1/2 in. Chrome-Plated Brass PEX-A Barb x 1/4 in. Compression Quarter-Turn Icemaker Tee Valve
- Quarter-turn, single lever flow control
- 1/4 in. OD male compression outlets for supply line integration
- Designed exclusively for use within type A PEX piping systems
- View More Details
Free & Easy Returns In Store or Online
Return this item within 90 days of purchase.
Ask about this product
Get an answer now with AI
AI-generated from the text of manufacturer documentation. To verify or get additional information, please contact The Home Depot customer service.
Product Details
About This Product
The Apollo ExpansionPEX 1/2 in. Chrome-Plated Brass PEX-A Barb x 1/4 in. Compression Quarter-Turn Icemaker Tee Valve is a unique design that allows flow control to the outlet of the tee. It was designed with retrofit ice maker and water filtration installations in mind. The 1/4 in. compression outlet provides the capability to install 1/4 in. O.D. tubing or 1/4 in. supply lines. Apollo ExpansionPEX fittings must be secured into place Apollo ExpansionPEX sleeves or comparable expansion-type sleeve or ring (all sold separately). The Apollo ExpansionPEX system is a comprehensive cold expansion piping system comprised of brass fittings, poly alloy fittings, manifolds, valves, fasteners, tools and tubing designed for implementation in water delivery systems, simple or complex. A cold-expansion tool (sold separately) is required for installation.
Highlights
- Constructed of chrome-plated lead free dezincification resistant (DZR) brass for superior reliability and strength
- Cold-expansion tool (sold separately) is required for installation
- Meets or exceeds ASTM F1960 standard
- Meets UPC, IPC, and cUPC standard requirements
- Must secured in place using Apollo ExpansionPEX sleeves or other PEX-A expansion sleeves/rings (all sold separately)
- Meets UPC, IPC and cUPC standard
- NSF listed
- 1/2 in. PEX-A barb x 1/2 in. PEX-A barb x 1/4 in. O.D. male compression outlet for PEX-A plumbing systems
- Rated to 200 degree F and 200 psi
- To ensure secure connections every time, fittings cannot be dry fit
- Maximum working pressure of 200 psi and maximum temperature of 250 degree F
- Item is not compatible with PEXb pipe, crimp-style (ASTM 1807) or pinch clamp (ASTM F2098) piping systems
- Go/no-go gauges are never required
- Return Policy
- California residentssee Prop 65 WARNINGS
Product Information
Specifications
Dimensions
Inlet Diameter (In.) | 1/2 |
|---|---|
Outlet Diameter (In.) | 1/4 |
Product Length (in.) | 2.505 in |
Details
Application | Potable Water |
|---|---|
Compatible Pipe Material | PEX |
Connection | Barb |
Features | Corrosion Resistant, Lead Free, Quarter Turn |
Indoor/Outdoor | Indoor |
Material | Brass |
Maximum Pressure (PSI) | 200 PSI |
Maximum Working Temperature (F) | 200 |
Pack Size | 1 |
Returnable | 90-Day |
Warranty / Certifications
Manufacturer Warranty | 5 Years: For exclusive use with ASTM F1960 fittings, fasteners and pipe. |
|---|
