Internet #205886666

Model #BPC-3LP

Store SO SKU #1001267989

9000 - 36000 BTU Outdoor Wall Mounting Bracket for Ductless Mini Split Air Conditioners and Heat Pumps

  • Universal mount bracket fits most of mini split outdoor units
  • Upgraded 1-1/4 inch shock absorbent feet for vibration control
  • 8.8 grade bolts used in foldable brackets to increase reliability
  • See More Details

Frequently Bought Together

+
+
Price:
$8592

Product Overview

This mounting bracket is made of white powder coated steel and features upgraded equipment mounts, sometimes referred to as "feet". The upgraded feet are 1-1/4 in. tall with built-in vibration control and shock absorbers which have a positive impact on the long term operation of the condenser. This bracket is a good choice when a white finish is desired over stainless steel but coastal and harsh and/or extreme weather environmental concerns are a factor in the purchasing decision. The mounting bracket's design begins with an adjustable cross bar that attaches to the wall. Since it is adjustable, this again, is another upgraded feature and takes the guess work out of what size bracket to purchase for various Mini Split BTU sizes. This superior mounting bracket is super strong and ideal for most Mini Split units up to 36,000 BTU's as long as the weight does not exceed 300 lbs. 2 L-shaped brackets are hooked and bolted to the crossbar where the condenser is then mounted and secured. Many consumers and HVAC technicians prefer the use of mounting brackets verse ground pads for condenser installations for their placement versatility especially when the installation is on the second level or higher.
  • California residents
  • Adjustable to fit 9,000 BTU - 36,000 BTU units with a maximum weight capacity of 300 lbs.
  • Powder coated hardened steel
  • Hardware included for attaching the condenser and expansion bolts to the wall mounting
  • Built-in vibration control and shock absorbers
  • Adjustable backstop
  • Ideal solution for mounting mini split condensers above ground on multi-level buildings
  • Provides more protection from ground level debris, heavy rains and floods, vandalism, etc. than ground pads

Info & Guides

You will need Adobe® Acrobat® Reader to view PDF documents. Download a free copy from the Adobe Web site.

Compare Similar Mini Split Parts

Folding Mounting Bracket for Mini Split Unit with Leveler
current product
9000 - 36000 BTU Outdoor Wall Mounting Bracket for Ductless Mini Split Air Conditioners and Heat Pumps
Copper Piping Kit for Mini Split Installation 3/8 in. - 5/8 in., 10 ft.Aspen Mini White 115/208-230-Volt Condensate Pump for Ductless Mini-Split Indoor Units Up to 2-1/2 Tons
BrandPioneerDuctlessAirePioneerRectorSeal
NameFolding Mounting Bracket for Mini Split Unit with Leveler9000 - 36000 BTU Outdoor Wall Mounting Bracket for Ductless Mini Split Air Conditioners and Heat PumpsCopper Piping Kit for Mini Split Installation 3/8 in. - 5/8 in., 10 ft.Aspen Mini White 115/208-230-Volt Condensate Pump for Ductless Mini-Split Indoor Units Up to 2-1/2 Tons
Price
$3999
/box
$8592
$8800
/inch
$15843
Ratings
(0)
(295)
(1)
(2)
Mini Split Accessory/Part TypeMini Split Mounting Hardware & PartsMini Split Mounting Hardware & PartsMini Split Line SetsMini Split Pumps
Part TypeBracketBracket Pump
View ProductView ProductView ProductView Product

Specifications

Dimensions

Product Depth (in.)
22
Product Height (in.)
18
Product Width (in.)
2

Details

Color
White
Color Family
White
Mini Split Accessory/Part Type
Mini Split Mounting Hardware & Parts
Part Type
Bracket
Product Weight (lb.)
10
Returnable
180-Day

Warranty / Certifications

Manufacturer Warranty
None

Questions & Answers

22Questions72Answers

The instructions for this bracket say to install 3 bolts into each arm. With the legs on my cond...

Asked by FL12345 September 14, 2018
10
Answers

Install the shelf first!!

does the condenser attach to the bracket with bolts to secure it or just sit atop it?

Asked by Bailey August 4, 2018
10
Answers

Bolts

I have a shed. Can I mount this bracket into the studs?

Asked by Bo July 24, 2018
10
Answers

I don't see why you couldn't as long as you use proper screws.

I want to put an outside Coleman 48 qt cooler on the wall inside my house, will this work?

Asked by Carter September 28, 2018
9
Answers

That would be using the bracket in a way that it was not intended to be used. However, it may work well but keep in mind that water weighs 62 pounds per cubic foot so measure the inside of the cooler and calculate the number of cubic feet. use a measuring tape and measure the height x length x width. Multiply those three together and find out the number of cubic inches in the cooler. There are 1728 cubic inches in a cubic foot. if it is more than 2 ft.³ I don’t think I would use it.

I see half put these close to the ground and half put these near the roofline. Are there reasons...

Asked by MasterGardener January 18, 2020
7
Answers

Since your copper gas lines want to be a minimum of 10 feet (more is better), mount this where you will accommodate that spec and, if possible, keep it out of direct sun but let it get some rain on it (keep the dust off the cooling fins). Really doesn't matter if it's high or low.

What are the mesurments for this mount

Asked by TCT March 9, 2018
6
Answers

30" x 16"

Can this be couples qirh another interior init?

Asked by Pattycakes January 11, 2017
5
Answers

Explain "another unit?" This a 15 - 20 minute effort at best to install the brackets.

Would this work with a mitsibishi unit?

Asked by Aaron July 5, 2018
5
Answers

It's fully adjustable and will work with any unit.

Order On Line?

Asked by Me December 9, 2015
5
Answers

Yes

Whats the best way to mount this to double 4 vinyl siding? Any pics would be helpful as well.

Asked by Aaron July 13, 2018
5
Answers

Yes, but you have to find studs inside wall and secure the bracket on studs.

9000 - 36000 BTU Outdoor Wall Mounting Bracket for Ductless Mini Split Air Conditioners and Heat Pumps - page 2

Customer Reviews

  • 295 Customer Reviews
  • 4.5 out of 5 stars overall
90% of customers recommended.
Overall Ratings
5star-icon(205)
4star-icon(55)
3star-icon(13)
2star-icon(11)
1star-icon(11)
Sort By:
Rating provided by a verified purchaser...
Rating provided by a verified purchaser
Was this helpful?
1
0
Not 90 Degrees, way off. Cut off and re-drill holes to square are up.
Quality :
1
Value :
1
Defective design, does not open even close to 90 degrees, way off. Leans AC into the wall at the top. It takes a few hours to cut off the ends, square up and drill new holes, go get 8 new short 5/16 bolts and nuts and washers, paint the cut parts and drilled holes a couple of times and reassemble. After you square up the bracket it is usable.
Was this helpful?
1
0
Great build quality, worth the extra money from cheaper mounts
Quality :
4
Value :
5
Used on a Bosch 24k BTU unit that weighs 130lbs. With the arms mounted into the studs, has no problem supporting this weight. Good build quality and very sturdy. Just be sure to get the dimensions of the base mounting holes of your outside unit. Very likely they are not 16 or 32 inches wide like your studs in the wall are, meaning your arms won't be either. Had to make modifications with pressure treated wood for a base, but I expected this based on prior research.
Was this helpful?
0
0
Simple to install and handles the weight of my Mr. Cool AC unit, no problem.
Quality :
5
Value :
5
Simple to install and handles the weight of my Mr. Cool AC unit, no problem.
Was this helpful?
1
0
I purchased the 18,000 BTU unit and it was not difficult at all to install. It is a wonderful un...
Quality :
5
Value :
5
I purchased the 18,000 BTU unit and it was not difficult at all to install. It is a wonderful unit. I put in in my garage because that is where my Treadmill is located and I could not use it in a closed garage in 100 degree heat. Now my garage is nice and cool. It works wonderfully and you can't even hear it running. It was the best money I have spent since I purchased my new home. And I am sure it has added value to my home as well. I would definitely recommend this unit it is well worth the money.
Was this helpful?
2
0
The rubber isolators bottom bolt pulled out on two of the four, very easily. Ended up having to ...
The rubber isolators bottom bolt pulled out on two of the four, very easily. Ended up having to go another route to mount the unit to the brackets. The metal portion of the brackets worked very well though.
Was this helpful?
2
0
DYI'd installing a mini-split and chose this DuctlessAire bracket for the outside unit. Easy to ...
Quality :
5
Value :
5
DYI'd installing a mini-split and chose this DuctlessAire bracket for the outside unit. Easy to follow the instructions, very sturdy and looks great. The rubber bushings are doing a good job, there is no noise transfer coming through the 2x4 stud wall. Very please with how it looks and holds the unit.
Was this helpful?
1
0
Excellent perfect off the ground for winter months
Excellent perfect off the ground for winter months
Was this helpful?
0
0
LOVE THIS PRODUCT. EASY TO INSTALL, VERY STURDY AND VERY STRONG METAL AS A WOMAN I COULD IT INST...
Quality :
5
Value :
5
LOVE THIS PRODUCT. EASY TO INSTALL, VERY STURDY AND VERY STRONG METAL AS A WOMAN I COULD IT INSTALL IT ON MY OWN, AND NO EXPERIENCE NEED IT
Was this helpful?
0
0
This bracket worked perfectly for our DuctlessAire 12,000 btu mini split. There is no vibration ...
This bracket worked perfectly for our DuctlessAire 12,000 btu mini split. There is no vibration noice at all in the garage when the unit is running which apparently can be a problem sometimes.
Was this helpful?
0
0
