GE

PowerMark Gold 125 Amp 8-Space 16-Circuit Outdoor Main Lug Circuit Breaker Panel

  • Outdoor NEMA 3R enclosure
  • Main lugs are factory installed; convertible to main breaker
  • Use with equipment ground kit TGK12 (order separately)
$ 46 00
Loading Options
store icon Loading Buying Options...
package icon Loading Buying Options...
Sorry, but we ran into issues loading these options. Please try refreshing.

Frequently Bought Together

Frequently Bought Together

+
+

Product Overview

  • Outdoor NEMA 3R enclosure
  • Main lugs are factory installed; convertible to main breaker
  • Use with equipment ground kit TGK12 (order separately)
The load center includes a sturdy tin-plated copper buss bar and a galvanized box for increased durability and reliability. The one-piece interior removes and re-installs easily. Outdoor NEMA 3R enclosure. This load center is UL listed and ANSI Certified.
  • Use as an outdoor main lug load center or convert to a main breaker
  • Galvanized box for rust resistance with a self-adjusting, dead-front cover
  • Copper buss for excellent conductivity
  • Full-length neutral bars for faster and easier wiring
  • 100% split neutral holes on each side are rated for #14-4 wire
  • Top or bottom feed
  • Single phase
  • 3 wire
  • 120/240-Volt
  • 22,000 AIR
  • Compatible with GFCI, AFCI and standard GE circuit breakers
  • ANSI certified and UL listed
  • Closure caps included, hubs ordered separately
  • Learn More About Electrical Panels Here in our Buying Guide.






  • Click here for more information on Electronic Recycling Programs

Product Overview

  • Outdoor NEMA 3R enclosure
  • Main lugs are factory installed; convertible to main breaker
  • Use with equipment ground kit TGK12 (order separately)
Model #: TLM812RCUP
Sku #: 301515
Internet #: 202046230

The load center includes a sturdy tin-plated copper buss bar and a galvanized box for increased durability and reliability. The one-piece interior removes and re-installs easily. Outdoor NEMA 3R enclosure. This load center is UL listed and ANSI Certified.

  • Use as an outdoor main lug load center or convert to a main breaker
  • Galvanized box for rust resistance with a self-adjusting, dead-front cover
  • Copper buss for excellent conductivity
  • Full-length neutral bars for faster and easier wiring
  • 100% split neutral holes on each side are rated for #14-4 wire
  • Top or bottom feed
  • Single phase
  • 3 wire
  • 120/240-Volt
  • 22,000 AIR
  • Compatible with GFCI, AFCI and standard GE circuit breakers
  • ANSI certified and UL listed
  • Closure caps included, hubs ordered separately
  • Learn More About Electrical Panels Here in our Buying Guide.






  • Click here for more information on Electronic Recycling Programs

Info & Guides

You will need Adobe® Acrobat® Reader to view PDF documents. Download a free copy from the Adobe Web site.

Key Features

Product Overview
Key Features
  • Outdoor NEMA 3R enclosure
  • Main lugs are factory installed; convertible to main breaker
  • Use with equipment ground kit TGK12 (order separately)
The load center includes a sturdy tin-plated copper buss bar and a galvanized box for increased durability and reliability. The one-piece interior removes and re-installs easily. Outdoor NEMA 3R enclosure. This load center is UL listed and ANSI Certified.
  • Use as an outdoor main lug load center or convert to a main breaker
  • Galvanized box for rust resistance with a self-adjusting, dead-front cover
  • Copper buss for excellent conductivity
  • Full-length neutral bars for faster and easier wiring
  • 100% split neutral holes on each side are rated for #14-4 wire
  • Top or bottom feed
  • Single phase
  • 3 wire
  • 120/240-Volt
  • 22,000 AIR
  • Compatible with GFCI, AFCI and standard GE circuit breakers
  • ANSI certified and UL listed
  • Closure caps included, hubs ordered separately
  • Learn More About Electrical Panels Here in our Buying Guide.






  • Click here for more information on Electronic Recycling Programs

Product Overview

  • Outdoor NEMA 3R enclosure
  • Main lugs are factory installed; convertible to main breaker
  • Use with equipment ground kit TGK12 (order separately)
Model #: TLM812RCUP
Sku #: 301515
Internet #: 202046230

The load center includes a sturdy tin-plated copper buss bar and a galvanized box for increased durability and reliability. The one-piece interior removes and re-installs easily. Outdoor NEMA 3R enclosure. This load center is UL listed and ANSI Certified.

  • Use as an outdoor main lug load center or convert to a main breaker
  • Galvanized box for rust resistance with a self-adjusting, dead-front cover
  • Copper buss for excellent conductivity
  • Full-length neutral bars for faster and easier wiring
  • 100% split neutral holes on each side are rated for #14-4 wire
  • Top or bottom feed
  • Single phase
  • 3 wire
  • 120/240-Volt
  • 22,000 AIR
  • Compatible with GFCI, AFCI and standard GE circuit breakers
  • ANSI certified and UL listed
  • Closure caps included, hubs ordered separately
  • Learn More About Electrical Panels Here in our Buying Guide.






  • Click here for more information on Electronic Recycling Programs

Info & Guides

You will need Adobe® Acrobat® Reader to view PDF documents. Download a free copy from the Adobe Web site.

Compare Similar

Compare Similar Products
Brand GE GE GE GE
Name PowerMark Gold 125 Amp 4-Space 8-Circuit Outdoor Main Lug Circuit Breaker Panel PowerMark Gold 125 Amp 8-Space 16-Circuit Indoor Main Lug Circuit Breaker Panel PowerMark Gold 125 Amp 4-Space 8-Circuit Outdoor Single-Phase Main Lug Circuit Breaker Panel PowerMark Gold 125 Amp 8-Space 16-Circuit Outdoor Main Lug Circuit Breaker Panel
Price
$34.48
$34.58
$34.99
$46.00
Ratings (14) (11) (18) (13)
Indoor/Outdoor Outdoor Indoor Outdoor Outdoor
Number of Phases 1 1 1 1
Mounting type Plug In Plug In Plug In Plug In
Maximum Amperage (amps) 125 125 125 125
Number of Spaces 4 8 4 8
View Product View Product View Product View Product

Specifications

Dimensions

Load center depth (in.)
4.2
Load center height (in.)
11.11
Load center width (in.)
11.58

Details

Electrical Product Type
Main Lug/ Main Lug Kit
Indoor/Outdoor
Outdoor
Load Center Type
Main Lug
Maximum Amperage (amps)
125
Mounting type
Plug In
Number of Phases
1
Number of Spaces
8
Product Weight (lb.)
10lb
Returnable
90-Day
Voltage (volts)
240

Warranty / Certifications

Certifications and Listings
1-UL Listed
Manufacturer Warranty
One year warranty from first use

Specifications

Dimensions

Load center depth (in.)
4.2
Load center height (in.)
11.11
Load center width (in.)
11.58

Details

Electrical Product Type
Main Lug/ Main Lug Kit
Indoor/Outdoor
Outdoor
Load Center Type
Main Lug
Maximum Amperage (amps)
125
Mounting type
Plug In
Number of Phases
1
Number of Spaces
8
Product Weight (lb.)
10lb
Returnable
90-Day
Voltage (volts)
240

Warranty / Certifications

Certifications and Listings
1-UL Listed
Manufacturer Warranty
One year warranty from first use

Questions & Answers

Can you bring power in from the bottom of panel

Asked by: Lynn
Yes, you can feed the power in from the bottom of the panel.
Answered by: CommunityAnswer
Date published: 2018-03-27

What awg al wire will this handle?

What awg al wire will this handle?
Asked by: swatj15
Thank you for your question. The TLM812RCUP lugs will accomodate #6 to #1 al wire.
Answered by: MCoffman
Date published: 2019-05-16

When feeding wire from bottom do you rotate the broad, rotate the box, or loop the wire.

When feeding wire from bottom do you rotate the broad, rotate the box, or loop the wire.
Asked by: shelter
Good morning and thanks for the question. Typically the wire enters from bottom and run up the side to the lugs at the top. I don’t understand what your terminology of “broad” means and you would not rotate the box as it is rated Nema 3R for outdoor use in up right position only. As always local electrical codes apply and if you are unsure please consult with a local liscensed contractor tow confirm. Thanks and good luck.
Answered by: JE
Date published: 2018-11-21

What are the dimension of this panel

What are the dimension of this panel
Asked by: Cliff
The dimensions are: Load center depth (in.) 3.25 Load center height (in.) 11.125 Load center width (in.) 11.25
Answered by: CommunityAnswer
Date published: 2018-07-29
  • y_2019, m_9, d_15, h_1CST
  • bvseo_bulk, prod_bvqa, vn_bulk_2.0.13
  • cp_1, bvpage1
  • co_hasquestionsanswers, tq_6
  • loc_, sid_202046230, prod, sort_[SortEntry(order=NUM_ANSWERS, direction=DESCENDING), SortEntry(order=SUBMISSION_TIME, direction=DESCENDING), SortEntry(order=LAST_APPROVED_ANSWER_SUBMISSION_TIME, direction=DESCENDING), SortEntry(order=LAST_APPROVED_ANSWER_SUBMISSION_TIME, direction=DESCENDING), SortEntry(order=BEST_ANSWER_FEEDBACK_COUNT, direction=DESCENDING), SortEntry(order=POSITIVE_ANSWER_FEEDBACK_COUNT, direction=DESCENDING), SortEntry(order=NUM_ANSWERS, direction=DESCENDING)]
  • clientName_homedepot
  • bvseo_sdk, java_sdk, bvseo-3.1.1
  • CLOUD, getContent, 4ms
  • QUESTIONS, PRODUCT

Customer Reviews

PowerMark Gold 125 Amp 8-Space 16-Circuit Outdoor Main Lug Circuit Breaker Panel is rated 4.7 out of 5 by 13.
Rated 5 out of 5 by from 5 Star Review Rating provided by a verified purchaser
Date published: 2019-07-31
Rated 5 out of 5 by from Great panel. GE is the best... Great panel. GE is the best
Date published: 2019-09-03
Rated 4 out of 5 by from Good quality Good quality
Date published: 2019-08-27
Rated 4 out of 5 by from Nice little outdoor box Nice little outdoor box. I bought two, one for a pavilion (outdoor kitchen), the other for the pool hook-ups. The knock-outs were neither plentiful nor in the right places for me, but it was not a problem drilling out what I needed. I went in with some pretty heavy service cable, so it was tight working in the box. Very pleased overall with the outcome.
Date published: 2012-07-24
Rated 5 out of 5 by from Great Weather Proof Sub Panel Never really used GE panels/sub panels. I was amazed at the quality of their product. I usually use QO panels but was forced into using this brand because of existing gfci breakers it was cheaper to use same GE brand. Once I started the install I was blown away by the quality and I have been an Electrician for 21 years.
Date published: 2011-09-15
Rated 5 out of 5 by from Very good... Very good
Date published: 2019-04-19
Rated 5 out of 5 by from Just the one I needed for split load between a small shop and water well room. Just the one I needed for split load between a small shop and water well room.
Date published: 2019-02-19
Rated 5 out of 5 by from 5 Star Review Rating provided by a verified purchaser
Date published: 2019-02-06
