Southwire 500 ft. 4/0-4/0-2/0 Black Stranded AL Sweetbriar URD Cable
0032886596445

Southwire

500 ft. 4/0-4/0-2/0 Black Stranded AL Sweetbriar URD Cable

$89775 /each

Product Overview

The Southwire Company 500 ft. 4/0-4/0-2/0 AL URD Service Entry Electrical Cable features aluminum-compressed conductors with a vulcanized interlinked polyethylene insulation. This Cable can be directly buried or placed in a duct. UL listed and RoHS compliant.
store icon Loading Buying Options...
package icon Loading Buying Options...
Sorry, but we ran into issues loading these options. Please try refreshing.

Frequently Bought Together

Product Overview

The Southwire Company 500 ft. 4/0-4/0-2/0 AL URD Service Entry Electrical Cable features aluminum-compressed conductors with a vulcanized interlinked polyethylene insulation. This Cable can be directly buried or placed in a duct. UL listed and RoHS compliant.
  • For secondary distribution, street light applications and underground service at 600-Volt or less
  • Designed for problematic installations due to adjacent utility work, homeowner or voltage surge damage
  • For direct burial or in ducts
  • For outdoor use
  • Can be used in temperatures up to 194˚F
  • 500 ft. of cable
  • Conductors are stranded, compressed aluminum and insulated with a vulcanized interlinked polyethylene insulation
  • Neutral conductor contains 3 yellow extruded stripes and sequential footage markers
  • Triplex construction made of 2 phase conductors and 1 neutral
  • URD has a visco-elastic sealant in the channels between the inner and outer layer
  • Design helps allow for cleaner stripping, more uniform sealant disbursement in the cable and great shrink-back performance
  • Click to learn the factors you must consider when wiring your home

Product Overview

The Southwire Company 500 ft. 4/0-4/0-2/0 AL URD Service Entry Electrical Cable features aluminum-compressed conductors with a vulcanized interlinked polyethylene insulation. This Cable can be directly buried or placed in a duct. UL listed and RoHS compliant.

  • For secondary distribution, street light applications and underground service at 600-Volt or less
  • Designed for problematic installations due to adjacent utility work, homeowner or voltage surge damage
  • For direct burial or in ducts
  • For outdoor use
  • Can be used in temperatures up to 194˚F
  • 500 ft. of cable
  • Conductors are stranded, compressed aluminum and insulated with a vulcanized interlinked polyethylene insulation
  • Neutral conductor contains 3 yellow extruded stripes and sequential footage markers
  • Triplex construction made of 2 phase conductors and 1 neutral
  • URD has a visco-elastic sealant in the channels between the inner and outer layer
  • Design helps allow for cleaner stripping, more uniform sealant disbursement in the cable and great shrink-back performance
  • Click to learn the factors you must consider when wiring your home

Specifications

Dimensions

Product Depth (in.)
34
Product Height (in.)
29.5
Product Length (ft.)
500 ft
Product Width (in.)
34
Wire/Cable Length (ft.)
500

Details

Allowable Ampacities
Not Specified
Cable/Wire Type
URD
Commercial / Residential
Residential
Conductor Gauge
4/0
Conductor Material
Aluminum
Electrical Product Type
Service Entry Electrical Cable
Grounded
No
Indoor/Outdoor
Outdoor
Jacketed
Yes
Number of Conductors
3
Outer Color
Black
Returnable
90-Day
Shielded
No
Stranded or Solid
Stranded
Sunlight / UV Resistant
No
Wet Location Use
Yes
Wire Cut Type
Pre-Cut Length

Warranty / Certifications

Certifications and Listings
1-UL Listed
Manufacturer Warranty
NA

Specifications

Dimensions

Product Depth (in.)
34
Product Height (in.)
29.5
Product Length (ft.)
500 ft
Product Width (in.)
34
Wire/Cable Length (ft.)
500

Details

Allowable Ampacities
Not Specified
Cable/Wire Type
URD
Commercial / Residential
Residential
Conductor Gauge
4/0
Conductor Material
Aluminum
Electrical Product Type
Service Entry Electrical Cable
Grounded
No
Indoor/Outdoor
Outdoor
Jacketed
Yes
Number of Conductors
3
Outer Color
Black
Returnable
90-Day
Shielded
No
Stranded or Solid
Stranded
Sunlight / UV Resistant
No
Wet Location Use
Yes
Wire Cut Type
Pre-Cut Length

Warranty / Certifications

Certifications and Listings
1-UL Listed
Manufacturer Warranty
NA

More Products With These Features

Search

Questions & Answers

Is this available in 1,200 ' rolls ?

Asked by: Conrad
The Home Depot only carries the 500' rolls. However, you can place a special order at Home Depot for the 1000' roll if you need to. Just go to the pro desk and they can assist. Southwire does make a 1000' roll.
Answered by: SouthwireCustomerService
Date published: 2015-12-31

What is the current capacity of that conductor for the 4/0 gauge sections? The table in the descr...

What is the current capacity of that conductor for the 4/0 gauge sections? The table in the descriptions are left empty. Is it equivalent to a 4/0 aluminum solid wire or the diameter of the stranded bundle is the same as that of a solid 4/0 aluminum wire, so the current rating has to be further derated from 4/0 solid aluminum wire?
Asked by: KokoLand
The allowable amps for direct burial is 315 and in ducts is 240 for 4/0-4/0-2/0 stranded AL Sweetbriar URD. The above advice is based upon the current edition of the National Electric Code (NEC). Free access to the latest version of the NEC is available online at www.nfpa.org/freeaccess. The NEC and local building codes regulate the types of wire and cable that can be used in specific electrical applications, as well as the manner of installation. Check your local building codes before you start any wiring and cable electrical project and be sure to obtain required permits. When your work is complete, always have it inspected for compliance with local codes to ensure that it has been safely installed.
Answered by: SouthwireCustomerService
Date published: 2017-07-31

How much does a 500 foot spool weigh?

Asked by: cranky
approximately 354 lbs.
Answered by: SouthwireCustomerService
Date published: 2016-06-01

Voltage loss

How long of a run can you run before there is a voltage loss?
Asked by: rjtemple
Unfortunately we weren't provided enough information to answer your question. Please view our voltage drop calculator @--> http://www.southwire.com/support/voltage-drop-calculator.htm
Answered by: SouthwireCustomerService
Date published: 2016-05-24
