Best Barns Arlington 12 ft. x 16 ft. Wood Storage Shed Kit with Floor including 4 x 4 Runners
0609788086727

Best Barns

Arlington 12 ft. x 16 ft. Wood Storage Shed Kit with Floor including 4 x 4 Runners

  • High sidewalls and a large loft provides plenty of storage
  • Windows provide both ventilation and light (included)
  • Ready to paint any color. Purchase shingles to match your home
$ 7095 60 /each
store icon Loading Buying Options...
package icon Loading Buying Options...
Sorry, but we ran into issues loading these options. Please try refreshing.

Frequently Bought Together

Frequently Bought Together

Product Overview

  • High sidewalls and a large loft provides plenty of storage
  • Windows provide both ventilation and light (included)
  • Ready to paint any color. Purchase shingles to match your home
The Arlington by Best Barns offers a spacious interior and large loft area for all your storage needs. Featuring a second floor loft with 4 ft. - 3 in. headroom that provides enough space for a sleeping area if you are looking for a cabin or a significant amount of storage area. 2 Dormers and a gable window with sunburst provide additional light and ventilation. The first floor, with it's high side walls, has plenty of room to add shelving for even more versatile storage. Included are double pocket doors, 1, 32 in. x 80 in. 9 lite walk-in door, 2, 18 in. x 36 in. windows with vinyl shutters, 1 gable window with sunburst and 2 dormers with windows. Floor included. Check with your local permit authority before placing order. Shingles purchased by homeowner. Building is shipped directly to you via curbside delivery.
  • Assembled dimensions: 144 in. W x 192 in. D x 170 in. H
  • Sturdy-built truss system provides for 40 lb. snow load and 130 MPH wind load
  • Select grade pre-cut white pine trim
  • Premium LP smart side paneling grooved 8 in. O.C. treated to resist fungal decay and insect infestation carries a 50-year limited warranty, siding is primed ready to paint
  • Pre-assembled, 6 ft. - 6 in. high x 5 ft. - 5 in. wide pocket doors with cross buck door design
  • Deluxe floor with 3/4 in. plywood floor sheathing and treated 2 x 4 floor joist 16 in. O.C. and 4 x 4 runners included
  • Premium grade 2x4 construction spaced 24 in. O.C.
  • All required nails, hardware, glue are provided along with detailed easy to follow step-by-step instructions
  • Assembly required, some cutting required during assembly
  • 18 in. x 36 in. windows with vinyl shutters, gable and dormer windows include lower screen for ventilation
  • 15-year limited warranty
  • Check with your local permit office before purchasing
  • Check with your local permit office before purchasing
  • Click to find out more about buying outdoor storage sheds
  • California residents see Prop 65 WARNINGS

Product Overview

  • High sidewalls and a large loft provides plenty of storage
  • Windows provide both ventilation and light (included)
  • Ready to paint any color. Purchase shingles to match your home
Model #: arlington_1216df
Internet #: 203431827

The Arlington by Best Barns offers a spacious interior and large loft area for all your storage needs. Featuring a second floor loft with 4 ft. - 3 in. headroom that provides enough space for a sleeping area if you are looking for a cabin or a significant amount of storage area. 2 Dormers and a gable window with sunburst provide additional light and ventilation. The first floor, with it's high side walls, has plenty of room to add shelving for even more versatile storage. Included are double pocket doors, 1, 32 in. x 80 in. 9 lite walk-in door, 2, 18 in. x 36 in. windows with vinyl shutters, 1 gable window with sunburst and 2 dormers with windows. Floor included. Check with your local permit authority before placing order. Shingles purchased by homeowner. Building is shipped directly to you via curbside delivery.

  • Assembled dimensions: 144 in. W x 192 in. D x 170 in. H
  • Sturdy-built truss system provides for 40 lb. snow load and 130 MPH wind load
  • Select grade pre-cut white pine trim
  • Premium LP smart side paneling grooved 8 in. O.C. treated to resist fungal decay and insect infestation carries a 50-year limited warranty, siding is primed ready to paint
  • Pre-assembled, 6 ft. - 6 in. high x 5 ft. - 5 in. wide pocket doors with cross buck door design
  • Deluxe floor with 3/4 in. plywood floor sheathing and treated 2 x 4 floor joist 16 in. O.C. and 4 x 4 runners included
  • Premium grade 2x4 construction spaced 24 in. O.C.
  • All required nails, hardware, glue are provided along with detailed easy to follow step-by-step instructions
  • Assembly required, some cutting required during assembly
  • 18 in. x 36 in. windows with vinyl shutters, gable and dormer windows include lower screen for ventilation
  • 15-year limited warranty
  • Check with your local permit office before purchasing
  • Check with your local permit office before purchasing
  • Click to find out more about buying outdoor storage sheds
  • California residents see Prop 65 WARNINGS

Info & Guides

You will need Adobe® Acrobat® Reader to view PDF documents. Download a free copy from the Adobe Web site.

Compare Similar

Price
$7,095.60 /each
$7,747.92 /each
$8,174.58 /each
$8,709.75 /each
Name Arlington 12 ft. x 16 ft. Wood Storage Shed Kit with Floor including 4 x 4 Runners Arlington 12 ft. x 24 ft. Wood Storage Shed Kit Arlington 12 ft. x 20 ft. Wood Storage Shed Kit with Floor Including 4 x 4 Runners Arlington 12 ft. x 24 ft. Wood Storage Shed Kit with Floor including 4 x 4 Runners
Brand Best Barns Best Barns Best Barns Best Barns
Ratings (2) (1) (1) (2)
Approximate Width (ft.) 12 12 12 12
Maximum Roof Load (lb./ sq. ft.) 40 40 40 40
Storage Capacity (cu. ft.) 1920 2880 2400 2880
Manufacturer Warranty 15 Year Limited Warranty 15 Year Limited Warranty 15 Year Limited Warranty 15 Year Limited Warranty
Maximum Wind Resistance (mph) 130 130 130 130
Approximate Depth (ft.) 16 24 20 24
Foundation Foundation Included Foundation Not Included Foundation Included Foundation Included
Shed Features Door Latch,Double Door,Lockable Door,Loft,Shutters,Single Door,Windows Door Latch,Double Door,Lockable Door,Loft,Shutters,Single Door,Windows Door Latch,Double Door,Lockable Door,Loft,Shutters,Single Door,Windows Door Latch,Double Door,Lockable Door,Loft,Shutters,Single Door,Windows
Coverage Area (sq. ft.) 192 288 240 288
View Product View Product View Product View Product

Specifications

Dimensions

Approximate Depth (ft.)
16
Approximate Width (ft.)
12
Assembled Depth (in.)
192 in
Assembled Height (in.)
163 in
Assembled Width (in.)
144 in
Coverage Area (sq. ft.)
192
Door Opening Height (In.)
78
Door Opening Width (In.)
65
Door Opening Width (ft.)
5
Exact Width x Depth
12 ft x 16 ft
Sidewall Height (in.)
97.0

Details

Assembly Required
Yes
Capacity (cu. ft.) - Total
1920
Color Family
Clear
Floor Options
With Floor and Runners
Foundation
Foundation Included
Manufacturers Recommended Assembly Time (hours)
96
Manufacturers Recommended Tools needed for Assembly
Safety Glasses, Hammer, Screwdriver, Level, Ladders, Tape Measure, Square, Drill, Circular Saw
Maximum Roof Load (lb./ sq. ft.)
40
Maximum Wind Resistance (mph)
130
Number of People Recommended by Manufacturer to Assemble
3
Number of Windows
5
Product Weight (lb.)
2200lb
Returnable
90-Day
Roof Color Family
Clear
Roof Material
Wood
Roof Pitch
10/12
Roof Shape
Peak
Shed Door Type
Double
Shed Features
Door Latch,Double Door,Lockable Door,Loft,Shutters,Single Door,Windows
Shed Included
Floor
Shed Style
Ranch
Shed Type
Wood
Siding Color Family
Gray
Storage Capacity (cu. ft.)
1920

Warranty / Certifications

Manufacturer Warranty
15 Year Limited Warranty

Specifications

Dimensions

Approximate Depth (ft.)
16
Approximate Width (ft.)
12
Assembled Depth (in.)
192 in
Assembled Height (in.)
163 in
Assembled Width (in.)
144 in
Coverage Area (sq. ft.)
192
Door Opening Height (In.)
78
Door Opening Width (In.)
65
Door Opening Width (ft.)
5
Exact Width x Depth
12 ft x 16 ft
Sidewall Height (in.)
97.0

Details

Assembly Required
Yes
Capacity (cu. ft.) - Total
1920
Color Family
Clear
Floor Options
With Floor and Runners
Foundation
Foundation Included
Manufacturers Recommended Assembly Time (hours)
96
Manufacturers Recommended Tools needed for Assembly
Safety Glasses, Hammer, Screwdriver, Level, Ladders, Tape Measure, Square, Drill, Circular Saw
Maximum Roof Load (lb./ sq. ft.)
40
Maximum Wind Resistance (mph)
130
Number of People Recommended by Manufacturer to Assemble
3
Number of Windows
5
Product Weight (lb.)
2200lb
Returnable
90-Day
Roof Color Family
Clear
Roof Material
Wood
Roof Pitch
10/12
Roof Shape
Peak
Shed Door Type
Double
Shed Features
Door Latch,Double Door,Lockable Door,Loft,Shutters,Single Door,Windows
Shed Included
Floor
Shed Style
Ranch
Shed Type
Wood
Siding Color Family
Gray
Storage Capacity (cu. ft.)
1920

Warranty / Certifications

Manufacturer Warranty
15 Year Limited Warranty

Questions & Answers

how do you flash the dormers when roofing if it is single wall siding?

how do you flash the dormers when roofing if it is single wall siding?
Asked by: Kyle
Kyle, Dormers include step flashing and also an OSB underlay which is then sided over after flashing and shingles are installed. Richard Best Barns
Answered by: Best Barns Support
Date published: 2018-12-03

Does the windows on the bottom floor open?

Asked by: Lisa
Yes, the lower windows are functional and come with a screen.
Answered by: CommunityAnswer
Date published: 2018-10-13

Can this be purchased without the dormers? If so, how much less would the price be?

Can this be purchased without the dormers? If so, how much less would the price be?
Asked by: Karen
The answer posted did not address my question. Can I get the Arlington without the dormers? The Arlington, not the Belmont. Thank you.
Answered by: Karen
Date published: 2017-07-20

I couldn't find window installation information in the plans. Shouldn't the windows go in first, ...

I couldn't find window installation information in the plans. Shouldn't the windows go in first, before the siding?
Asked by: Atilla
The windows would be best added after the shed is complete. They are not installed the same way that windows in a house would be, and there is too great a chance they would get broken when you are setting the walls into place. Best done last.
Answered by: Muffin
Date published: 2018-08-15
  • y_2018, m_12, d_10, h_18CST
  • bvseo_bulk, prod_bvqa, vn_bulk_2.0.9
  • cp_1, bvpage1
  • co_hasquestionsanswers, tq_21
  • loc_, sid_203431827, prod, sort_[SortEntry(order=NUM_ANSWERS, direction=DESCENDING), SortEntry(order=SUBMISSION_TIME, direction=DESCENDING), SortEntry(order=LAST_APPROVED_ANSWER_SUBMISSION_TIME, direction=DESCENDING), SortEntry(order=LAST_APPROVED_ANSWER_SUBMISSION_TIME, direction=DESCENDING), SortEntry(order=BEST_ANSWER_FEEDBACK_COUNT, direction=DESCENDING), SortEntry(order=POSITIVE_ANSWER_FEEDBACK_COUNT, direction=DESCENDING), SortEntry(order=NUM_ANSWERS, direction=DESCENDING)]
  • clientName_homedepot
  • bvseo_sdk, java_sdk, bvseo-3.1.1
  • CLOUD, getContent, 29ms
  • QUESTIONS, PRODUCT

Customer Reviews

Arlington 12 ft. x 16 ft. Wood Storage Shed Kit with Floor including 4 x 4 Runners is rated 4.0 out of 5 by 2.
Rated 4 out of 5 by from We aren't quite finished building this shed, but it is fun to put together. A few notes; the lon... We aren't quite finished building this shed, but it is fun to put together. A few notes; the long sidewall measurements in the instruction manual are incorrect. If we had built them the way the book stated, they would have been 3 inches too narrow for the opening. I had to recalculate where to put the studs in order to make the siding work out right. Thankfully we caught the error before wasting a sheet of siding. Also, the top wall tie members are also figured at the wrong lengths. The construction book needs another revision. The 2 long sidewall sections (without the door or windows) need to be exactly the same measurements, and then the other long sidewall with the door and windows needs to be 3 inches wider. This did make it a little harder to construct because we had to stop and reconfigure both of those walls. Another note, the gable ends are extremely heavy and while 3 young people may be able to get them up on top of the wall, we would recommend 4 people, 2 inside to help haul the gable ends up and 2 at the bottom to steady it. We haven't put the gable ends up yet, but we are going to attach some eye bolts to the inside 2x4's and use some ropes or straps to help get it up. The remaining trusses are probably easy enough for 3 people to handle, as they are much lighter. If I am able to update the review after the shed is completed, I will complete my thoughts on this product.
Date published: 2018-08-15
Rated 4 out of 5 by from The load of lumber from Home Depot locally was embarrassingly... The load of lumber from Home Depot locally was embarrassingly poor. I had to return at least 25 pieces and choose my own. The trim on the sliding doors was bowed, so they don’t fit quite right. There was no space above the service door for adjusting, so the header had to be trimmed. Dormer const
Date published: 2017-11-02
