Internet #206424479

Model # 6864

Store SO SKU #1001535218

0696471068641

Generac

5,000-Watt Diesel Powered Electric Start Portable Generator

  • Efficient diesel power requires less maintenance and long life
  • Provides a long run time of 32.4 hours at 1/2 load
  • 5500 starting watts and 5000 running watts.
$ 3,799 00
store icon Loading Buying Options...
package icon Loading Buying Options...
Sorry, but we ran into issues loading these options. Please try refreshing.

Frequently Bought Together

Frequently Bought Together

Product Overview

  • Efficient diesel power requires less maintenance and long life
  • Provides a long run time of 32.4 hours at 1/2 load
  • 5500 starting watts and 5000 running watts.
If you’ve got a tough job to do, look no further than the XD5000E generator. The sturdy steel frame features an integrated lifting eye for easy transport and on-site security. True Power Technology provides less than 6% total harmonic distortion for smooth operation of tools, appliances, even sensitive electronics. And it’s engineered to keep running, thanks to a large fuel tank and idle control.
  • Diesel power requires less maintenance, is more efficient and provides a long life
  • Yanmar LW series 435cc air-cooled direct injection, industrial-grade diesel engine
  • Truepower technology provides less than 6% total harmonic distortion for clean, smooth operation of sensitive electronics, tools and appliances
  • Large-capacity 12 Gal. fuel tank with fuel gauge provides a long run-time of 32.4 hours at 50% load
  • Idle control conserves fuel and reduces noise
  • Low oil shutdown automatically safeguards engine from damage
  • Durable, fully welded 1-1/4 in. steel frame
  • Integrated lifting eye provides easy transport and security on the job site
  • 120/240 selector switch provides full 120-Volt power
  • Single touch electric start provides hassle-free start-up, battery not included
  • Hour meter with maintenance resets, tracks usage and monitors maintenance cycles



Product Overview

  • Efficient diesel power requires less maintenance and long life
  • Provides a long run time of 32.4 hours at 1/2 load
  • 5500 starting watts and 5000 running watts.
Model #: 6864
Internet #: 206424479

If you’ve got a tough job to do, look no further than the XD5000E generator. The sturdy steel frame features an integrated lifting eye for easy transport and on-site security. True Power Technology provides less than 6% total harmonic distortion for smooth operation of tools, appliances, even sensitive electronics. And it’s engineered to keep running, thanks to a large fuel tank and idle control.

  • Diesel power requires less maintenance, is more efficient and provides a long life
  • Yanmar LW series 435cc air-cooled direct injection, industrial-grade diesel engine
  • Truepower technology provides less than 6% total harmonic distortion for clean, smooth operation of sensitive electronics, tools and appliances
  • Large-capacity 12 Gal. fuel tank with fuel gauge provides a long run-time of 32.4 hours at 50% load
  • Idle control conserves fuel and reduces noise
  • Low oil shutdown automatically safeguards engine from damage
  • Durable, fully welded 1-1/4 in. steel frame
  • Integrated lifting eye provides easy transport and security on the job site
  • 120/240 selector switch provides full 120-Volt power
  • Single touch electric start provides hassle-free start-up, battery not included
  • Hour meter with maintenance resets, tracks usage and monitors maintenance cycles



Info & Guides

You will need Adobe® Acrobat® Reader to view PDF documents. Download a free copy from the Adobe Web site.

Key Features

Product Overview
Key Features
  • Efficient diesel power requires less maintenance and long life
  • Provides a long run time of 32.4 hours at 1/2 load
  • 5500 starting watts and 5000 running watts.
If you’ve got a tough job to do, look no further than the XD5000E generator. The sturdy steel frame features an integrated lifting eye for easy transport and on-site security. True Power Technology provides less than 6% total harmonic distortion for smooth operation of tools, appliances, even sensitive electronics. And it’s engineered to keep running, thanks to a large fuel tank and idle control.
  • Diesel power requires less maintenance, is more efficient and provides a long life
  • Yanmar LW series 435cc air-cooled direct injection, industrial-grade diesel engine
  • Truepower technology provides less than 6% total harmonic distortion for clean, smooth operation of sensitive electronics, tools and appliances
  • Large-capacity 12 Gal. fuel tank with fuel gauge provides a long run-time of 32.4 hours at 50% load
  • Idle control conserves fuel and reduces noise
  • Low oil shutdown automatically safeguards engine from damage
  • Durable, fully welded 1-1/4 in. steel frame
  • Integrated lifting eye provides easy transport and security on the job site
  • 120/240 selector switch provides full 120-Volt power
  • Single touch electric start provides hassle-free start-up, battery not included
  • Hour meter with maintenance resets, tracks usage and monitors maintenance cycles



Product Overview

  • Efficient diesel power requires less maintenance and long life
  • Provides a long run time of 32.4 hours at 1/2 load
  • 5500 starting watts and 5000 running watts.
Model #: 6864
Internet #: 206424479

If you’ve got a tough job to do, look no further than the XD5000E generator. The sturdy steel frame features an integrated lifting eye for easy transport and on-site security. True Power Technology provides less than 6% total harmonic distortion for smooth operation of tools, appliances, even sensitive electronics. And it’s engineered to keep running, thanks to a large fuel tank and idle control.

  • Diesel power requires less maintenance, is more efficient and provides a long life
  • Yanmar LW series 435cc air-cooled direct injection, industrial-grade diesel engine
  • Truepower technology provides less than 6% total harmonic distortion for clean, smooth operation of sensitive electronics, tools and appliances
  • Large-capacity 12 Gal. fuel tank with fuel gauge provides a long run-time of 32.4 hours at 50% load
  • Idle control conserves fuel and reduces noise
  • Low oil shutdown automatically safeguards engine from damage
  • Durable, fully welded 1-1/4 in. steel frame
  • Integrated lifting eye provides easy transport and security on the job site
  • 120/240 selector switch provides full 120-Volt power
  • Single touch electric start provides hassle-free start-up, battery not included
  • Hour meter with maintenance resets, tracks usage and monitors maintenance cycles



Info & Guides

You will need Adobe® Acrobat® Reader to view PDF documents. Download a free copy from the Adobe Web site.

Compare Similar

Compare Similar Products
Brand Generac Generac Generac Generac
Name 1,800-Watt Gasoline Powered Portable Generator 5,500-Watt Gasoline Powered Portable Generator 17,500-Watt Gasoline Powered Electric Start Portable Generator 5,000-Watt Diesel Powered Electric Start Portable Generator
Price
$359.00
$729.00
$2,999.00
$3,799.00
Ratings (30) (1008) (170) (3)
Engine Make OEM Branded OEM Branded OEM Branded OEM Branded
Features Automatic Voltage Regulation,Fuel Gauge,Low Oil Shutdown,Muffler Automatic Voltage Regulation,Built-in Fuel Gauge,Fuel Gauge,Hour Meter,Low Oil Shutdown,Muffler Auto Idle Control,Automatic Voltage Regulation,Fuel Gauge,GFCI Outlet(s),Low Oil Shutdown,Muffler,OSHA Required GFCI Outlets Electric Start,Fuel Gauge,Hour Meter,Low Oil Shutdown
Running Wattage 1800 5500 17500 5000
CA (CARB) Compliant Not CARB Compliant Not CARB Compliant Not CARB Compliant CARB Compliant
View Product View Product View Product View Product

Specifications

Dimensions

Product Height (in.)
25.6
Product Length (in.)
33.1
Product Width (in.)
22.5

Details

Application
Home Standby,Job Site,Recreation
CA (CARB) Compliant
CARB Compliant
Color Family
Orange
Engine Displacement (cc)
435
Engine Make
OEM Branded
Features
Electric Start,Fuel Gauge,Hour Meter,Low Oil Shutdown
Fuel Tank Capacity (gallons)
12
Full load fuel consumption (gallons/hour)
16.2
Horsepower (hp)
13.38
Included
Engine Lubricant
Number of circuits/outlets
4
Operational Volume (dB)
0
Outlet Type
120V 20A,240V 30A
Power Type
Gasoline
Product Weight (lb.)
247lb
Returnable
30-Day
Run time at 50% load (hours/tank or charge)
32.4
Running Wattage
5000
Start Type
Recoil Start
Starting Wattage
5500
Suggested Uses
Battery Charger,Lights,Mobile Devices,Power Tools,Small Appliances

Warranty / Certifications

Manufacturer Warranty
2 year limited warranty

Specifications

Dimensions

Product Height (in.)
25.6
Product Length (in.)
33.1
Product Width (in.)
22.5

Details

Application
Home Standby,Job Site,Recreation
CA (CARB) Compliant
CARB Compliant
Color Family
Orange
Engine Displacement (cc)
435
Engine Make
OEM Branded
Features
Electric Start,Fuel Gauge,Hour Meter,Low Oil Shutdown
Fuel Tank Capacity (gallons)
12
Full load fuel consumption (gallons/hour)
16.2
Horsepower (hp)
13.38
Included
Engine Lubricant
Number of circuits/outlets
4
Operational Volume (dB)
0
Outlet Type
120V 20A,240V 30A
Power Type
Gasoline
Product Weight (lb.)
247lb
Returnable
30-Day
Run time at 50% load (hours/tank or charge)
32.4
Running Wattage
5000
Start Type
Recoil Start
Starting Wattage
5500
Suggested Uses
Battery Charger,Lights,Mobile Devices,Power Tools,Small Appliances

Warranty / Certifications

Manufacturer Warranty
2 year limited warranty

Questions & Answers

What RPM does this unit operate? I am hoping to find a 1800 RPM unit instead of the 3600 RPM units.

What RPM does this unit operate? I am hoping to find a 1800 RPM unit instead of the 3600 RPM units.
Asked by: Don
This model is 3,600 RPMs.
Answered by: CommunityAnswer
Date published: 2018-12-21

Whats the best price you can give me on this generator by generac.i am a commercial revolving card holder Nateghian prop

Generac diesel 5000watts by generac
Asked by: nateghianproperties
$1200 cash out the back door
Answered by: Buford
Date published: 2016-12-19

is this generator brushless?

Asked by: ricky
Yes, this is a brushless generator
Answered by: Generac
Date published: 2019-05-31

For $3,799, why doesn't this unit utilize an oil filter (it might, but I can't find it in the picture)?

Asked by: NathanInMontana
The Generac portable generator model #6864 does utilize a oil filter part #0L13630202.
Answered by: Generac
Date published: 2019-08-02
  • y_2019, m_8, d_23, h_5CST
  • bvseo_bulk, prod_bvqa, vn_bulk_2.0.13
  • cp_1, bvpage1
  • co_hasquestionsanswers, tq_8
  • loc_, sid_206424479, prod, sort_[SortEntry(order=NUM_ANSWERS, direction=DESCENDING), SortEntry(order=SUBMISSION_TIME, direction=DESCENDING), SortEntry(order=LAST_APPROVED_ANSWER_SUBMISSION_TIME, direction=DESCENDING), SortEntry(order=LAST_APPROVED_ANSWER_SUBMISSION_TIME, direction=DESCENDING), SortEntry(order=BEST_ANSWER_FEEDBACK_COUNT, direction=DESCENDING), SortEntry(order=POSITIVE_ANSWER_FEEDBACK_COUNT, direction=DESCENDING), SortEntry(order=NUM_ANSWERS, direction=DESCENDING)]
  • clientName_homedepot
  • bvseo_sdk, java_sdk, bvseo-3.1.1
  • CLOUD, getContent, 45ms
  • QUESTIONS, PRODUCT

Customer Reviews

5,000-Watt Diesel Powered Electric Start Portable Generator is rated 3.7 out of 5 by 3.
Rated 5 out of 5 by from Great for my Shop I'm using this Generator to run tire shop equipment and so far it is running like a beast. Because I'm running an in-home shop, my excess to 240V is very limited and this generator has made life easier. The generator does not come with wheels but its frame makes moving it easy. I run it about 5-8 hrs a day and I noticed that I'm only filling up once a week because it has a large fuel tank. It also comes with oil. The manual states that the engine automatically shuts down when their's low oil to prevent damage. I have not tried this feature but I'm certain that its an excellent feature especially when dealing with a high volume business as I usually forget to check the oil level. The noise level is moderate when compared to an air compress. I left this generator on the wooden pallet to prevent vibration as I work in a small area. Overall, I'm very satisfied with the quality and power of this generator. I highly recommend it for home use or to use at a small business.
Date published: 2015-10-26
Rated 1 out of 5 by from generac xd5000e diesel generator purchased xd 5000e from homedepot.com.when picking up gen from local home depot,i was informed I had 30days for refund.this time frame started when ordered,not when I received/picked up.lost approx. 8 days on 30 day refund policy. on initial startup everthing fine,however there really is no idle control,engine runs 3600 rpm load or noload.unacceptable for this pricerange. calls to yan mar (engine manufacturer)no help on idle control.call to generac in Wisconsin totally of no help,infact they would not let service tech talk to individual consumers.said only available for dealer questions.owners manual had no exploded parts diagram(no parts),and no mention of advertised idle control.returned item and can never recommend generac.
Date published: 2015-11-21
Rated 5 out of 5 by from Reliability Just finished a 10 state tour delivering HighMont Beef to the western states and the Generac XD-5000-E ran perfectly. We had it in a ventilated stock trailer and fuel consumption was minimal and performance was excellent. I do agree that noise level requires ear protection or a muffler but otherwise this generator did what I hoped it would. It ran four large freezers without fail. Thank you Generac!
Date published: 2017-08-01
