Wayne 12 Volt Transfer Pump-PC1 - The Home Depot
Discontinued

Wayne

Model # PC1

Internet # 203663854

12 Volt Transfer Pump


Wayne 12 Volt Transfer Pump


This item has been discontinued.
The Home Depot no longer carries this specific product.

$139.97 / each
Loading...

PRODUCT OVERVIEW

Model # PC1

Internet # 203663854

The WAYNE PC1 is a portable 12 volt transfer pump that is light weight and easily transported anywhere. The 11 ft. power cord connects directly to a 12 volt battery (not included). The intake and output for the pump connects with standard garden hose, making this pump easy to use.

  • pumps up to 350 GPH at 0 ft.
  • 3/4 in. chrome-plated bronze suction/discharge
  • Removes water down to 1/8 in. of surface when water suction attachment is connected
  • Easy connection to 12 volt battery with convenient on/off switch
  • Alligator clamps connect to battery
  • Includes a 6 ft. suction hose, water suction attachment, and replacement parts kit
  • Home Depot Protection Plan:

    Home Depot Protection Plan

Info & Guides

You will need Adobe® Acrobat® Reader to view PDF documents. Download a free copy from the Adobe Web site.

SPECIFICATIONS

Dimensions
Assembled Depth (in.)  9 in  Assembled Height (in.)  7.6 in
Assembled Width (in.)  9 in  Maximum Pumping Height (ft.)  45
Product Depth (in.)  Product Height (in.)  7.6
Product Width (in.)  7.6
Details
Adjustable Speed  No  Amperage (amps)  14
Cord Length (ft.)  11  Corrosion Resistant  Yes
Discharge Flow @ 0 ft. (gallons/hour)  300  Discharge Flow @ 10 ft. (gallons/hour)  250
Float Switch  No  Hardware Included  No
Head Pressure (ft.)  45  Horsepower (hp)  0 hp
Housing Material  Aluminum  Inlet Connection  Threaded male
Maximum Discharge Flow (gallons/hour)  300  Maximum Working Temperature (F)  120
Minimum working temperature (F)  40  Outlet Connection  Threaded male
Power Type  Electric  Power Type Required  DC
Product Weight (lb.)  6.3 lb  Pump Switch Type  Switchless
Returnable  90-Day  Run-Dry Capable  No
Self-Priming  Yes  Submersible  No
Voltage (volts)  12
Warranty / Certifications
Certifications and Listings  SSPMA Certified  Manufacturer Warranty

CUSTOMER REVIEWS

Rated 5.0 out of 5 by 6 reviewers.
Rated 5.0 out of 5.0 by Product has saved time and money This product has saved us time and money. At our remote building's rainwater collection system, we run this pump from our truck battery. At the house garden, we attach it directly to the battery array powered by our solar panels. It has replaced doing the job of watering the gardens by watering can and we can use our rainwater collection systems efficiently. June 12, 2013
Rated 5.0 out of 5.0 by Worked Beautifully! Have used pump three times so far- Pumped 6 feet high from a creek and then pumped water 25 feet to my storage barrels. No problems. Filled 4 50 gallon barrels in less than an hour. No problems. May 28, 2013
Rated 5.0 out of 5.0 by 3 Years, 120+ Gallons a Week and going strong! I wish everything I bought worked this well and was as dependable. I just plain works. Every time. For a long time. I/we use it in the house to move filtered (5 stage) water around. We move at least 120 gallons a week. Every week. I bought it it's own little battery and a wee trickle charger. If I need it outside I grab it and the battery and go. We fill a lot of gallon jugs. Takes 20 seconds flat. For the mathematically impaired that's 3 a minute or 180 an hour in real life. In all honesty, don't expect to lift water very high. Simply because of the priming needed. If your source is "up" over a foot or so you need to prime the unit with some vegetable oil or a slight prime by sucking on the out hose a tad. What that does is extend it's life...fried the first one's pump. But it was replaced and when used correctly, as in read the instructions first, it works like the Energizer bunny. July 21, 2013
Rated 5.0 out of 5.0 by This product is very simple to use. This product is very light and portable and it does what its suppose to do. I love it that I can take it anywhere. The only thing I recommend is to lay it on the ground level when using it. August 21, 2013
Rated 5.0 out of 5.0 by Works very good Very pleased with the pump , works good muddy water and is very easy to assemble January 28, 2014
Rated 5.0 out of 5.0 Descent pump. The pump does what its designed to do. Not very high pressure but it does work well. July 2, 2013
