Windward IV 52 in. Indoor LED Brushed Nickel Ceiling Fan with Dimmable Light Kit, Remote Control and Reversible Motor
- Large room ceiling fan with a unique, modern look
- Saves up to 75% more energy and moves up to 40% more airflow
- Includes LED bulbs, remote control and downrod
Free & Easy Returns In Store or Online
Return this item within 90 days of purchase.
Get an immediate answer with AI
AI-generated from the text of manufacturer documentation. To verify or get additional information, please contact The Home Depot customer service.
Product Details
About This Product
The patented High-Efficiency Blade System of the Home Decorators Collection 52 in. Windward IV saves up to 75% more energy and moves up to 40% more airflow than standard fans while allowing for ultra-quiet, wobble-free operation. This simple, yet contemporary design has a light kit with a frosted opal glass bowl and includes two 9.5-Watt LED bulbs. The fan's steeper 29° blade pitch provides greater air movement and features a three-speed reverse function for year-round comfort and savings. The thermostatic remote with digital display controls the speed of your ceiling fan (high, medium, low) and the light (on/off/dimming). The remote includes a programmable feature that allows the fan to automatically turn on and off when the room reaches a desired temperature. This Eco Option ceiling fan has less of an impact on the environment than comparable standard ceiling fans.
Highlights
- Brushed nickel finish
- 5-high efficiency blades in black finish with 29-degree blade pitches provide greater air movement and moves up to 40% more airflow
- Dimmable light kit with frosted opal glass
- Programmable thermostatic remote control allows temperature and light control; included
- 153 mm x 15 mm motor offers superior air movement; 6052 CFM
- 6 in. threaded downrod included for increased stability
- Tri-mount installation (close-to-ceiling without downrod, standard with downrod or angled mount with extension downrod - sold separately)
- Designed for indoor use in large rooms 12 ft. x 12 ft. to 18 ft. x 18 ft.
- Assembled height with downrod 16.5 in.
- Two 9.5-Watt LED bulbs included
- Compatible with threaded 3/4 in. dia. extension downrods up to 48 in. in length (sold separately)
- Lifetime motor warranty
- Click here to learn more about exclusive Home Decorators Collection products
- Finishes shown are representative of the item. Actual finish may vary slightly.
- Click here to view the complete installation video
- For any questions regarding your purchase, product, or replacement parts please call 1-800-HOME-DEPOT (1-800-466-3337) for customer support
- Click here for more information on Electronic Recycling Programs
- Return Policy
Product Information
Specifications
Dimensions: H 16.5 in, W 52 in, D 52 in
Dimensions
Assembled Depth (in.) | 52 in |
|---|---|
Assembled Height (in.) | 16.5 in |
Assembled Weight (lbs.) | 23.1 |
Assembled Width (in.) | 52 in |
Blade Length (in.) | 22.8 in |
Blade Width (in.) | 5.3 in |
Downrod Length (in.) | 6 |
Details
Actual Color Temperature (K) | 2700 |
|---|---|
Blade Color | Black |
Blade Color Family | Black |
Blade Material | Acrylonitrile Butadiene Styrene (ABS) |
Blade Pitch | 29 |
Blade Span (in.) | 52 in |
Ceiling Fan Design | Standard |
Color Temperature | Warm White |
Commercial/Residential | Residential |
Compatible Bulb Type | LED |
Control Type | Remote |
Damp/Wet Rating | Dry Rated (Indoor) |
Dimmable Capability | Dimmable |
Durability | Not Applicable |
Features | Dimmable, Quick & Easy Install, Reversible Rotation, Timer, Twist & Lock Shade |
Housing Color | Brushed Nickel |
Housing Color Family | Nickel |
Housing Material | Steel |
Included | Downrod Included, Light Bulb(s) Included, Light Kit Included, Mounting Hardware Included, Remote Control Included, Shade(s) Included |
Indoor/Outdoor | Indoor |
Light Bulb Base Code | E26 |
Light Bulb Type Included | LED |
Location Use | Bedroom, Foyer, Kids Room, Living Room, Nursery, Office |
Lumens | 1600 |
Max. Airflow (CFM) | 6052 |
Max. Bulb Wattage (W) | 9.5 W |
Max. Motor Speed (RPM) | 170 |
Motor Type | AC |
Mounting Type | Angled Mount, Downrod Mount, Flush Mount |
Number of Blades | 5 |
Number of Lights | 2 |
Number of Speeds | 3 |
Recommended Room Size | Large Room (400 sq. ft.) |
Returnable | 90-Day |
Shade Material | Glass |
Shade Shape | Round |
Style | Modern |
Warranty / Certifications
Manufacturer Warranty | Lifetime Motor Warranty |
|---|
Questions & Answers
Windward IV 52 in. Indoor LED Brushed Nickel Ceiling Fan The lights are not functioning even with new bulbs. What can the problem be?
Are the blades reversible and if so what is the other color besides the black?
Thank you for your question. No, the blades are black.
How do I remove the globe? What lightbulb does it use?
Thank you for your question. Use palm of hand to turn counterclockwise to remove the shade. It may help to knock lightly around the edges of the dome and then push up slightly when twisting the shade off. The fan uses two 9.5-Watt dimmable LED bulbs.
can you mount the remote on the wall?
Thank you for your question. Yes, a wall cradle can be ordered by calling Home Decorators Collection customer service at 1-800-986-3460. Please reference part number 08239206954 when calling.
The light in my fan keep turning on automatically. How can I reset so that there is no auto functionality. I want to be able to control the light and fan with the remote not for it to automatically turn on at different times of the day and night.
Thank you for your question. Seems like the fans signal has something interfering with it. The remote and receiver have dip switches that can be set to any unique combination of up or down as long as the settings in the remote match the settings on the receiver. Please change them both to a different code. This will prevent the light turning on when you don't want it to. This is covered in detail in the complete installation video located with the alternate images on the product page (fast forward to the 8:43 mark).
Is there a way to change the frequency on the fan and remote? It keeps going on and off in the middle of the night and we're figuring someone else has a device on the same frequency.
Thank you for your question. Seems like the fans signal has something interfering with it. The remote and receiver have dip switches that can be set to any unique combination of up or down as long as the settings in the remote match the settings on the receiver. Please change them both to a different code. This will prevent the light turning on when you don't want it to. This is covered in detail in the complete installation video located with the alternate images on the product page (fast forward to the 8:43 mark).
Will a TR-220A remote work with an older model Windward 4 fan that has a FAN-97 remote?
Thank you for your question. Technically yes this remote/receiver can work. We don't recommend doing that because you would have to splice the connector off the fan wires. This fan has a plastic connector for the receiver. To order a new remote or receiver please call Home Decorators Collection customer service at 1-800-986-3460 and one of the team members will be able to help you place the order for the correct replacement parts.
Can I use the remote to control the fan, and 1 light switch to control the light separately? How?
Thank you for your question. The remote receiver is separate and the fan can be wired to wall control switches instead of the remote receiver. Please note that the fan can not be installed with both a remote and wall controls. You can use only a toggle on/off wall switch with the remote/receiver.
