Wayne 1 HP Shallow Well Jet Pump-SWS100 - The Home Depot


Model # SWS100

Internet # 203668878

1 HP Shallow Well Jet Pump

Wayne 1 HP Shallow Well Jet Pump

This item has been discontinued.
The Home Depot no longer carries this specific product.

$279.00 / each


Model # SWS100

Internet # 203668878

WAYNE pumps are durable, reliable, and worry-free. The WAYNE SWS100 is a 1 HP durable, cast iron shallow well jet pump packaged with a comprehensive installation manual to help anyone build a safe and long-lasting well pump system. The SWS100 has a dedicated priming port for volute filling. This product comes with a 3 year limited warranty.

  • Model SWS100 pumps up to 558 GPH at 5 ft. depth - (50 PSI)
  • Dual voltage (120/240) high efficiency square flange motor (factory wired for 120 volts)
  • Pressure switch is pre-set at 30-50 PSI for automatic operation
  • 3/4 in. NPT discharge with 1-1/4 in. suction durable cast iron volute
  • For wells 0 ft. - 25 ft. in depth

Info & Guides

You will need Adobe® Acrobat® Reader to view PDF documents. Download a free copy from the Adobe Web site.


Assembled Depth (in.)  22.3 in  Assembled Height (in.)  10.3 in
Assembled Width (in.)  11.5 in  Product Depth (in.)  22.3
Product Height (in.)  10.3  Product Width (in.)  11.5
Adjustable Speed  No  Amperage (amps)  13
Cord Length (ft.)  Corrosion Resistant  Yes
Discharge Flow 0 ft. @ 40 PSI (gallons/hour)  840  Discharge Flow 15 ft. @ 40 PSI (gallons/hour)  690
Discharge Flow 25 ft. @ 40 PSI (gallons/hour)  Discharge Flow 40 ft. @ 40 PSI (gallons/hour)
Discharge Flow 5 ft. @ 40 PSI (gallons/hour)  780  Discharge Flow 60 ft. @ 40 PSI (gallons/hour)
Discharge Flow 90 ft. @ 40 PSI (gallons/hour)  Discharge Flow @ 0 ft. (gallons/hour)  840
Float Switch  No  Hardware Included  No
Head Pressure (ft.)  20  Horsepower (hp)  1 hp
Housing Material  Cast-Iron  Inlet Connection  Threaded female
Jet Pump Product Type  Shallow Well  Maximum Pressure (psi)  50
Maximum Working Temperature (F)  120  Minimum working temperature (F)  40
Non-Clogging  No  Number of Impellers
Outlet Connection  Threaded female  Power Type Required  AC
Product Weight (lb.)  42 lb  Pump Switch Type  Switchless
Returnable  90-Day  Self-Priming  Yes
Thermal Overload Protection  Yes  Voltage (volts)  120/240
With Tank  No
Warranty / Certifications
Manufacturer Warranty


Rated 4.7 out of 5 by 3 reviewers.
Rated 4 out of 5 by one week of operation and all is well This pump appears to be a fine value for the money. i replaced my existing 1/2 hp with this 1hp unit thinking I would get faster and better delivery, but did not achieve all the results I'd hoped for due I think to a fixed size inlet pipe from the well. This pump is quieter than the Sta Rite I had, whose bushings sounded to be failing, and the installation process was easy - no hassles with the pump, only some minor plumbing re-arrangements. I would recommend at this point. I did not give five stars simply because I will need to see if it is still working just as well next year. September 4, 2013
Rated 5 out of 5 by Worked out just Fine I went to the 1hp pump to increase presure and it has done the job September 24, 2013
Rated 5 out of 5 by 1 hp shallow well jet pump follow instructions & pour in water to get pump going. I went from 1/2 hp to 1 hp. got good pressure. very please. December 24, 2013
1-3 of 3
