found this answer helpful.
Was this helpful?helpful0unhelpful1

May 13, 2013
Answer:
Hi Ray. Please follow the link I uploaded that shows how to adjust the Voyager II. Thanks for the question.
User submitted video
0points
1out of 2found this answer helpful.
Was this helpful?helpful1unhelpful1

May 13, 2013
Answer:
Hi Ray. Please follow the link I uploaded to a short movie about how to adjust the Voyager II. Thanks for the question.
User submitted video
-1point
1out of 3found this answer helpful.
Was this helpful?helpful1unhelpful2
This question is from Voyager Gear Drive (2-Pack)

2 answers

What is the max flow rate in GPM and at what pressure in PSI

This question is from Voyager Gear Drive (2-Pack)
March 9, 2016
0points
0out of 0found this question helpful.
Was this helpful?helpful0unhelpful0

Answers (2)

March 10, 2016
Answer:
The PSI is 120.
-3points
0out of 3found this answer helpful.
Was this helpful?helpful0unhelpful3

March 10, 2016
Answer:
Sprinkelerquestionguy, the second half of your question is a bit difficult to determine exactly what you are asking (and how to answer it), but the Voyager II has a max flow rate of 4.0 GPM. As for water pressure, and how that plays into everything, please contact us directly. We'd prefer to hear more from you about your question, so we don't misunderstand you and leave an accidentally-misleading answer Read More
Sprinkelerquestionguy, the second half of your question is a bit difficult to determine exactly what you are asking (and how to answer it), but the Voyager II has a max flow rate of 4.0 GPM. As for water pressure, and how that plays into everything, please contact us directly. We'd prefer to hear more from you about your question, so we don't misunderstand you and leave an accidentally-misleading answer here. Please contact our Support team at 1-800-488-6156 for more information. Thanks! Read Less
+2points
2out of 2found this answer helpful.
Was this helpful?helpful2unhelpful0
This question is from Voyager Gear Drive (2-Pack)

1 answer

Do you offer a 1/2 inch femal connection or only the 3/4 inch?

This question is from Voyager Gear Drive (2-Pack)
Asked by
Read all my Q&A
April 6, 2016
If not, is there an adaptor to connect to a 1/2 inch line?
0points
0out of 0found this question helpful.
Was this helpful?helpful0unhelpful0

Answer (1)

April 7, 2016
Answer:
GM, the Voyager only has the 3/4" connection, but there are adapters that make the 1/2"-to-3/4" connection viable. Which adapter you use, however, will depend on the type of 1/2" pipe that your system uses. Please contact our Support team at 1-800-488-6156, and we'd be more than happy to walk you through the process and make sure you know which product(s) would be the best fit for your irrigation system. Read More
GM, the Voyager only has the 3/4" connection, but there are adapters that make the 1/2"-to-3/4" connection viable. Which adapter you use, however, will depend on the type of 1/2" pipe that your system uses. Please contact our Support team at 1-800-488-6156, and we'd be more than happy to walk you through the process and make sure you know which product(s) would be the best fit for your irrigation system. Thanks! Read Less
+1point
1out of 1found this answer helpful.
Was this helpful?helpful1unhelpful0
2 »
  • 2016-06-25 T15:37:29.575-05:00
  • bvseo_lps, prod_bvqa, vn_prr_5.6
  • cp-1, bvpage1
  • co_hasquestionsanswers
  • loc_en_US, sid_202257142, prod, sort_default
2 »
  • bvseo_sdk, java_sdk, bvseo-3.1.1
  • CLOUD, getContent, 1038ms
  • QUESTIONS, PRODUCT

CUSTOMER REVIEWS

Rated 4.4 out of 5 by 35 reviewers.
Rated 5.0 out of 5.0 by Great rotary new or replacmenet This rotary head was easy to attach to another brand base. I replaced another brand with this one - and didn't even have to disconnect the old unit. No special tool needed to adjust the Orbit Voyager, just a small flat head screwdriver. I even used (not that I recommend it) my pocket knife once when I was too lazy to go get a screwdriver. I purchased this unit to directly replace another brand; based on price and ease of install. Happy with this unit; easy to adjust/install and works very well. June 21, 2016
Rated 5.0 out of 5.0 by great reliable procuct the sprinklers were easy to onstall and the adjustment instructions were easy to follow. June 14, 2016
Rated 2.0 out of 5.0 by Doesn't cover entire area properly It's a decent sprinkler but it doesn't cover much of the inside of the spray. It does wet it some but not for a proper watering. May 31, 2016
Rated 5.0 out of 5.0 by Value Orbit sprinkler heads are a good brand to begin with, the onsale price of the two pack fits every definition of the word bargain. Nice! June 12, 2016
Rated 5.0 out of 5.0 by Better design and setup than other sprinkler heads that I have purchased The design allows you to easily set and adjust the water spray. Seems to be a better sprinkler head than many others that I have purchased. October 6, 2015
Rated 4.0 out of 5.0 by Great product for the price, works great! The sprinklers was perfect for installing sprinklers as well as for replacing old sprinkler heads. October 6, 2015
Rated 5.0 out of 5.0 by Works great! I installed it myself by unscrewing the old one (without digging a whole around it) and replacing it with the new one. Took me 5 min the most. It was also easy to set the coverage range by following simple instructions. No additional tools were needed. I'm so happy that I did not have to call my sprinkling service as they charge $25 per head install. It's a definitely DIY project. September 1, 2015
Rated 5.0 out of 5.0 by sprinkler part Great item and work so well Replaced several heads with this one and I am very happy with them September 1, 2015
