Model # KERDI200/5M

Internet #202608388

Store SKU #571918

Store SO SKU #1000894570

Schluter Kerdi 3 ft. 3 in. x 16 ft. 5 in. Waterproofing Membrane


Kerdi 3 ft. 3 in. x 16 ft. 5 in. Waterproofing Membrane

  • Easy to install
  • Eliminates water damage
  • For use on tiled showers
$9997 /roll
store icon Loading Buying Options...
package icon Loading Buying Options...
Sorry, but we ran into issues loading these options. Please try refreshing.

Frequently Bought Together

Product Overview

Kerdi is a sheet-applied polyethylene waterproofing membrane and vapor retarder. Kerdi200/5M covers 54 sq. ft. and is ideal for waterproofing tiled tub surrounds and showers. This membrane features an anchoring fleece on both sides to anchor it in thin-set mortar. Kerdi eliminates water damage which can lead to mold and mildew.

  • Roll dimensions are 3 ft. 3 in. x 16 ft. 5 in.
  • For commercial and residential use
  • Installs easily with unmodified thin-set mortar (sold separately)
  • Waterproofing for tiled shower walls and floors
  • Covers 54 sq. ft.

Info & Guides

You will need Adobe® Acrobat® Reader to view PDF documents.  Download a free copy from the Adobe Web site.



Product Width (in.)


Color Family
Commercial / Residential
Commercial / Residential
Flooring Material Features
Waterproofing membrane
Flooring Product Type
Product Weight (lb.)

Warranty / Certifications

Manufacturer Warranty
10 Year Limited Warranty

More Products With These Features


Customer Questions & Answers

Can I use this over greenboard drywall before I tile it?

Will it support the weight of tile? Would cement board be a better choice?
Asked by: Shocky
Can be used over any drywall or concrete backer.
Answered by: mikem0452
Date published: 2017-05-16

this can be use in the floor for waterproofing

putting this product first then a little concret on top then the tile
Asked by: ed
Yes it can but most contractors would use ditra, which still requires kerdi band on the seams to make the floor waterproof.
Answered by: mikem0452
Date published: 2016-07-16

what thin set do you use with it when you put it on walls

Asked by: teeny
Answered by: remodeler
Date published: 2017-06-15

can kerdi be used in a steam shower including ceiling can it hold a16 by 32 inch tile on the ceiling using only un modified thin set

Asked by: patches
IMHO it can be used in a residential steam shower. However if the steam shower is going to be getting commercial use then I would use the thicker 20mm kerdi. Puttting tile on a ceiling is always challenging and the bigger the tile the bigger the challenge. Adhesion or suction from the wet thinset will not be able to hold tile any bigger than 6 x 6 maybe 12 x 12 with some temporary clamping. We us clamps used to hold wall cabinets and crown molding to initially hold the tile while the thinset sets up some. Otherwise the tile will rain down on you when you are not looking.
Answered by: mikem0452
Date published: 2016-10-12
  • y_2017, m_7, d_25, h_10CST
  • bvseo_bulk, prod_bvqa, vn_bulk_1.0.0-hotfix-1
  • cp_1, bvpage1
  • co_hasquestionsanswers, tq_17
  • loc_, sid_202608388, prod, sort_[SortEntry(order=NUM_ANSWERS, direction=DESCENDING), SortEntry(order=SUBMISSION_TIME, direction=DESCENDING), SortEntry(order=LAST_APPROVED_ANSWER_SUBMISSION_TIME, direction=DESCENDING), SortEntry(order=LAST_APPROVED_ANSWER_SUBMISSION_TIME, direction=DESCENDING), SortEntry(order=BEST_ANSWER_FEEDBACK_COUNT, direction=DESCENDING), SortEntry(order=POSITIVE_ANSWER_FEEDBACK_COUNT, direction=DESCENDING), SortEntry(order=NUM_ANSWERS, direction=DESCENDING)]
  • clientName_homedepot
  • bvseo_sdk, java_sdk, bvseo-3.1.1
  • CLOUD, getContent, 159ms

Customer Reviews

Kerdi 3 ft. 3 in. x 16 ft. 5 in. Waterproofing Membrane is rated 3.6 out of 5 by 16.
Rated 1 out of 5 by from Not for the DIY game homeowner. Thin set dried before... Not for the DIY game homeowner. Thin set dried before I could get it on wall. Had it all cut and ready, but to butter an 8 foot wall took longer than I thought. I may have had thin set too dry, was winter and was low humidity and sucked moisture out of thin set. Any air pockets and tiles will float.
Date published: 2017-02-07
Rated 4 out of 5 by from Waterproof Membrane This is a great product to apply over regular sheetrock in a shower. I wont say it was easy to install since we are wanna be remodelers but with some do overs we got it on the wall and cut pieces to fit in the shower window niches. Really terrific!!
Date published: 2017-03-07
Rated 3 out of 5 by from Very easy to use. Instructions are simplt to read... Very easy to use. Instructions are simplt to read and understand. Was glad to see lines on the product for easy tile markings when putting up the tile on material.
Date published: 2017-03-08
Rated 5 out of 5 by from Excellent product easy to install Excellent product easy to install
Date published: 2017-02-28
Rated 4 out of 5 by from Easy to Install It is a little expensive, but it does the job and is easy to install. The only problem I ran into, was that the store did not carry the correct mortar (un-modified) to adhere it to the wall.
Date published: 2016-10-18
Rated 5 out of 5 by from Kerdi shower and tub The Kerdi fabric is easy to install as long as you remember to mix the mortar fairly thin, and use unmodified, and then smooth it out carefully. Don't try to install it around the corners, but use the thinner joint tape instead. I've done four showers for myself and friends and the stuff works great. It is well worth the money - if you don't think so, try repairing the problems with water in your walls! Plus no breathing problems like you can run into with some of the roll on products.
Date published: 2013-11-25
Rated 4 out of 5 by from Good buy, easy install, use as directed and a sure bet for waterproofing. When using this product use the directions and you can't fail. Kerdi will work for you as a complete waterproofing system behind your tiles. Do not worry if you get thin set on the top of the Kerdi. It will have more thinset on it when putting up your tiles. Have some fun !
Date published: 2015-06-10
Rated 4 out of 5 by from The best Costs a lot but works well. Easy to install but a visit to the schluter-kerdi web site for instructions
Date published: 2016-08-24
