Model # 20492512

Internet #202316573

Store SKU #799645

Southwire 500 ft. 8 Green Stranded CU SIMpull THHN Wire
0032886231407

Southwire

500 ft. 8 Green Stranded CU SIMpull THHN Wire

  • #8 AWG commercial wiring for outlets, switches and other loads
  • 8 Gauge THHN wire contains Copper (CU) Conductors
  • #8 THHN comes stranded with variety of colors and lengths
$15300 /each
store icon Loading Buying Options...
package icon Loading Buying Options...
Sorry, but we ran into issues loading these options. Please try refreshing.

Frequently Bought Together

Product Overview

  • #8 AWG commercial wiring for outlets, switches and other loads
  • 8 Gauge THHN wire contains Copper (CU) Conductors
  • #8 THHN comes stranded with variety of colors and lengths
Southwire Type THHN or THWN-2 conductors are primarily used in conduit and cable trays for services, feeders and branch circuits in commercial or industrial applications as specified in the NEC 2. When used as Type THHN, or T90 Nylon conductor is suitable for use in dry locations at temperatures not to exceed 90˚C. Conductor is suitable for use in wet or dry locations at temperatures not to exceed 90˚C or not to exceed 75˚C when exposed to oil or coolant. UL listed.
  • THHN copper conductors are annealed (soft) copper, rated at 600-Volt and heat, moisture, gasoline and oil resistant
  • THHN cable is insulated with a tough heat and moisture resistant polyvinyl chloride (PVC)
  • THHN is available in a variety of colors, lengths and gauges; also available in solid and stranded copper
  • THHN cable is suitable for use in wet or dry locations at temperatures not to exceed 90˚C
  • Also available in solid and stranded copper
  • Note: product may vary by store
  • Click to learn the factors you must consider when wiring your home

Product Overview

  • #8 AWG commercial wiring for outlets, switches and other loads
  • 8 Gauge THHN wire contains Copper (CU) Conductors
  • #8 THHN comes stranded with variety of colors and lengths
Model #: 20492512
Sku #: 799645
Internet #: 202316573

Southwire Type THHN or THWN-2 conductors are primarily used in conduit and cable trays for services, feeders and branch circuits in commercial or industrial applications as specified in the NEC 2. When used as Type THHN, or T90 Nylon conductor is suitable for use in dry locations at temperatures not to exceed 90˚C. Conductor is suitable for use in wet or dry locations at temperatures not to exceed 90˚C or not to exceed 75˚C when exposed to oil or coolant. UL listed.

  • THHN copper conductors are annealed (soft) copper, rated at 600-Volt and heat, moisture, gasoline and oil resistant
  • THHN cable is insulated with a tough heat and moisture resistant polyvinyl chloride (PVC)
  • THHN is available in a variety of colors, lengths and gauges; also available in solid and stranded copper
  • THHN cable is suitable for use in wet or dry locations at temperatures not to exceed 90˚C
  • Also available in solid and stranded copper
  • Note: product may vary by store
  • Click to learn the factors you must consider when wiring your home

Info & Guides

You will need Adobe® Acrobat® Reader to view PDF documents. Download a free copy from the Adobe Web site.

Specifications

Dimensions

Product Depth (in.)
11.75
Product Height (in.)
6.13
Product Length (ft.)
500 ft
Product Width (in.)
11.75
Wire/Cable Length (ft.)
500

Details

Allowable Ampacities
55
Cable/Wire Type
THHN
Commercial / Residential
Commercial / Residential
Conductor Gauge
8
Conductor Material
Copper
Direct Burial
No
Electrical Product Type
Single Conductor Electrical Wire
Flame Retardant
No
Grounded
No
Indoor/Outdoor
Indoor/Outdoor
Jacketed
Yes
Number of Conductors
1
Outer Color
Green
Returnable
90-Day
Shielded
No
Stranded or Solid
Stranded
Sunlight / UV Resistant
No
Wet Location Use
No
Wire Cut Type
Pre-Cut Length

Warranty / Certifications

Certifications and Listings
1-UL Listed,CSA Listed
Manufacturer Warranty
NA

Specifications

Dimensions

Product Depth (in.)
11.75
Product Height (in.)
6.13
Product Length (ft.)
500 ft
Product Width (in.)
11.75
Wire/Cable Length (ft.)
500

Details

Allowable Ampacities
55
Cable/Wire Type
THHN
Commercial / Residential
Commercial / Residential
Conductor Gauge
8
Conductor Material
Copper
Direct Burial
No
Electrical Product Type
Single Conductor Electrical Wire
Flame Retardant
No
Grounded
No
Indoor/Outdoor
Indoor/Outdoor
Jacketed
Yes
Number of Conductors
1
Outer Color
Green
Returnable
90-Day
Shielded
No
Stranded or Solid
Stranded
Sunlight / UV Resistant
No
Wet Location Use
No
Wire Cut Type
Pre-Cut Length

Warranty / Certifications

Certifications and Listings
1-UL Listed,CSA Listed
Manufacturer Warranty
NA

Questions & Answers

Need 175 ft of green 2G THHN wire. Cannot find on your site. Price?

Asked by: Larry
Thank you for your recent inquiry with The Home Depot, Larry. We do not have the 2 gauge in green in 175 foot lengths of by the foot. We do carry 500 ft. 2 Gauge Stranded Aluminum THHN Wire - Green Internet # 205818580. We appreciate your business and look forward to serving you in the future. Thank you for shopping Home Depot.
Answered by: THDSupport
Date published: 2015-11-11

I need this Solid, not stranded

Asked by: RAL
8 solid THHN is only offered in stranded. 14-Gauge, 10 Gauge, and 12 Gauge are the THHN's which are offered in solid.
Answered by: SouthwireCustomerService
Date published: 2017-04-16
