Internet #205214604

Model #B8-60DW6 P

1/2 in. FIP x 3/8 in. Compression x 60 in. Braided Polymer Dishwasher Connector with 3/8 in. Compression Elbow

How to Get It

Product Overview

BrassCraft Speedi Plumb PLUS 1/2 in. Female Iron Pipe inlet x 3/8 in. Compression outlet x 60 in. length flexible braided polymer water connector with 3/8 in. Compression Elbow adaptor. Used to connect the water supply to your dishwasher, this connector features a high tenacity, multi-filament yarn, protected by a special polymer coating for optimum corrosion resistance and durability. On the inside, our tough PVC tubing resists attack by chlorine, chloramines and other corrosive elements. The braided polymer fibers are designed to bend freely without kinking or crimping.
  • 60 in. length connector with 1/2 in. FIP connection to water supply or water shut-off valve
  • Includes 3/8 in. compression elbow fitting to connect to appliance
  • Bends freely, without kinking or crimping, installation is easier, especially in cramped quarters
  • External corrosion resistance to common household, tile and glass cleaners
  • Internal corrosion resistance to harsh water conditions
  • 8-sided pneumatic crimp for greater dependability and reliable nut-to-hose connections
  • Temperature rating: 40° to 140° F, intermittent to 180° F
  • Pressure rating: 125 psi maximum
  • No-lead certified
  • IAPMO and CSA listed to ASME A112.18.6/CSA B125.6
  • Designed, machined and assembled in the USA
  • California residents

Additional Resources

From the Manufacturer

Compare Similar Supply Lines

1/2 in. FIP x 3/8 in. Compression x 48 in. Braided Polymer Dishwasher Connector with 3/8 in. Compression Elbow
current product
1/2 in. FIP x 3/8 in. Compression x 60 in. Braided Polymer Dishwasher Connector with 3/8 in. Compression Elbow
3/8 in. Compression x 3/8 in. Compression x 60 in. Braided Polymer Dishwasher Connector with 3/8 in. Compression Elbow1/2 in. FIP x 1/2 in. FIP x 48 in. Braided Polymer Dishwasher Connector
BrandBrassCraftBrassCraftBrassCraftBrassCraft
Name1/2 in. FIP x 3/8 in. Compression x 48 in. Braided Polymer Dishwasher Connector with 3/8 in. Compression Elbow1/2 in. FIP x 3/8 in. Compression x 60 in. Braided Polymer Dishwasher Connector with 3/8 in. Compression Elbow3/8 in. Compression x 3/8 in. Compression x 60 in. Braided Polymer Dishwasher Connector with 3/8 in. Compression Elbow1/2 in. FIP x 1/2 in. FIP x 48 in. Braided Polymer Dishwasher Connector
Price
$1305
$1610
$1610
$1656
Ratings
(4)
(4)
(1)
(208)
Product Length (in.)48.250 in61.375 in61.000 in48.375 in
Tube Diameter (in.)0.5500.5500.5500.550
Inlet Fitting End TypeFIPFIPCompressionFIP
Outlet Fitting End TypeCompressionCompressionCompressionFIP
Inlet Diameter (In.)1/21/23/81/2
Outlet Diameter (In.)3/83/83/81/2
Plumbing Part TypeSupply LineSupply LineSupply LineSupply Line
Product Width (in.)0.8750.8750.6890.875
FeaturesFlexibleFlexibleFlexibleFlexible
Application Potable Water
View ProductView ProductView ProductView Product

Specifications

Dimensions

Inlet Diameter (In.)1/2Outlet Diameter (In.)3/8
Product Depth (in.)1.125Product Length (in.)61.375 in
Product Width (in.)0.875Tube Diameter (in.)0.550

Details

Color FamilySilverColor/FinishSilver
FeaturesFlexibleFitting MaterialBrass
Inlet Fitting End TypeFIPMaximum Pressure (PSI)125
Outlet Fitting End TypeCompressionPlumbing Part TypeSupply Line
Returnable90-Day

Warranty / Certifications

Certifications and ListingsCSA Certified,IAPMO CertifiedManufacturer WarrantyLimited Manufacturer Warranty
