Class 3 Trailer Hitch for Toyota Rav4

  • Tested and rated for 3,500 lbs. gross trailer weight
  • Industry-leading, co-cured Bonderite and powder coat finish
  • Standard 2" receiver to accept a ball mount
$ 139 45
store icon Loading Buying Options...
package icon Loading Buying Options...
Sorry, but we ran into issues loading these options. Please try refreshing.

Frequently Bought Together

Frequently Bought Together

Product Overview

  • Tested and rated for 3,500 lbs. gross trailer weight
  • Industry-leading, co-cured Bonderite and powder coat finish
  • Standard 2" receiver to accept a ball mount
The CURT Class 3 trailer hitch is the most common type of trailer hitch installed on full-size pickup trucks and SUVs. It is also popular on crossovers and mid-size trucks. That is because the Class 3-packs the punch of a heavyweight hitch while still staying light on its feet. CURT Class 3 hitches range in gross trailer weight capacity from 3,500 lbs. to an impressive 8,000 lbs. and offer a comparable tongue weight capacity ranging from 350 lbs. to 800 lbs. These hitches are engineered to be strong and capable, having a quality steel frame in round tube or square tube form. Class 3 trailer hitches are able to tow most standard size trailers. This type of hitch uses a 2 in. x 2 in. receiver tube opening to accept a ball mount or towing accessory with an equivalent shank. One special feature about the Class 3 that is not found in Classes 1 or 2 is its compatibility with a weight distribution hitch. When used in combination with a WD hitch, the Class 3 hitches gross trailer weight capacity increases to 12,000 lbs. and the tongue weight capacity to 1,200 lbs. CURT Class 3 hitches are put through strenuous testing before they are deemed ready for market. They also come with 2 coatings a liquid Aquence coating and a powder coat in high-gloss black that cure together to form a strong resistance against rust, scratching, UV damage and other wear. Our hitches are our pride, and as such, we back them up with a limited lifetime warranty and a 1-year finish warranty.
  • Round tube main body
  • Ballmount not included
  • Never exceed vehicle weight rating
  • Hitch ball and ball mount sold separately


















Product Overview

  • Tested and rated for 3,500 lbs. gross trailer weight
  • Industry-leading, co-cured Bonderite and powder coat finish
  • Standard 2" receiver to accept a ball mount
Model #: 13149
Internet #: 205631051

The CURT Class 3 trailer hitch is the most common type of trailer hitch installed on full-size pickup trucks and SUVs. It is also popular on crossovers and mid-size trucks. That is because the Class 3-packs the punch of a heavyweight hitch while still staying light on its feet. CURT Class 3 hitches range in gross trailer weight capacity from 3,500 lbs. to an impressive 8,000 lbs. and offer a comparable tongue weight capacity ranging from 350 lbs. to 800 lbs. These hitches are engineered to be strong and capable, having a quality steel frame in round tube or square tube form. Class 3 trailer hitches are able to tow most standard size trailers. This type of hitch uses a 2 in. x 2 in. receiver tube opening to accept a ball mount or towing accessory with an equivalent shank. One special feature about the Class 3 that is not found in Classes 1 or 2 is its compatibility with a weight distribution hitch. When used in combination with a WD hitch, the Class 3 hitches gross trailer weight capacity increases to 12,000 lbs. and the tongue weight capacity to 1,200 lbs. CURT Class 3 hitches are put through strenuous testing before they are deemed ready for market. They also come with 2 coatings a liquid Aquence coating and a powder coat in high-gloss black that cure together to form a strong resistance against rust, scratching, UV damage and other wear. Our hitches are our pride, and as such, we back them up with a limited lifetime warranty and a 1-year finish warranty.

  • Round tube main body
  • Ballmount not included
  • Never exceed vehicle weight rating
  • Hitch ball and ball mount sold separately


















Key Features

Product Overview
Key Features
  • Tested and rated for 3,500 lbs. gross trailer weight
  • Industry-leading, co-cured Bonderite and powder coat finish
  • Standard 2" receiver to accept a ball mount
The CURT Class 3 trailer hitch is the most common type of trailer hitch installed on full-size pickup trucks and SUVs. It is also popular on crossovers and mid-size trucks. That is because the Class 3-packs the punch of a heavyweight hitch while still staying light on its feet. CURT Class 3 hitches range in gross trailer weight capacity from 3,500 lbs. to an impressive 8,000 lbs. and offer a comparable tongue weight capacity ranging from 350 lbs. to 800 lbs. These hitches are engineered to be strong and capable, having a quality steel frame in round tube or square tube form. Class 3 trailer hitches are able to tow most standard size trailers. This type of hitch uses a 2 in. x 2 in. receiver tube opening to accept a ball mount or towing accessory with an equivalent shank. One special feature about the Class 3 that is not found in Classes 1 or 2 is its compatibility with a weight distribution hitch. When used in combination with a WD hitch, the Class 3 hitches gross trailer weight capacity increases to 12,000 lbs. and the tongue weight capacity to 1,200 lbs. CURT Class 3 hitches are put through strenuous testing before they are deemed ready for market. They also come with 2 coatings a liquid Aquence coating and a powder coat in high-gloss black that cure together to form a strong resistance against rust, scratching, UV damage and other wear. Our hitches are our pride, and as such, we back them up with a limited lifetime warranty and a 1-year finish warranty.
  • Round tube main body
  • Ballmount not included
  • Never exceed vehicle weight rating
  • Hitch ball and ball mount sold separately


















Product Overview

  • Tested and rated for 3,500 lbs. gross trailer weight
  • Industry-leading, co-cured Bonderite and powder coat finish
  • Standard 2" receiver to accept a ball mount
Model #: 13149
Internet #: 205631051

The CURT Class 3 trailer hitch is the most common type of trailer hitch installed on full-size pickup trucks and SUVs. It is also popular on crossovers and mid-size trucks. That is because the Class 3-packs the punch of a heavyweight hitch while still staying light on its feet. CURT Class 3 hitches range in gross trailer weight capacity from 3,500 lbs. to an impressive 8,000 lbs. and offer a comparable tongue weight capacity ranging from 350 lbs. to 800 lbs. These hitches are engineered to be strong and capable, having a quality steel frame in round tube or square tube form. Class 3 trailer hitches are able to tow most standard size trailers. This type of hitch uses a 2 in. x 2 in. receiver tube opening to accept a ball mount or towing accessory with an equivalent shank. One special feature about the Class 3 that is not found in Classes 1 or 2 is its compatibility with a weight distribution hitch. When used in combination with a WD hitch, the Class 3 hitches gross trailer weight capacity increases to 12,000 lbs. and the tongue weight capacity to 1,200 lbs. CURT Class 3 hitches are put through strenuous testing before they are deemed ready for market. They also come with 2 coatings a liquid Aquence coating and a powder coat in high-gloss black that cure together to form a strong resistance against rust, scratching, UV damage and other wear. Our hitches are our pride, and as such, we back them up with a limited lifetime warranty and a 1-year finish warranty.

  • Round tube main body
  • Ballmount not included
  • Never exceed vehicle weight rating
  • Hitch ball and ball mount sold separately


















Compare Similar

Compare Similar Products
Brand CURT CURT CURT CURT
Name Class 3 Trailer Hitch for Dodge Ram, Ram 1500 Class 3 Trailer Hitch for Toyota Rav4 Class 3 Trailer Hitch for Acura MDX Class 4 Trailer Hitch for Chevrolet Silverado, GMC Sierra
Price
$84.01
$139.45
$146.59
$153.92
Ratings (14) (12) (11) (7)
View Product View Product View Product View Product

Specifications

Dimensions

Product Depth (in.)
11
Product Height (in.)
48
Product Width (in.)
24

Details

Automotive Part Type
Trailer Hitch
Body Shape
Round
Drilling Required
No
Features
Rust Resistant
Finish
Gloss Black Powder Coat
General Part Type
Trailer Hitch
Hitch Class
Class III
Hitch Class
III
Installation Instructions Included
Yes
Material
Steel
Product Weight (lb.)
45lb
Receiver Opening (in.)
2 in
Receiver Tube Size
2.000 in.
Returnable
90-Day
Visibility
Exposed
Weight Carrying Rating - Gross Trailer Weight (lb.)
3500
Weight Carrying Rating - Tongue Weight (lb.)
525

Warranty / Certifications

Manufacturer Warranty
Limited Lifetime

Specifications

Dimensions

Product Depth (in.)
11
Product Height (in.)
48
Product Width (in.)
24

Details

Automotive Part Type
Trailer Hitch
Body Shape
Round
Drilling Required
No
Features
Rust Resistant
Finish
Gloss Black Powder Coat
General Part Type
Trailer Hitch
Hitch Class
Class III
Hitch Class
III
Installation Instructions Included
Yes
Material
Steel
Product Weight (lb.)
45lb
Receiver Opening (in.)
2 in
Receiver Tube Size
2.000 in.
Returnable
90-Day
Visibility
Exposed
Weight Carrying Rating - Gross Trailer Weight (lb.)
3500
Weight Carrying Rating - Tongue Weight (lb.)
525

Warranty / Certifications

Manufacturer Warranty
Limited Lifetime

Questions & Answers

Are the mounting bolts included

Are the mounting bolts included
Asked by: doitdonnie
Yes
Answered by: Anonymous
Date published: 2019-10-01

Do you have the hitch to fit the 2019 Rav4?

Do you have the hitch to fit the 2019 Rav4?
Asked by: Hooper
Curt's hitch for the 19 Rav4 is part number 13416
Answered by: CURTCustomerService
Date published: 2019-08-27

Can you please add the Rav4 models the product fits to in the product description? In particular,...

Can you please add the Rav4 models the product fits to in the product description? In particular, does this fit 2010 Rav4?
Asked by: Sam
The Instruction sheet that came with the hitch says it fits 2006 - current. The sheet itself says 1/28/2015, so I would check the Curt website www.curtmfg.com for models made after they moved the spare off the rear door)
Answered by: William
Date published: 2019-11-05

Will this fit my 2018 RAV4 hybrid? Are mounting bolts included?

Asked by: Meritmetal
Yes and yes
Answered by: Anonymous
Date published: 2019-10-01
  • y_2019, m_12, d_5, h_21CST
  • bvseo_bulk, prod_bvqa, vn_bulk_3.0.3
  • cp_1, bvpage1
  • co_hasquestionsanswers, tq_9
  • loc_, sid_205631051, prod, sort_[SortEntry(order=NUM_ANSWERS, direction=DESCENDING), SortEntry(order=SUBMISSION_TIME, direction=DESCENDING), SortEntry(order=LAST_APPROVED_ANSWER_SUBMISSION_TIME, direction=DESCENDING), SortEntry(order=LAST_APPROVED_ANSWER_SUBMISSION_TIME, direction=DESCENDING), SortEntry(order=BEST_ANSWER_FEEDBACK_COUNT, direction=DESCENDING), SortEntry(order=POSITIVE_ANSWER_FEEDBACK_COUNT, direction=DESCENDING), SortEntry(order=NUM_ANSWERS, direction=DESCENDING)]
  • clientName_homedepot
  • bvseo_sdk, java_sdk, bvseo-3.1.1
  • CLOUD, getContent, 8ms
  • QUESTIONS, PRODUCT

Customer Reviews

CURT Class 3 Trailer Hitch for Toyota Rav4 is rated 3.8 out of 5 by 12.
Rated 4 out of 5 by from This hitch is very sturdy, however because of its weight, dropping it on one of the brackets will... This hitch is very sturdy, however because of its weight, dropping it on one of the brackets will bend it. The slightest bend of the bracket causes the holes to not line up. I had 2 shipped to me that came bent. The 3rd one finally came with no bends. The hitch fits great and is very sturdy. I think that Curt could do a better job of packing it to keep any weight from resting on the brackets. Home Depot did compensate me for my inconvenience, which was appreciated.
Date published: 2019-10-01
Rated 5 out of 5 by from I installed hitch on 2007 RAV-4 to accommodate a bike... I installed hitch on 2007 RAV-4 to accommodate a bike rack. Installed it in 20 minutes by myself, and had no trouble with the installation (after figuring out the hardware and instructions were taped inside the receiver). You need a 17&19mm sockets & Ft Lb Torque wrench that can be set to 86 ft lbs.
Date published: 2019-11-05
Rated 4 out of 5 by from 4 Star Review Rating provided by a verified purchaser
Date published: 2019-10-23
Rated 2 out of 5 by from Didn’t FIT. Struggled to make it fit by me and... Didn’t FIT. Struggled to make it fit by me and a second attempt by a mechanic. Sent it back. It was recommended and out of the box appeared to be a sturdy product. Very frustrating . With regrets, it was returned. Home Depot service person very nice.
Date published: 2019-07-23
Rated 5 out of 5 by from 5 Star Review Rating provided by a verified purchaser
Date published: 2019-08-28
Rated 5 out of 5 by from Goot product... Goot product
Date published: 2019-07-03
Rated 4 out of 5 by from 4 Star Review Rating provided by a verified purchaser
Date published: 2019-05-15
Rated 5 out of 5 by from Hitch fit perfectly.... Hitch fit perfectly.
Date published: 2019-04-09
