- Constructed of high-impact resistant polystyrene for durability
- Multiple mounting options for installation flexibility
- Quarter-turn ball valve design for simple flow control
- View More Details
Free & Easy Returns In Store or Online
Return this item within 90 days of purchase.
Ask about this product
Get an answer now with AI
AI-generated from the text of manufacturer documentation. To verify or get additional information, please contact The Home Depot customer service.
Product Details
About This Product
The Apollo ExpansionPEX Ice Maker Outlet Box includes a 1/2 in. Brass PEX-A barb ice maker valve and is simple to install. It provides flow control through an anti-stick and smooth operating quarter-turn handle. Ideal for installations of ice makers, refrigerators and filtered water dispensers. Apollo ExpansionPEX barb fittings are a key component of the most economical potable water piping systems. Apollo ExpansionPEX barb connections must be secured into place Apollo ExpansionPEX sleeves or comparable expansion-type sleeve or ring (all sold separately). The Apollo ExpansionPEX system is a comprehensive piping system comprised of lead free brass fittings, poly alloy fittings, manifolds, valves, fasteners, tools and tubing designed for implementation in water delivery systems, simple or complex. A cold-expansion tool (sold separately) is required for installation.
Highlights
- Valve constructed of lead free dezincification resistant (DZR) brass for superior reliability and strength
- Designed exclusively for use within type A PEX piping systems
- 1/4 in. O.D. male compression outlet
- Box design allows for left or right stud mounting
- Snap in place faceplate allows for up to 3/4 in. drywall
- Ideal for installations of ice makers, refrigerators and filtered water dispensers
- Larger internal diameter of Apollo ExpansionPEX fittings results in a 25% greater flow rate within the system
- Meets or exceeds ASTM F1960 standard
- Meets UPC, IPC, and cUPC standard requirements
- Must secured in place using Apollo ExpansionPEX sleeves or other PEX-A expansion sleeves/rings (all sold separately)
- NSF listed
- Barb x barb connection for PEX-A plumbing systems
- Go/no-go gauges are never required
- To ensure secure connections every time, fittings cannot be dry fit
- Maximum working pressure of 200 psi and maximum temperature of 200 degree F
- Return Policy
- California residentssee Prop 65 WARNINGS
Product Information
Specifications
Dimensions
Inlet Diameter (In.) | 1/2 |
|---|---|
Outlet Diameter (In.) | 1-1/4 |
Product Length (in.) | 7.25 in |
Details
Application | Potable Water |
|---|---|
Compatible Pipe Material | PEX |
Connection | Barb |
Features | Corrosion Resistant, Lead Free, Quarter Turn |
Indoor/Outdoor | Indoor |
Material | Brass |
Maximum Pressure (PSI) | 200 PSI |
Maximum Working Temperature (F) | 200 |
Pack Size | 1 |
Returnable | 90-Day |
Warranty / Certifications
Manufacturer Warranty | 5 Years: For exclusive use with ASTM F1960 fittings, fasteners and pipe. |
|---|
Questions & Answers
Does Applo offer this box with the water hammer arrester as part of the on/off valve?
Do I need to add a water hammer arrestor to this?
A hammer arrestor should be installed if you're experience water hammer—a loud banging or knocking noise in your plumbing system caused by the sudden stop of water flow.
It’s says 1/2” outlet so this won’t work with the standard 1/4 in. COMP x 1/4 in. COMP x 60 in. Stainless Steel Ice Maker Connector?
The supply line is for 1/2" PEX-A Bard but the outlet is still 1/4 in O.D Male Compression.
Can the entire valve be rotated so the water line connecting to my frig will be at a lesser angle (45-deg instead of 90-deg) my frig is large, so I need it close to the wall as possible. Water line coming out of the valve at 90-deg interferes with this.
Yes, valve can be rotated.
Can this be used for hot water (for a dishwasher)?
Sure, as long as the water does not exceed 200°F.
Can this box be mounted upsidedown with the pex line coming from the top and the valve below that?
Yes, the Apollo 1/2 in. Brass PEX-A Barb Icemaker Outlet Box may be mounted and installed upside down.
Installing in a duplex firewall, are these fire rated? 1 or 2 hour?
No, these are not fire rated.
Viewing 1-7 of 7
