Model # QT504-441-5

Internet #203624274

Q-SEE Premium Series 4 CH 500GB Hard Drive D1 Surveillance System with Four 600 TVL Cameras-DISCONTINUED
0645439235151

Discontinued Q-SEE

Premium Series 4 CH 500GB Hard Drive D1 Surveillance System with Four 600 TVL Cameras-DISCONTINUED

Frequently Bought Together

Product Overview

What can you see about 120 ft. away in the dark - Probably not much. Let the four included security cameras in this bundle do the work by capturing detailed activity with a broadcast quality D1 view. The cameras are equipped with an infrared cut sensor, 600 TV lines of resolution, 42 infrared LEDs and a 120 ft. night vision range. With the included 500GB hard drive, you can save numerous hours of video, and the industry-standard H.264 video compression allows for maximum recording time while minimizing file size. Video is captured in real-time, broadcast-quality D1 704x480 pixel resolution at a rate of 30 frames per second (per camera), which results in smooth, continuous video motion and a larger D1 video image for improved recognition of people and objects. Do you want the DVR to record 24/7? No problem. Set it to record on any day or hour, or set it up to record during motion detection only. The QT504-441-5 DVR+Camera bundle puts you in control of your security. If you're committed to protecting your premises, you'll appreciate the mobile surveillance features that allow you to view live footage via the Internet or a Smartphone. The only thing you may have to ponder is which Internet Browser you'll use. The QT504 is compatible with Internet Explorer 7-9, Safari 5.0, Mozilla Firefox and Google Chrome, Windows Mobile Pro, Symbian OS, iPhone, iPad, Android, and Blackberry. Also this DVR can send you email alerts when motion is detected to give you piece of mind.

  • Remote surveillance - remote monitoring from macintosh or PC computers connected to the internet, free "Q-See QT view" app for iPhone and "Q-See QT view HD" for iPad available from Apple's AppStore, free "Q-See QT View" for Android phones and "Q-See QT View HD" for Android tablets available from Android market, free "SuperCam" app for Windows Phone 7 in the Windows phone marketplace or available as a free download for Windows Mobile Pro, free "SuperCam" apps available for BlackBerry and Symbian devices
  • Operating systems - Windows XP, Windows Vista, Windows 7, and MAC OS 10.6 and 10.7
  • Internet browsers - Internet Explorer (IE), Google Chrome or Mozilla Firefox with IE Plug-in, Safari
  • H.264 Compression - superior H.264 video compression minimizes file size in order to maximize the recording time without affecting the image quality, this allows you to efficiently store and transfer high quality video using less space on your hard drive
  • 500GB Hard drive size - record and store video footage on the pre-installed 500GB AV rated SATA hard drive, this system can support a hard drive up to 2 terabytes
  • Remote monitoring - remotely monitor and manage your home or office 24/7 via the internet using a Windows PC, MAC OS, or a supported 3G/4G Smartphone, including iPhone/iPad, Android, Blackberry, and Windows Phone (10 users at the same time), enjoy additional peace of mind by receiving instant email alerts to three different email addresses with snapshot images when motion is detected, when the hard drive is full, or when and if video loss has occurred
  • Recording resolution / frames per second video is captured in real-time, broadcast-quality D1 on each channel -704x480 pixel resolution at a rate of 30 frames per second per camera), which results in smooth, continuous video motion and a larger D1 video image for improved viewing quality
  • Four recording modes - select from 4 different recording modes: advanced motion detection, alarm sensor trigger, and manually
  • Three viewing modes: single cam, multi-cam and timed auto sequence
  • Multi-tasking functionality - the multi-tasking feature allows up to five functions to occur on the system at one time: record video, watch live video or playback video, while also monitoring and managing the system remotely, and backing up files
  • Three search options - quickly find previously recorded video by searching in one of three ways: time, motion detection event, and alarm triggered event
  • Convenient backup- backup video files from the surveillance system to a PC, flash drive or USB hard drive in order to free-up space for new video while retaining important footage
  • Connects to a monitor/TV - connect to a TV or to a 19 in. or larger VGA monitor
  • Universal Plug 'n Play (UPnP): Instantly connect your DVR to your net work and the Internet via your UPnP-enabled router for ready-to-go remote monitoring without the need for software or time-consuming configuration routines
  • Cameras: 600 TV line high-resolution, 1/3 in. enhanced infrared cut sensors: allows for a higher quality picture, accurate colors, and better image quality than most standard surveillance cameras. lens: 5.0mm lens providing a 50-55 degree radius field of view
  • Night vision - up to 120 ft. in the dark with 42 infrared LED (night vision appears in B and W, day viewing in color)
  • Cables: 60 ft. cable included with each camera (extensions available if needed)
  • Theft-deterrent mounting brackets: flexible 3-axis brackets allow for more precise positioning of the cameras, while guiding the cables directly through the camera brackets to reduce the threat of vandalism to the cameras

Info & Guides

You will need Adobe® Acrobat® Reader to view PDF documents.  Download a free copy from the Adobe Web site.

Specifications

Dimensions

Details

More Products With These Features

Search

Customer Questions & Answers

1 Question1 Answer

Customer Questions & Answers

Premium Series 4 CH 500GB Hard Drive D1 Surveillance System with Four 600 TVL Cameras-DISCONTINUED
Premium Series 4 CH 500GB Hard Drive D1 Surveillance System with Four 600 TVL Cameras-DISCONTINUED

Ask your questions. Share your answers.



Clear Search Term



1 answer

specs

This question is from Premium Series 4 CH 500GB Hard Drive D1 Surveillance System with Four 600 TVL Cameras-DISCONTINUED
Asked by
Anthony
salem nh
October 20, 2012
What is included in this package as far as cables? Connections? Can I back up stored video to a USB thumb drive? Can I set cameras to record non stop from a certain time and then switch to motion activated? For example, can I set them to record from 5am to 9pm non stop, and then set them for motion activated from 9pm to 5am every day?
0points
0out of 0found this question helpful.
Was this helpful?helpful0unhelpful0

Answer (1)

Asked by
Anaheim, CA
Read all my Q&A
October 22, 2012
Answer:
Hi Anthony,
I have included a file that includes everything that is included in the box**. Also you can back up your footage onto a USB flash drive. The cameras can be set up to record continuously at a certain time and then set to record on motion on a schedule as well.
**4 Channel DVR with pre-installed 500GB Hard drive
12v DVR power supply and cord
USB mouse
Remote control for DVR
BCA to RCA
Read More
Hi Anthony,
I have included a file that includes everything that is included in the box**. Also you can back up your footage onto a USB flash drive. The cameras can be set up to record continuously at a certain time and then set to record on motion on a schedule as well.
**4 Channel DVR with pre-installed 500GB Hard drive
12v DVR power supply and cord
USB mouse
Remote control for DVR
BCA to RCA Adapter
RJ45 Ethernet cable
BNC to RCA video Cable
Manual and Software CD-ROM
Setup and Remote Monitoring quick start guides and posters
Window labels
4 - Weatherproof cameras with 3-Axis mounts
Camera manual
Camera power supply
4-Way power splitter
Mounting screws
4- 60ft power and video cables
Read Less
