Internet # 205958076

Model # EZA555-HB

Textured Black Aluminum Hand Rail Adjustable Angle

$66.96
Apply Now
Pay $41.96 after $25 OFF your total qualifying purchase upon opening a new card. info
Apply for a Home Depot Consumer Card
  • Efficiently connects any two 1.9 in. round handrails
  • Made of aluminum alloy for enhanced strength
  • Can be easily installed without splices
  • View More Details
icon
Free & Easy Returns In Store or Online
Return this item within 90 days of purchase. Read Return Policy

Product Details

About This Product

The EZ Adjustable Angle connects any two 1.9 in. round handrails together for stair to landing transitions and sloped pathways. It requires support on both sides of the connection from EZ wall brackets. No splices are required when installing this fitting.

Highlights

  • Connects sloped to level handrails
  • Meets 2010 ADA standards for accessible design
  • 100% Aluminum alloy for superior strength
  • Compatible with all EZ Handrails and components
  • Made in USA, custom powder coat colors available through your local Home Depot Pro Desk
  • Return Policy

Product Information

Internet # 205958076

Model # EZA555-HB

Specifications

Dimensions: H 2 in, W 6 in, D 2 in

Dimensions

Product Depth (in.)

2 in

Product Height (in.)

2 in

Product Width (in.)

6 in

Details

Color Family

Black

Color/Finish

Textured Black

Features

Paintable

Fitting Type

Adjustable Elbow

Indoor/Outdoor

Indoor, Outdoor

Material

Aluminum

Product Weight (lb.)

1 lb

Returnable

90-Day

Warranty / Certifications

Certifications and Listings

ADA Compliant

Questions & Answers

6Questions
caret
Q:How adjustable is the angle on that device? Thanks. I want to use it to change the rail orientation to follow my curved pathway.. thanks
by|May 11, 2021
1 Answer
Answer This Question

A:  Hi Gerard. The Adjustable Angle has 90 degrees movement; 45 degrees either side of straight. It will not rotate to a complete 90 degree turn. Thank you for the great question as I don't think its been asked in the last 7 years. Dan H. (EZ Handrail Dev. Team).

by|May 13, 2021
    caret
    Q:The angle is a loose fit on the rail end and it looks like additional hardware is required to fasten each end of the rails
    by|Oct 1, 2020
    1 Answer
    Answer This Question

    A:  Hi Bob. I highly recommend using Permatex Steel Weld Epoxy or Locktite Metal and Concrete Epoxy or Gorilla Weld on each end of the adjustable angle. All three of these epoxies are quick setting (10 min avg.) and easy to work with. The Permatex is the most substantial and creates the "gap" bond between the draft at the end of the adjustable angle to the round pipe handrail; which is how this product was originally designed. Alternatively, in the past 15+ years of this products life, there are thousands of mechanical fasteners that installers have used that meet code and are still aesthetically pleasing: tapping in a set screw, drilling 1/8" hole and inserting a spring or roll pin, or simply screwing in a round headed metal screw. Of all mechanical solutions my favorite is the roll/spring pin (use 2 or 3 per end). If any of this very technical answer needs further explanation, please email us at support@ezhandrail.com. Thank you for the great question. Dan H. (EZ Handrail Dev. Team)

    by|Oct 1, 2020
      caret
      Q:Is there any way this adjustable angle can be mounted into a concrete wall?
      by|Jul 31, 2020
      1 Answer
      Answer This Question

      A:  Hi Jessica. I'm sure there is but I think I might have a better solution for you. We rolled out a new 1.9" Round Adjustable Wall Mount Bracket that has a flat plate you can fasten to your concrete wall with Tapcons or sleeve anchors and it has a round female handrail receiver that pivots up and down or side to side. Unfortunately this bracket is not on homedepot.com (7/31/20) yet, but is available simply by emailing support@ezhandrail.com and we can ship to your local store. I expect this bracket to be online in late September. Thank you for your timely question! Dan H. (EZ Handrail Dev. Team)

      by|Aug 1, 2020
        caret
        Q:Will this slip inside a 1 1/4" or 1 1/2" schedule 40 steel pipe?
        by|Jul 30, 2020
        1 Answer
        Answer This Question

        A:  Hi Race. No, it is 1.9" (1 7/8" approx.) OD. Thank you for your question. Dan H. (EZ Handrail Dev. Team)

        by|Jul 30, 2020
          Showing 1-4 of 6
