Wayne

Model # VIP50

Internet # 100034817

1/2 HP Non-Clogging Vortex, Reinforced Thermoplastic Submersible Utility Pump

$77.99 /each
  • Pumps up to 2500 GPH at 0 ft.
  • Corrosion resistant, thermoplastic construction
  • Bottom suction design filters debris

Frequently Bought Together

Product Overview

The Wayne 1/2 HP submersible water pump can handle up to 1/2 in. solids without getting clogged. It can pump up to 2500 Gal. per hour and is designed with bottom suction that removes water down to 1/8 in. of the surface. Thermoplastic housing, volute, and impeller are corrosion resistant. Designed with 1- 1/4 in. discharge for high volume water removal or 3/4 in. garden hose adapter for smaller jobs.

  • Pumps dirty water with small (1/2 in.) solids
  • Removes water down to 1/8 in. of surface
  • Corrosion resistant, sealed thermoplastic construction
  • Fully submersible
  • 1/2 HP; max. flow rate is 2500 GPH; 1550 GPH at 10 ft. of discharge lift
  • For removing water from flooded basements, boats, low-lying outdoor collection spots
  • 1-1/4 in. discharge with 3/4 in. garden hose adapter
  • Additional Features:


Info & Guides

You will need Adobe® Acrobat® Reader to view PDF documents.  Download a free copy from the Adobe Web site.

Specifications

Dimensions

Maximum Pumping Height (ft.)
20
Product Depth (in.)
7.7
Product Height (in.)
11.4
Product Width (in.)
7.3 in

Details

Adjustable Speed
No
Amperage (amps)
9.5
Cord Length (ft.)
Corrosion Resistant
Yes
Discharge Flow @ 0 ft. (gallons/hour)
2500
Discharge Flow @ 10 ft. (gallons/hour)
1550
Float Switch
No
Hardware Included
No
Head Pressure (ft.)
21
Horsepower (hp)
1/2 hp
Housing Material
Thermoplastic
Inlet Connection
Plain end
Maximum Discharge Flow (gallons/hour)
2500
Maximum Working Temperature (F)
120
Minimum working temperature (F)
40
Outlet Connection
Threaded female
Pool Cover Pump
No
Power Type Required
AC
Product Weight (lb.)
6.8 lb
Pump Switch Type
Switchless
Returnable
90-Day
Run-Dry Capable
No
Self-Priming
Yes
Submersible
Yes
Voltage (volts)
115
Waterfall Pump
No

Warranty / Certifications

Certifications and Listings
1-UL Listed,CSA Listed,SSPMA Certified
Manufacturer Warranty
1 Year Limited Warranty

More Products With These Features

Search

Customer Questions & Answers

22 Questions17 Answers

Customer Questions & Answers

1/2 HP Non-Clogging Vortex, Reinforced Thermoplastic Submersible Utility Pump
1/2 HP Non-Clogging Vortex, Reinforced Thermoplastic Submersible Utility Pump

Ask your questions. Share your answers.



Clear Search Term


Sort By:

2 answers

Can this be use to empty swimming pool?

This question is from 1/2 HP Non-Clogging Vortex, Reinforced Thermoplastic Submersible Utility Pump
Asked by
Concord CA
Read all my Q&A
March 18, 2016
0points
0out of 0found this question helpful.
Was this helpful?helpful0unhelpful0

Answers (2)

Asked by
Read all my Q&A
May 27, 2016
Answer:
That should work. Might want to keep the plug connection above water.
0points
0out of 0found this answer helpful.
Was this helpful?helpful0unhelpful0

March 19, 2016
Answer:
No, this device is used for removing water from flooded basements, boats, and low-lying outdoor collection spots.
-2points
0out of 2found this answer helpful.
Was this helpful?helpful0unhelpful2

2 answers

Where do you purchase 3/4 in. garden hose adapter

This question is from 1/2 HP Non-Clogging Vortex, Reinforced Thermoplastic Submersible Utility Pump
Asked by
NORCO,CA
Read all my Q&A
October 24, 2015
Where do you purchase 3/4 in. garden hose adapter if you want to use a water hose? If you do not use a water hose what do you buy instead? I have about 15 to 25 feet that the water will need to be pumped to
0points
0out of 0found this question helpful.
Was this helpful?helpful0unhelpful0

Answers (2)

Asked by
Hattiesburg, MS, USA
Read all my Q&A
December 23, 2015
Answer:
This pump has the adaptor with it.
+3points
3out of 3found this answer helpful.
Was this helpful?helpful3unhelpful0

Asked by
Texas
Read all my Q&A
Home Improvement Profile: DIYer
October 25, 2015
Answer:
The adapter comes with it, you just unscrew the existing outlet and flip it around, then screw it back on.
+4points
4out of 4found this answer helpful.
Was this helpful?helpful4unhelpful0

1 answer

What minimum depth of standing water will this pump?

This question is from 1/2 HP Non-Clogging Vortex, Reinforced Thermoplastic Submersible Utility Pump
Asked by
Illinois
Read all my Q&A
July 13, 2016
Product description page here says (boldly emphasized, even) that it can pump down to 1/8" ("nearly dry!"), manufacturer's page says 3/8", one reviewer here (recent) said it would pump down to only 2.5 inches.

I want to use this for pumping water out of basement when it floods, which is the correct answer?
0points
0out of 0found this question helpful.
Was this helpful?helpful0unhelpful0

Answer (1)

July 14, 2016
Answer:
The minimum depth is 3/8''.
0points
0out of 0found this answer helpful.
Was this helpful?helpful0unhelpful0

1 answer

Can this pump be used for 1000 gallon pond continuasly?

This question is from 1/2 HP Non-Clogging Vortex, Reinforced Thermoplastic Submersible Utility Pump
Asked by
richmond, va
Read all my Q&A
July 12, 2016
0points
0out of 0found this question helpful.
Was this helpful?helpful0unhelpful0

Answer (1)

July 12, 2016
Answer:
This item can pump up to 2500 gallons.
-2points
0out of 2found this answer helpful.
Was this helpful?helpful0unhelpful2
2 »
  • 2016-07-25 T21:34:07.148-05:00
  • bvseo_lps, prod_bvqa, vn_prr_5.6
  • cp-1, bvpage1
  • co_hasquestionsanswers
  • loc_en_US, sid_100034817, prod, sort_default
2 »
  • bvseo_sdk, java_sdk, bvseo-3.1.1
  • CLOUD, getContent, 121ms
  • QUESTIONS, PRODUCT

Customer Reviews

Rated 4.3 out of 5 by 145 reviewers.
Rated 5.0 out of 5.0 by 1/2 HP Non-Clogging Vortex Utility pump Shipping was fast-easy to set up and works great-price was also great (compared to ones i price checked) Glad i made the purchase--dont need all the time, was the first time i needed one-due to hot water heater going to heck--but all is good now. Great Investment July 12, 2016
Rated 5.0 out of 5.0 by Work horse Works perfect for what I wanted. Good purchase. Submerge in pool to remove excess rain water. And good for removing water from sump if sump motor fails in heavy rain. Good all around pump to have around. July 7, 2016
Rated 5.0 out of 5.0 by Great pump I use this pump to pump water from a creek to 275 gallon water storage tanks for our half acre garden. I bought adapters to attach my 1 inch hard plastic water line to the pump at a local hardware store. Easy. The water is pumped up about 15 feet in elevation over a distance of 100 feet. I can fill a 275 tank in under 30 minutes, about 10 gallons per minute, much faster than the older less powerful pump I used. The pump has been in regular use since April and has performed flawlessly. June 24, 2016
Rated 3.0 out of 5.0 by Almost worked. It almost did what I was looking for.They failed to say that it was only good to 2.5 inchs of water. Was using it to empty a above ground pool June 24, 2016
Rated 5.0 out of 5.0 by Great pump for the money. The pump arrived on time. I plugged it in and put it to work. It finished draining my pool cover very efficiently. Because it is not specifically a pool cover pump it had to lay on its side, otherwise it was strong enough to suck the pool cover to the base of the pump. i would have liked it to have an auto shut off feature, but other than that it is great. June 14, 2016
Rated 4.0 out of 5.0 by Used to drain a pool It worked fine but I did need to filter water through a pool net for the last inch. June 24, 2016
Rated 5.0 out of 5.0 by Works like a champ I bought this pump do lower the level of my pool. Attach the hose, drop it in the water, plug it in. Easy as pie. Perfect for my need; great value. May 3, 2016
Rated 5.0 out of 5.0 by Great Submersible Pump! Bought this unit for draining church baptistry and it works great! Unit is very quiet and VERY fast - entire baptistry (around 150 gallons) is drained in less than 15 minutes, almost to the very bottom of the tank. Also a big plus that the adapter, which comes with the pump, connects to standard garden hose. Some time of cord would be better to lower & raise the pump, but for now the power cord suffices. Very pleased with this unit. April 5, 2016
