#1 Home Improvement Retailer

Internet #207091957

Model #E5RICAT

Store SKU #1001862472

E26 5 in. Aluminum Recessed Lighting Housing for Remodel Ceiling, Insulation Contact, Air-Tite

  • Simple install, adjustable speed clamps easily lock into ceiling
  • Compatible with a variety of 5 in. recessed light trim styles
  • Remodel can for recessed lighting with limited ceiling access
  • See More Details

Frequently Bought Together

+
+
Price:

Product Overview

Recessed light can designed for use with various trims




Compatible with Various Trims

The design of this recessed can light is suitable for use with a variety of different trims, making it easy to achieve various looks.

Recessed light housing with an Air Tite rated design




Air Tite Rated Design

An Air Tite rated design that prevents the flow of air from the attic to the living space.

Recessed can light designed for fast and easy installation




Designed for Fast and Easy Installation

Clamps make this recessed can light fast and easy to install and lock into place.

The E5RICAT is a compact and efficient recessed remodel housing optimized and listed for EISA compliant tungsten-Halogen lamps, as well as Incandescent, CFL and LED lamps. Housing is suitable for residential or light commercial applications. For installation in insulated ceilings and non-insulated ceilings with airtight code compliant construction. Use with a variety of trims and finishes to create different lighting effects or to match any decor. May be retrofit with compatible Halo LED lighting systems.
  • Can be installed from below the ceiling in home remodel applications, ideal for those who have limited or no access to their ceiling
  • Insulation contact rated: Designed for insulated ceilings where contact is necessary
  • Air-Tite rated design meets restricted air flow code requirements which prevents airflow between attic and living areas and saves on both heating and air conditioning costs
  • Exclusive remodel speed clamps securely lock from 3/8 in. to 2 in. ceilings eliminating the struggle often experienced with recessed housing clips
  • Compatible with a wide variety of 5 inch Recessed light trims but is best with Halo 5071, 5070, 5054, 5051, 5021, 5020, 5016, 5001, 5000 series models
  • Compatible with a wide variety of 5 inch LED retrofit trims but is best with Halo quality RL, RA, SLD, LT, SMD, and ML series models (Bulb free with some having a 45 year LED lifespan)
  • Slide-N-Side Junction Box: connectors allow non-metallic sheathed cable for both U.S. and Canada to be installed without tools
  • High performance E26 Series 5 inch trim options available
  • Socket bracket adjusts lamp to various trim styles and designs
  • Three Quick Connect connectors eliminate the need for separate wire nuts - simply strip supply wires and push in
  • Features an integral thermal protector to guard against misuse of insulation materials and improper lamping



Info & Guides

You will need Adobe® Acrobat® Reader to view PDF documents. Download a free copy from the Adobe Web site.

Compare Similar Recessed Lighting Housings

E26 6 in. Aluminum Recessed Lighting Housing for Remodel Ceiling, Insulation Contact, Air-Tite
current product
E26 5 in. Aluminum Recessed Lighting Housing for Remodel Ceiling, Insulation Contact, Air-Tite
E26 6 in. Aluminum Recessed Lighting Housing for New Construction Shallow Ceiling, Insulation Contact, Air-TiteE26 6 in. Aluminum Recessed Lighting Housing for Remodel Shallow Ceiling, Insulation Contact, Air-Tite
BrandHaloHaloHaloHalo
NameE26 6 in. Aluminum Recessed Lighting Housing for Remodel Ceiling, Insulation Contact, Air-TiteE26 5 in. Aluminum Recessed Lighting Housing for Remodel Ceiling, Insulation Contact, Air-TiteE26 6 in. Aluminum Recessed Lighting Housing for New Construction Shallow Ceiling, Insulation Contact, Air-TiteE26 6 in. Aluminum Recessed Lighting Housing for Remodel Shallow Ceiling, Insulation Contact, Air-Tite
Price
Ratings
(171)
(170)
(13)
(24)
Nominal Lens Aperture Size6 in.5 in.6 in.6 in.
New Construction or RemodelNew ConstructionNew ConstructionRemodelNew Construction
Compatible Bulb TypeCFL,Halogen,LEDLEDLEDCFL,Halogen,LED
FeaturesAir TightAir TightAir TightAir Tight
IC RatingIC RatedIC RatedIC RatedIC Rated
Indoor/OutdoorIndoor,OutdoorIndoor,OutdoorIndoor,OutdoorIndoor,Outdoor
Damp/Wet RatingDamp Rated,Wet RatedDamp Rated,Wet RatedDamp Rated,Wet RatedDamp Rated,Wet Rated
VoltageLine VoltageLine VoltageLine VoltageLine Voltage
Reflector Finish FamilyAluminumAluminumAluminumAluminum
View ProductView ProductView ProductView Product
Recessed light can designed for use with various trims




Compatible with Various Trims

The design of this recessed can light is suitable for use with a variety of different trims, making it easy to achieve various looks.

Recessed light housing with an Air Tite rated design




Air Tite Rated Design

An Air Tite rated design that prevents the flow of air from the attic to the living space.

Recessed can light designed for fast and easy installation




Designed for Fast and Easy Installation

Clamps make this recessed can light fast and easy to install and lock into place.

Specifications

Dimensions

Actual Aperture Width (in.)
5.25
Housing Height (in.)
7.5
Housing Width (in.)
5.75
Maximum Cutout Size (in.)
5.5
Nominal Lens Aperture Size
5 in.

Details

Compatible Bulb Type
LED
Damp/Wet Rating
Damp Rated,Wet Rated
Features
Air Tight
IC Rating
IC Rated
Included
Mounting Brackets
Indoor/Outdoor
Indoor,Outdoor
Maximum Bulb Wattage
75
New Construction or Remodel
New Construction
Number of Housings Included
1
Package Quantity
1
Product Weight (lb.)
1.8 lb
Reflector Finish Family
Aluminum
Returnable
90-Day
Voltage
Line Voltage

Warranty / Certifications

Certifications and Listings
UL Listed,cUL Listed
Manufacturer Warranty
1 year limited

Questions & Answers

27Questions11Answers

What is the hole size for this can. I presently have 5 inch holes in the ceiling??

Asked by Billy April 2, 2021
1
Answer

The ceiling opening is 5-3/4" [146mm].

Does this come with mounting brackets? What makes this “remodeling”?

Asked by Giovanni June 9, 2020
1
Answer

There are two types housings we offer . New construction housing - This type of housing is installed on the roof before ceiling work. Remodel Type - This type of housing is used when there is an existing ceiling and want to install a housing on the existing ceiling.Remodel housing clamps are included with the housing.

what type of eyeball recessed light trim will fit the clamp this housing lite? the eyeball trim d...

Asked by JOHN April 26, 2020
1
Answer

List of compatible eyeball trims for this housing is given on the specification sheet. Please use the below link to specification sheet. https://images.homedepot-static.com/catalog/pdfImages/98/986ab03f-06ba-4611-8769-de60fa2f456a.pdf

I do not like the light from an LED bulb, can I use a halogen or incandescent bulb with this?

Asked by Bulb April 7, 2020
1
Answer

Yes, you could use a non-LED bulb, you would just need to follow the recommendations for compatible bulbs, which I believe is printed on a sticker inside the can if it's not listed in the specs. Compatible bulbs are probably listed on the manufacturers website as well if its not on Home Depot's given specs.

What size hole saw do you get? 6"?

Asked by BulldogAMD December 5, 2019
1
Answer

Please use the below link to Installation sheet which will show hole cutout dimensions for E7RICAT housing (generally 6" housing will need 6-1/4” (15.9cm) hole size) https://images.homedepot-static.com/catalog/pdfImages/fd/fda27485-d587-4699-ba22-049ef175a836.pdf

Is this dimmable?

Asked by Lori November 17, 2019
4
Answers

the can itself is not a dimmable item. but the bulb you put in there, can be. yes. the best way to go now is these retrofit lights. they fit well, they close off the can with the fixture itself, you do not need to buy a trim ring or baffle, the new LED retrofit light is a one piece unit that looks nice and works well. if you buy a dimmable light, it will be dimmable. most of these new retrofit kits are dimmable

Bulb compatibility questions please? Can this work with various bulb types incandescent, LED, hal...

Asked by DP3192 August 31, 2019
1
Answer

Yes, it is compatible with CFL, Halogen, and LED.

Do these work in 8" joist cavity?

Asked by Greg March 19, 2019
0
Answers

Is this suitable for wet location (ie above a tub in bathroom)

Asked by Laurence December 11, 2018
1
Answer

No, this product is not suitable for wet location.

Can this Halo can be used with non Halo trims, such as PROCURU 6" Fresnel Glass Lens with White M...

Asked by Brenda October 8, 2018
0
Answers

E26 5 in. Aluminum Recessed Lighting Housing for Remodel Ceiling, Insulation Contact, Air-Tite - page 2

Customer Reviews

  • 4.5
    out of 170 reviews
  • 85% recommend this product
Filter by:
Showing 1-10 of 170 reviews
Two stars for cheaping out. Bad form Halo for two items. First, there are only two little fins ...
Two stars for cheaping out. Bad form Halo for two items. First, there are only two little fins to hold this in place. Really? You realize that these are going into ceilings right? And ceilings predominantly consist of sheet rock? While working up in the attic attaching the power to these, one of the little wings went through the sheet rock and damaged the ceiling. Thanks alot guys. Right, I should have been more careful, of course. But I have to say it didn't take that much to have it go through. Three would certainly have spread the pressure much more evenly. Come on guys, pick up the game. Now, for number two. The joke you play with the weather stripping isn't funny. Make up your minds. Are you going to put it on the side of the can or on the lip? Half and half doesn't work. The wiring connections worked great for me although I have read some complaining about them. If you are installing a bunch of these, buy the hole saw that has blades and a plastic surround. Home Depot carries the Milwaukee version - just be aware that the 5.5 inch measure isn't 5.5 inches. You'll have to go to the 5.75 to get a big enough hole as it is off. Measure your distances to be sure. My recommendation to use these is tempered by my comments - beware.
by subfam2
great product, easy install!
great product, easy install!
by rpscuztums
This remodel can is great. I used to be a Residential Electrician and remember the old way that y...
This remodel can is great. I used to be a Residential Electrician and remember the old way that you secured the cans. The new design is much easier. 2 screw which turn a tab. Great job Halo. Also the pre wired push in connectors are great as well.
by FormerResElectrician
Streamlined, functional, well designed. Converted a junc box hanging light to a flat can LED in 2...
Streamlined, functional, well designed. Converted a junc box hanging light to a flat can LED in 20 minutes? Completely changed the look of the room.
by HomeDepotCustomer
I purchased these recessed housings to hold my phillips hue smart downlights. The cans were easy...
I purchased these recessed housings to hold my phillips hue smart downlights. The cans were easy to install and fit snugly into their holes that I cut. I was pleased at how easily they mounted into the ceiling and how easy they are to wire. The wires fit snuggly into the housing and are plug and play. Overall, I am quite impressed at the quality and simplicity of these ceiling mounts.
by Eric
1 person found this helpful
Hi Friends This is (without a doubt) the best product to install lights in an existing ceiling. I...
Hi Friends This is (without a doubt) the best product to install lights in an existing ceiling. It's amazing how great they are ... really, a lot of great improvements have been made from earlier versions. After 40 years of electrical work, I can tell you that these are the very best choice for quality and ease of installation. The 5 inch style is best, because it uses the same trim (as 6") in a smaller hole, so you can cover mistakes easier. Make sure you get the LED trims to go with it! Good luck!
by Sparky1110
Excellent product. I just finished installing it and I had no issues. Followed instructions for c...
Excellent product. I just finished installing it and I had no issues. Followed instructions for connections, almost expecting it to fail, cause it seemed too easy, but it didn't! :) I am very pleased with the fit. Some people on the reviews mentioned that you had to cut the hole exact for this to be able to attach and work properly. So I cut the holes exact, not even passing the line I had marked with the template, but it was too tight, so I cut the hole a hair wider ( like setting the blade right on the line), and then it went in nice and snug.. very snug.. So, I would say there is a little room for error here and there, just be careful. Also, I made sure I pushed it tight against the ceiling and held it firmly while tightening the screws, and once I hit some resistance I stopped tightening, let go, and it kept it right in place. Great stuff!!!
by zam
2 people found this helpful
don't follow the template
My template was for a five and a half inch hole and the fixture will not fit in that hole the drawing on this listing shows a 5-3/4" hole and that is more like it i bought twenty three fixtures and they all had instructions for a 5-1/2" hole if it were not for these awsome clips which makes my 3/4" beadboard ceilings possible I would have had a meltdown! I now am a proud owner of some worthless 5-1/2" hole saws and try buying a 5-3/4" hole saw... in the picture is a 5-1/2" inch hole with paper template and the fixture fits ok in the 6" hole
by Steven
There are 4 Home Depots between my house and work so I shop at all 4. ONLY one store carries this...
There are 4 Home Depots between my house and work so I shop at all 4. ONLY one store carries this light. I bought it because of the tabs that hold it down. I love the post production electrical boxes that use them. The tabs on these cans don't pull the lip to the ceiling, the can remains loose . It took me several trips and Finally I had to take the light back into the store to get the right ring which required the removal of screws and adjusting the base to allow the ring to fit then the ring does not fit flush. Finally pulled both back out and made minor adjustments and placed them in the trash. I will replace them with some other brand
by Dyna
I originally bought them to replace two existing can lights. I love the flip out wall grips ( in ...
I originally bought them to replace two existing can lights. I love the flip out wall grips ( in wall sockets) . Neither one pulled upork flush. Had to go to 4 different stories to find the trim rings which did not fit to the ceiling either. Inside of rhetoric rings are hideous and it takes a special 30.00 bulb. It was finally too much so I found the proper place for them. In the trash. I will never buy another HALO product as long as I live.
by Dyna
Showing 1-10 of 170 reviews
