Model # H27ICAT

Internet #202024770

Store SKU #842006

Halo H27 6 in. Aluminum Recessed Lighting Housing for New Construction Shallow Ceiling, Insulation Contact, Air-Tite
0662400605898

Halo

H27 6 in. Aluminum Recessed Lighting Housing for New Construction Shallow Ceiling, Insulation Contact, Air-Tite

  • Adjustable socket for different recessed lamp types and sizes
  • Best with Halo 6 in. recessed can lights and LED retrofits
  • An ideal recessed can for ceilings with very limited space
$1698 /each

Choose Your Options

1
  • 1
  • 6
store icon Loading Buying Options...
package icon Loading Buying Options...
Sorry, but we ran into issues loading these options. Please try refreshing.

Frequently Bought Together

Product Overview

  • Adjustable socket for different recessed lamp types and sizes
  • Best with Halo 6 in. recessed can lights and LED retrofits
  • An ideal recessed can for ceilings with very limited space
The H27ICAT housing is designed for use in shallow ceilings. The wide variety of trims available allows a number of different lighting effects to be created with 1 basic housing. The H27ICAT is designed for shallow ceilings where insulation is present. The H27ICAT housing is of AIR-TITE construction and prevents airflow between conditioned spaces and unconditioned attic/plenum areas.
  • New construction recessed can, ideal for those who have easy access to their ceilings
  • Insulation contact rated: Designed for insulated ceilings where contact is necessary
  • Shallow recessed can for ceilings with 2 x 6 joist construction, fits perfectly in tight spaces
  • Bulb not included
  • Compatible with a wide variety of 6 inch Recessed light trims but is best with Halo 426, 420, 353, 310, 301, 172, 78, 71, 70, and 30 series models
  • Compatible with a wide variety of 6 inch LED retrofit trims but is best with Halo quality RL, RA, SLD, LT, SMD, and ML series models (Bulb free with some having a 45 year LED lifespan)
  • Uses PAR 30 75-Watt bulbs (not included)
  • Got-Nail: Pre-installed nail easily installs in regular lumber, engineered lumber and laminated beams
  • Pass-N-Thru bar hangers: Fixture has pre-installed nails that easily installs in regular lumber, engineered lumber, and laminated beams
  • Three "Quick Connect" connectors eliminate the need for separate wire nuts - simply strip supply wires and push in
  • Features an integral thermal protector to guard against misuse of insulation materials and improper lamping

Product Overview

  • Adjustable socket for different recessed lamp types and sizes
  • Best with Halo 6 in. recessed can lights and LED retrofits
  • An ideal recessed can for ceilings with very limited space
Model #: H27ICAT
Sku #: 842006
Internet #: 202024770

The H27ICAT housing is designed for use in shallow ceilings. The wide variety of trims available allows a number of different lighting effects to be created with 1 basic housing. The H27ICAT is designed for shallow ceilings where insulation is present. The H27ICAT housing is of AIR-TITE construction and prevents airflow between conditioned spaces and unconditioned attic/plenum areas.

  • New construction recessed can, ideal for those who have easy access to their ceilings
  • Insulation contact rated: Designed for insulated ceilings where contact is necessary
  • Shallow recessed can for ceilings with 2 x 6 joist construction, fits perfectly in tight spaces
  • Bulb not included
  • Compatible with a wide variety of 6 inch Recessed light trims but is best with Halo 426, 420, 353, 310, 301, 172, 78, 71, 70, and 30 series models
  • Compatible with a wide variety of 6 inch LED retrofit trims but is best with Halo quality RL, RA, SLD, LT, SMD, and ML series models (Bulb free with some having a 45 year LED lifespan)
  • Uses PAR 30 75-Watt bulbs (not included)
  • Got-Nail: Pre-installed nail easily installs in regular lumber, engineered lumber and laminated beams
  • Pass-N-Thru bar hangers: Fixture has pre-installed nails that easily installs in regular lumber, engineered lumber, and laminated beams
  • Three "Quick Connect" connectors eliminate the need for separate wire nuts - simply strip supply wires and push in
  • Features an integral thermal protector to guard against misuse of insulation materials and improper lamping

Info & Guides

You will need Adobe® Acrobat® Reader to view PDF documents. Download a free copy from the Adobe Web site.

Compare Similar

Price
$9.85 /each
$16.98 /each
$19.00 /each
$22.00 /each
Name H7 6 in. Aluminum Recessed Lighting Housing for New Construction Ceiling, Insulation Contact H27 6 in. Aluminum Recessed Lighting Housing for New Construction Shallow Ceiling, Insulation Contact, Air-Tite H2750 6 in. Aluminum LED Recessed Lighting Housing for New Construction Shallow Ceiling, T24 Rated, IC Rated, Air-Tite 6 in. IC or Non-IC New Construction Recessed Housing without Socket Plate Includes Quick Connect Terminals
Brand Halo Halo Halo Thomas Lighting
Ratings (138) (75) (3) (0)
Insulation contact Insulation contact Insulation contact Insulation contact Insulation contact
Reflector finish family Aluminum Aluminum Aluminum Aluminum
Housing depth (in.) 7 10.5 5 7.5
Size 6 in. 6 in. 6 in. 6 in.
New Construction or Remodel New Construction New Construction New Construction New Construction
View Product View Product View Product View Product

Specifications

Dimensions

Aperture width (in.)
6.5
Housing depth (in.)
10.5
Product Depth (in.)
10.5
Product Height (in.)
5
Product Width (in.)
7.5
Size
6 in.

Details

Airtight
Yes
Insulation contact
Insulation contact
Light Bulb Type Included
No Bulbs Included
New Construction or Remodel
New Construction
Number of Housings Included
1
Package Quantity
1
Product Weight (lb.)
3.03 lb
Reflector finish family
Aluminum
Returnable
90-Day

Warranty / Certifications

Certifications and Listings
1-UL Listed,CSA Listed,IC Rated
Manufacturer Warranty
1 year limited

Specifications

Dimensions

Aperture width (in.)
6.5
Housing depth (in.)
10.5
Product Depth (in.)
10.5
Product Height (in.)
5
Product Width (in.)
7.5
Size
6 in.

Details

Airtight
Yes
Insulation contact
Insulation contact
Light Bulb Type Included
No Bulbs Included
New Construction or Remodel
New Construction
Number of Housings Included
1
Package Quantity
1
Product Weight (lb.)
3.03 lb
Reflector finish family
Aluminum
Returnable
90-Day

Warranty / Certifications

Certifications and Listings
1-UL Listed,CSA Listed,IC Rated
Manufacturer Warranty
1 year limited

Questions & Answers

which baffle and trim fit this housing ?

which baffle and trim fit this housing ?
Asked by: kev
A list of compatible trims can be found on the manufacturers spec sheet here: http://www.cooperindustries.com/content/dam/public/lighting/products/documents/halo/spec_sheets/halo-e27icat-td518050en-sss.pdf
Answered by: Shoholasmokin
Date published: 2017-11-28

I only have 5" height. Will the shallow cans work.

I only have 5" height. Will the shallow cans work.
Asked by: Joe
Joe, I just installed these shallow cans. My ceiling joists were 2x6 which gave me a little over 5 inches of space. The spec on these is 5 1/2 inches from the finished ceiling surface - like drywall. So if you have a full 5 inches of joist you should be fine. If that is not going to work for you, you may want to consider the Halo LED surface mount LED model number SMD6R6930WHDM or SMD6R6950WHDM. Just cut and paste these in the Home Depot product search box. These are super cool and easy to install. And they only require 2 1/4 inches of ceiling depth - no can required.
Answered by: Shoholasmokin
Date published: 2017-12-02

We are adding 1 1/2 tongue and grove ceiling. Are these suitable for such where trimming will reach?

Asked by: Rob
I just installed these with a T&G ceiling - but mine was only 3/4 thick. Are you adding the T&G over another ceiling like drywall to get to the 1 1/2 inch thickness? Do you have the option to remove some of the existing ceiling in the area of where the fixtures will be mounted? The I27ICAT for new construction can accommodate up to 3/8” - 1” ceiling thickness. Sounds like maybe you want to consider the E27RICAT for remodel which can accomodate 3/8” to 2” ceiling thicknesses.
Answered by: Shoholasmokin
Date published: 2017-11-28

is there a list of dimmer switches that are known to be compatible with these housings?

ive tried multiple dimmer switches and they all cause the housings to emit a loud buzzing sound. they are silent when i use standard switches (i've tested with single pole & 3-way)
Asked by: dre
LEVITON & LUTRON have many dimmers compatible. Just make sure you get the LED dimmer.
Answered by: HomeDepotCustomer
Date published: 2017-08-03
  • y_2018, m_1, d_15, h_15CST
  • bvseo_bulk, prod_bvqa, vn_bulk_2.0.6
  • cp_1, bvpage1
  • co_hasquestionsanswers, tq_21
  • loc_, sid_202024770, prod, sort_[SortEntry(order=NUM_ANSWERS, direction=DESCENDING), SortEntry(order=SUBMISSION_TIME, direction=DESCENDING), SortEntry(order=LAST_APPROVED_ANSWER_SUBMISSION_TIME, direction=DESCENDING), SortEntry(order=LAST_APPROVED_ANSWER_SUBMISSION_TIME, direction=DESCENDING), SortEntry(order=BEST_ANSWER_FEEDBACK_COUNT, direction=DESCENDING), SortEntry(order=POSITIVE_ANSWER_FEEDBACK_COUNT, direction=DESCENDING), SortEntry(order=NUM_ANSWERS, direction=DESCENDING)]
  • clientName_homedepot
  • bvseo_sdk, java_sdk, bvseo-3.1.1
  • CLOUD, getContent, 101ms
  • QUESTIONS, PRODUCT

Customer Reviews

H27 6 in. Aluminum Recessed Lighting Housing for New Construction Shallow Ceiling, Insulation Contact, Air-Tite is rated 4.6 out of 5 by 75.
Rated 5 out of 5 by from I use halo products as they are generally in expensive and get the job done. Even with an LED re... I use halo products as they are generally in expensive and get the job done. Even with an LED retrofit you can save $100 per fixture vs going with cans that have built in led drivers. Lighting can be really expensive and this is a good way to get a clean look without big $$. Really like the 4 inch (for closets, bathrooms etc) vs the 6 inch but since this is for an accessory building, I opted for the 6 inch. Because 6 inch is so common they tend to be cheaper. On this job, I wanted the shallow depth since ceiling joists were 2x6 and I wanted to have the option for storing things in the attic space without having the housing stick up above the attic floor.
Date published: 2017-11-07
Rated 5 out of 5 by from The best recessed lighting option for our shallow joists in our basement. I've been able to rapi... The best recessed lighting option for our shallow joists in our basement. I've been able to rapidly install 12 of these with only a moderate-level of DIY know-how. I'd recommend buying them in the case, because you can always find a garage or workspace to put your extras!
Date published: 2017-09-12
Rated 3 out of 5 by from No wire clamps Competitors products come with plastic 1/2" wire clamps pre installed. Not a big deal to install them but caused me a delay in my project and another trip to home depot. Additional 4 cents to install these by the vendor would have got them a higher rating
Date published: 2017-08-22
Rated 5 out of 5 by from These housings have a lot of nice features such as... These housings have a lot of nice features such as built in Romex clamps and pushin connectors. Quality was excellent and installation was quick without need a million tools.
Date published: 2017-10-24
Rated 4 out of 5 by from This is a great product. Easy to install. Unfortunately when I got back to my said hosue,one of t... This is a great product. Easy to install. Unfortunately when I got back to my said hosue,one of the mounting arms was missing. That one is on me. Must look closer next time.
Date published: 2017-12-05
Rated 5 out of 5 by from Very easy to install in new construction or old work where joists are exposed. Many parts adjusta... Very easy to install in new construction or old work where joists are exposed. Many parts adjustable to allow for exact fit.
Date published: 2017-11-21
Rated 5 out of 5 by from They where real easy to install. We are building a new addition and haven't got to try them yet They where real easy to install. We are building a new addition and haven't got to try them yet
Date published: 2017-11-08
Rated 3 out of 5 by from The new style hanger bars are a problem to shorten... The new style hanger bars are a problem to shorten for joists less than 14 & 1/2 inches.
Date published: 2017-08-15
