Ultra with Permeate Pump Loaded Under Sink Reverse Osmosis Water Filter System

  • Multi-stage filtration provides incredibly pure water
  • Can effectively treat up to 3,000 gal. water
  • Ensures effective filtration for up to 12 months
  • View More Details
How to Get It

Product Overview

Home Master Ultra Reverse Osmosis System with Permeate Pump Loaded version solves many of the problems associated with traditional reverse osmosis systems. Traditional reverse osmosis systems are destroyed by iron rich water, and do not treat microorganisms. The Home Master Ultra uses a KDF85 / catalytic carbon pre-filter to remove iron and a UV sterilizer to destroy microorganisms. Home Master systems use larger fittings and tubing than traditional RO systems to double the water flow rate. Home Master water filters uses all-in-one modular design for increased durability and easier annual service. Delivers exceptionally pure water by first stripping the water clean, removing up to 99% of chloramines, chlorine, fluoride, sulfur, chemicals, iron up to 1ppm, lead, metals, dissolved solids, other contaminants, and 99.99% of microorganisms using reverse osmosis, sediment, UV sterilization, and advanced catalytic carbon - the only carbon able to effectively remove the disinfectant chloramine. Included non-electric permeate pump reduces water waste by up to 80% and increases water production by up to 50%. With 6 stages of filtration, purification and sterilization Home Master Ultra produces exceptionally pure water. This Loaded model includes Brushed Nickel Luxury Standard RO Faucet, refrigerator connection kit, the latest Dow Filmtec 75gpd high hardness RO membrane for longer life and improved purity in both hard water and standard municipal water. 5 Year Limited Warranty.
  • A Better RO System: innovative design solves the most common problems associated with traditional RO systems, meets or exceeds NSF standards for material safety and purification performance, 5-year limited warranty, BPA free
  • Exceptional purification - 6 stages of filtration, purification, and sterilization. IRON pre-filter protects the RO membrane from iron up to 1ppm, making it perfect for well or city water, the UV filter safely destroys 99.99% of microorganisms
  • Removes up to 99% of chlorine, chloramines, hydrogen sulfide, chemicals, fluoride, chromium, iron, lead and metals, dissolved solids, pharmaceuticals and other contaminants using reverse osmosis, sediment, and advanced catalytic carbon media
  • Advanced catalytic carbon media effectively treat chloramines unlike ordinary carbon filters, plus, our granular media pressure throughput allowing the RO membrane to function more efficiently, with reduced water waste
  • Innovative modular design eliminates the most common problems associated with traditional canister RO systems - filter housing leaks, service challenges, and slow flow rate, Home Master systems use larger fittings and tubing to double the flow rate
  • Long-lasting all-in-one modular filters - built into the filter housing - prevent sediment, microorganisms and icky biofilm from accumulating, and makes the annual or 3,000 gal. filter change quick and easy - no wrenches required
  • Loaded Version includes New Dow Filmtec High Hardness 75gpd RO membrane outlasts and produces cleaner water than typical RO membranes on municipal and potable well water supplies
  • Loaded version also includes Fridge Connection kit to deliver clean water to fridge and ice centers, and the exquisite new lead-free Luxury Standard brushed nickel RO faucet with 1/4 turn ceramic valve and 360° swivel spout
  • Integrated non-electric permeate pump reduces water waste up to 80% and increases water production up to 50%, hand fastener for RO faucet included, eliminates installation hassle with tight spaces or specialized tools
  • In the box: fully assembled purification unit with filters, 3.2 gal. storage tank, 3/8 in. feed water adapter with shut off valve, luxury standard RO faucet in brushed nickel with adapter, TFC RO membrane, 110V power supply, drain saddle and instructions
  • Home Master Promise - this water filtration system is the finest equipment that money can buy, it will deliver years of trouble-free operation and produce perfect water, if something goes wrong, we will make it right, performance - support - peace of mind
  • Click here for more information on Electronic Recycling Programs

Info & Guides

You will need Adobe® Acrobat® Reader to view PDF documents. Download a free copy from the Adobe Web site.



Fitting size (in.)
Product Depth (in.)
16 in
Product Height (in.)
12 in
Product Width (in.)
20 in


Bacteria Reduction (%)
Chlorine reduction (%)
Contaminants Filtered
Lead, Chlorine, Bacteria, Copper, Fluoride, Iron
Copper Reduction (%)
Automatic shutoff
Filtration Method
Coconut Shell Carbon,KDF,Sand,Ultraviolet Light
Fitting style
Push to connect
Fluoride Reduction (%)
Faucet,Filter,Hardware,Installation kit
Iron Reduction (%)
Lead reduction (%)
Maximum feed water pressure (psi)
Maximum feed water temperature (F)
Maximum filtered water flow (gallons per min.)
Minimum feed water pressure (psi)
Minimum feed water temperature (F)
Number of filters included
Number of stages
Product Type
Filter System
Product Weight (lb.)
19 lb
Water Filtration System Type
Reverse Osmosis

Warranty / Certifications

Certifications and Listings
No Certifications or Listings
Manufacturer Warranty
5 years limited parts

Questions & Answers

Typical questions asked about products:

  • Is the product durable?
  • Is the product easy to use?
  • What are the dimensions of the product?

Customer Reviews

  • 3
    out of 2 reviews
  • 0%recommend this product
Filter by:
Showing 1-2 of 2 reviews
After installation by a plumber who has installed many such...
After installation by a plumber who has installed many such units, the unit was leaking. The plumber advised us that the pump needed to be replaced. When we called Home Depot we were told that it was not your problem and that we should look to the manufacturer to replace the pump. The cost - $60
  • Verified Purchase
1 person found this helpful
I bought this system a few months ago, it works well, does it's job, and thanks to this RO system...
I bought this system a few months ago, it works well, does it's job, and thanks to this RO system, i can rest easy knowing that my minis are drinking safe, purified drinking water. At first the system looks daunting but don't let that psych you out! It's like an easy DIY project from HGTV! My hubby and I were able to install it within an hour thanks to the company's installation videos on their website! I suggest this system to all my friends. Love the faucet.
    2 people found this helpful
    Showing 1-2 of 2 reviews
