Internet #100195700

Model #TLM1220RCUP

Store SKU #237433

PowerMark Gold 200 Amp 12-Space 24-Circuit Outdoor Main Lug Circuit Breaker Panel

  • Outdoor NEMA 3R enclosure
  • Main lugs are factory installed; convertible to main breaker
  • Use with equipment ground kit TGK24 (order separately)
  • See More Details

Frequently Bought Together

+
+
Price:
$6926

Product Overview

The load center includes a sturdy tin-plated copper buss bar and a galvanized box for increased durability and reliability. The one-piece interior removes and re-installs easily. Outdoor NEMA 3R enclosure. This load center is UL listed and ANSI Certified.

Info & Guides

You will need Adobe® Acrobat® Reader to view PDF documents. Download a free copy from the Adobe Web site.

Compare Similar Individual Subpanels

current product
PowerMark Gold 200 Amp 12-Space 24-Circuit Outdoor Main Lug Circuit Breaker Panel
200 Amp 20-Space 40-Circuit Main Lug Load CenterQO 200 Amp 30-Space 40-Circuit Indoor Main Lug Plug-On Neutral Load Center with Cover, Ground BarPowerMark Gold 200 Amp 30-Space 30-Circuit 3-Phase Indoor Main Lug Circuit Breaker Panel
BrandGEMurraySquare DGE
NamePowerMark Gold 200 Amp 12-Space 24-Circuit Outdoor Main Lug Circuit Breaker Panel200 Amp 20-Space 40-Circuit Main Lug Load CenterQO 200 Amp 30-Space 40-Circuit Indoor Main Lug Plug-On Neutral Load Center with Cover, Ground BarPowerMark Gold 200 Amp 30-Space 30-Circuit 3-Phase Indoor Main Lug Circuit Breaker Panel
Price
$6926
$9341
$11252
$17909
Ratings
(92)
(30)
(71)
(9)
Maximum Amperage (amps)200200200200
Indoor/OutdoorOutdoorIndoorIndoorIndoor
Number of Spaces12203030
Mounting TypePlug-OnBolt OnPlug-On NeutralPlug-On
Number of Circuits24403030
Load Center TypeMain LugMain LugMain LugMain Lug
Load center width (in.)1315.814.2514.38
Load center height (in.)296.029.8633.32
View ProductView ProductView ProductView Product

Specifications

Dimensions

Load center depth (in.)
5
Load center height (in.)
29
Load center width (in.)
13

Details

Electrical Product Type
Main Lug/ Main Lug Kit
Indoor/Outdoor
Outdoor
Load Center Mounting Type
Surface
Load Center Type
Main Lug
Maximum Amperage (amps)
200
Mounting Type
Plug-On
Number of Circuits
24
Number of Spaces
12
Phase Type
1 Phase
Product Weight (lb.)
26
Returnable
180-Day
Voltage (volts)
240

Warranty / Certifications

Certifications and Listings
UL Listed
Manufacturer Warranty
One year warranty from first use

Questions & Answers

54Questions10Answers

What size wire do I run from main panel to 70 amp sub panel

Asked by Rodrig January 19, 2021
2
Answers

I would encourage you to look up an ampacity chart readily available online to confirm your individual situation. If using romex or UF cable #4 would carry 70 amps under normal conditions. The temperature and length of run may change that so please confer with a qualified electrician or professional engineer to confirm. Thanks for the question.

Can I use a 40 amp 2-pole breaker (240 v) in this panel?

Asked by Peggy September 22, 2020
1
Answer

Thank you for your question. Yes, the TL270RCUP will accept 2pole 40a breakers THQL2140 or THQP240.

is it common for a panel to fail?

Asked by jer September 5, 2020
2
Answers

This is not a sub-panel, It is a Disconnect box for that purpose only. Used in HVAC mostly. Once is awhile they fail. ! out of 10,000.

Where can i order the 125 amp main breaker?

Asked by Mark July 28, 2020
0
Answers

what is the wire range for the Main Lugs supplied?

Asked by brendan June 26, 2020
1
Answer

Thank you for your question. The TL270RCUP main lugs accept #6 to #3 AWG wire.

is this panel have one ground terminal and one neutral terminal bars?

Asked by Mil May 11, 2020
1
Answer

Thank you for your question. It includes one. A TGK4CP equipment ground bar can be added to separate.

Can I the aluminium wire as the main feed?

Asked by Simples April 23, 2020
1
Answer

Thank you for your question. Yes, the TLM1220RCU is rated to receive CU and AL wire 6 AWG to 250 kcmil.

Will main lugs support 2/0 wire?

Asked by Michelle April 13, 2020
1
Answer

Thank you for your question. Yes, the TLM1212RCU main lugs will accept 6 to 2/0 AWG wire.

Can I bring power in through the side using 2/0 copper?

Asked by Cdbro March 23, 2020
0
Answers

What are the dimensions of this box?

Asked by lloyd February 12, 2020
1
Answer

Its dimensions are; Load center depth (in.) 3.98 Load center height (in.) 13.2 Load center width (in.) 7.71
