Model #24518

3/4 in. Brass Heat Guard 110-HX Thermostatic Mixing Valve for Radiant/Hydronic Heating

$7117
Apply Now
Pay $46.17 after $25 OFF your total qualifying purchase upon opening a new card. info
Apply for a Home Depot Consumer Card
  • Push to Connect system, quick and easy installation in seconds
  • Works on any combination of Copper, PE-RT, CPVC, PEX Pipe
  • Lead free DZR brass construction for durability and reliability
How to Get It

Frequently Bought Together

+
+
Price:
$7117

Product Overview

The Cash Acme HG110-HX is a temperature actuated thermostatic mixing valve that mixes hot and cold water to deliver the desired reduced temperature hot water. The valve offers a high flow rate which reduces system pressure losses, and robust, low complexity construction. An adjustable and lockable handle prevents tampering. The extended outlet temperature range - up to 176°F (80°C) - makes the 110-HX LF ideal for Radiant/Hydronic heating system applications.
  • High flow rate design for lower pressure losses within the system
  • Every valve is tested prior to shipping
  • Integral union connections on all 3 ports
  • Unique, purpose designed adjuster tool
  • Adjustable outlet temperature range: 85-176°F (29-80°C)
  • Listed by IAPMO and ASSE
  • California residents

Additional Resources

From the Manufacturer

Compare Similar Mixing Valves

current product
3/4 in. Brass Heat Guard 110-HX Thermostatic Mixing Valve for Radiant/Hydronic Heating
1/2 in. Brass Heat Guard 110-D Thermostatic Mixing Valve1/2 in. Push-to-Connect Brass Heat Guard 160 Thermostatic Mixing Valve3/4 in. Brass Heat Guard 160 Thermostatic Mixing Valve
BrandCash AcmeSharkBiteSharkBiteSharkBite
Name3/4 in. Brass Heat Guard 110-HX Thermostatic Mixing Valve for Radiant/Hydronic Heating1/2 in. Brass Heat Guard 110-D Thermostatic Mixing Valve1/2 in. Push-to-Connect Brass Heat Guard 160 Thermostatic Mixing Valve3/4 in. Brass Heat Guard 160 Thermostatic Mixing Valve
Price
$7117
$8856
$13107
$14035
Ratings
(5)
(8)
(9)
(1)
ConnectionFIP x FIP x FIPPTC x PTCPTC x PTCPTC x PTC
Inlet Diameter (In.)3/41/21/23/4
ApplicationPotable WaterPotable WaterPotable WaterPotable Water
Compatible Pipe MaterialMulti-PurposeMulti-PurposeMulti-PurposeMulti-Purpose
MaterialBronzeBronzeBrassBrass
Outlet Diameter (In.)3/41/21/23/4
THD SO SKU 10003177511000317752
View ProductView ProductView ProductView Product

Questions & Answers

Typical questions asked about products:

  • Is the product durable?
  • Is the product easy to use?
  • What are the dimensions of the product?

Customer Reviews

  • 4.6
    out of 5 reviews
  • 100%recommend this product
Filter by:
Showing 1-5 of 5 reviews
This is a temperature regulator used at water heater between hot and cold water pipes with solar ...
This is a temperature regulator used at water heater between hot and cold water pipes with solar heating to prevent scaling when hot water from solar getting too hot. My neighbor called a plumber but he couldn't figure out why the hot water was not coming out from the water heater although the water heater was hot. Replacing this parts was easy with the original Cash Acme Heatguard 110-HX ASSE1017 but this hot/cold side length of this LF series is 3.5" long and the original was 3", so I had to bend the 3/4" pipe out to make it fit. Also, be sure to check the marking, H and C to match the hot/cold side piping since I installed it reversed and it didn't work.
by
  • Verified Purchase
  • Recommended
I can't say to much yet but the dimensions would...
I can't say to much yet but the dimensions would have helped because the length was about 1/4 inch longer than the one I had but made it work. the valve does work fine.
by
Response from RWC SupportMay 21, 2019
Hi, Richard. We are sorry to hear about the confusion with the dimensions. The dimensions are provided on the specification sheet under the product Info & Guides section on the product page on homedepot.com for future reference. We would be happy to help you with any other information you are looking for. Please reach out to our Customer Service Team at 1-877-700-4242 so we can help further! SharkBiteCashAcme
  • Verified Purchase
Works great...
Works great
by
  • Verified Purchase
It was as described and fit the purpose perfectly...
It was as described and fit the purpose perfectly
by
  • Verified Purchase
As expected...
As expected
by
  • Verified Purchase
