Project Guide

Cutting a Cope Joint on Crown Moulding

1
LAYOUT AND MITRE THE COPE
Layout mitre cope - Cutting  Cope Crown Moulding

Nail the first piece of moulding in place. Hold the second piece temporarily in place, and lay out the direction of the miter by drawing a line that starts at the bottom of the moulding and angles up and away from the corner. The line is only a guide and doesn't need to be drawn at any particular angle. Put the moulding on the miter saw and set the saw to cut a 45-degree miter that angles in the general direction of the line you drew and make the cut.

2
BEGIN AT THE FLAT ALONG THE BOTTOM EDGE OF THE MOULDING
Bottom edge the moulding - Cutting  Cope Crown Moulding

Put the saw blade on the end grain just below the surface of the moulding, as shown. If the moulding is primed, you will lay the saw just a hair below the lower surface of the paint. Make a few passes with the saw, making a shallow groove along the entire length of the flat.

3
CHANGE THE ANGLE OF THE SAW
Change angle saw - Cutting  Cope Crown Moulding

Once you have made a shallow cut into the flat, lift the saw handle and begin cutting along the bottom corner of the moulding. Cut from the corner to the point where the cove begins, following the groove you cut in step two.

4
CUT IN FROM THE BACK
Cut from the back - Cutting  Cope Crown Moulding

Back the saw out of the cut you have made. Start a new cut from the back of the moulding. Cut up towards the middle of the cove and then follow the shape of the cove until you reach the cut you finished in step three. Remove the waste.

5
CUT OUT THE UPPER SECTION OF THE COVE
Cut upper section cove - Cutting  Cope Crown Moulding

Turn the saw around and cut along the profile of the upper section of the cove. Stop cutting when you reach the fillet.

6
CUT OUT THE FILLET
Cut out the fillet - Cutting  Cope Crown Moulding

Come in from the back of the moulding and cut along the fillet until you reach the cut you made at the top of the cove.

7
CUT ALONG THE S-CURVE
Cut along S-curve - Cutting  Cope Crown Moulding

Start at the fillet and cut along the S-curve until you reach the flat at the top of the moulding.

8
CUT OUT THE FLAT ALONG THE TOP OF THE MOULDING
Cut flat along moulding - Cutting  Cope Crown Moulding

Put the saw on the end grain just below the surface of the moulding. Make a few shallow passes and then raise the handle so that the saw is cutting deepest at what will be the top edge of the moulding. Continue cutting until the saw meets the cut along the S-curve and the waste falls away.
