Wayne 1/2 HP Non-Clogging Vortex, Reinforced Thermoplastic Submersible Utility Pump-VIP50 - The Home Depot
Discontinued

Wayne

Model # VIP50

Internet # 100034817

1/2 HP Non-Clogging Vortex, Reinforced Thermoplastic Submersible Utility Pump


Wayne 1/2 HP Non-Clogging Vortex, Reinforced Thermoplastic Submersible Utility Pump


This item has been discontinued.
The Home Depot no longer carries this specific product.

$84.75 / each
  • Easy to install with good instructions and easy to clean
  • Consumer reviewed as quality and reliable product with no leaks
Loading...

PRODUCT OVERVIEW

Model # VIP50

Internet # 100034817

The WAYNE 1/2 HP Submersible Utility Pump can pump up to 2,500 GPH and features corrosion-resistant, reinforced thermoplastic motor housing, volute and impeller. Its oil-filled, thermally protected motor helps prevent overheating while the 1-1/2 in. NPS discharge connects to flexible sump discharge hose for high-volume water removal.

  • Pumps up to 2500 GPH 0 ft.
  • Bottom suction design filters debris and removes water down to 1/4 in. of surface
  • Non-clogging vortex design passes upto 1/2 in. solids
  • 1-1/4 in. NPS high volume discharge with 3/4 in. garden hose adapter included
  • Easy-access handle for portability
  • Corrosion-resistant reinforced thermoplastic housing, volute and impeller
  • High performance 1/2 HP motor
  • UL listed

Info & Guides

You will need Adobe® Acrobat® Reader to view PDF documents. Download a free copy from the Adobe Web site.

SPECIFICATIONS

Dimensions
Assembled Depth (in.)  6.8 in  Assembled Height (in.)  11 in
Assembled Width (in.)  6.8 in  Maximum Pumping Height (ft.)  20
Product Depth (in.)  7.7  Product Height (in.)  11.4
Product Width (in.)  7.3 in
Details
Adjustable Speed  No  Amperage (amps)  9.5
Cord Length (ft.)  Corrosion Resistant  Yes
Discharge Flow @ 0 ft. (gallons/hour)  2500  Discharge Flow @ 10 ft. (gallons/hour)  1550
Float Switch  No  Hardware Included  No
Head Pressure (ft.)  21  Horsepower (hp)  1/2 hp
Housing Material  Thermoplastic  Inlet Connection  Plain end
Maximum Discharge Flow (gallons/hour)  2500  Maximum Working Temperature (F)  120
Minimum working temperature (F)  40  Outlet Connection  Threaded female
Pool Cover Pump  No  Power Type  Electric
Power Type Required  AC  Product Weight (lb.)  6.8 lb
Pump Switch Type  Switchless  Returnable  90-Day
Run-Dry Capable  No  Self-Priming  Yes
Submersible  Yes  Voltage (volts)  115
Waterfall Pump  No
Warranty / Certifications
Certifications and Listings  1-UL Listed,CSA Listed,SSPMA Certified  Manufacturer Warranty  1 Year Limited Warranty

CUSTOMER REVIEWS

Rated 4.3 out of 5 by 111 reviewers.
Rated 5 out of 5 by Great efficient pump I needed a pump to remove water from my swimming pool. In one day, I was able to pump 6,000 gallons of water out of the pool (I measured this with my water meter when I refilled the pool). May 28, 2014
Rated 5 out of 5 by Even a Caveman Can Use It needed a pump to for my hydroponic vertical strawberries , smaller pumps did not have the power to pump a half inch pipe 7ft straight up but this one had more than enough , with a 24hr timer set the only thing i have to worry about is forgetting to check my PH and TDS levels its so easy even a caveman can use it April 22, 2014
Rated 5 out of 5 by Simple and Fast I needed a pump to empty my hot tub and picked this one after a lot of web research. Have only used it once, but it worked great, drained 350 gallons in an hour with about a 3 ft. rise using the garden hose reducer on the outlet. The power cord is plenty long enough, and the unit is nicely weighted to stay put. Instructions were simple, hookup and operation were easy. The only "con" I have is that the instructions say it will pump down to 1/4 of an inch, but it needs 2 5/8 inches of water to operate, so keep an eye on the water level to avoid over heating the pump. Hoping to use this 3-4 times a year, time will tell how durable this unit is. April 22, 2014
Rated 5 out of 5 by it does exactly what itis designed to do and at a gret price. This pump was easy to install. I did have to get an adapter to go from hose fitting to 3/4 inch PVC slip fit for my application, but that is to be expected, and it was just a couple of dollars at home depot. I use mine for hydroponic gardening out doors for vegetables. It runs 15 stacks of pots. I use the EZ GRO system of Hydroponic gardening and I highly recommend this pump. the pump has to pump the water and nutrients up about 10 feet because my nutrient barrel is sunk into the ground to keep it cooler here in the Carolina heat. Then it has to supply 4 different 1/2" legs each 15 feet long (think of it as a manifold ) and then each leg has 8 to 10 1/4 inch drip hoses coming off of them so up 10 feet over 30 feet then out two more two foot by 1/4 inch lines. it's a heck of a pump. August 14, 2012
Rated 5 out of 5 by Submersible Utility Pump a Good Value This submersible pump did the job. It moved the water quickly and the price was reasonable. If you need a pump for the occasional requirement to drain small pools, hot tubs, etc., this will work for you. December 25, 2014
