80 Gal. 175 PSI Type 30-Vertical 5 HP 230-Volt 1-Phase Two-Stage Electric Air Compressor
- Ingersoll Rand 80 Gallon, 230 volt, 1-Phase, 60hz, 45465101
- 16.8 CFM @ 175 psi, 85 DBA, 5HP, 175 MAX PSI, 38x24x69, 597 lbs.
- 100% Cast Iron Pump, High-Efficiency Inlet Air Filter, 28 amp
- View More Details
Free & Easy Returns In Store
Return this item within 90 days of purchase.
Ask about this product
Get an answer now with AI
AI-generated from the text of manufacturer documentation. To verify or get additional information, please contact The Home Depot customer service.
Product Details
About This Product
Ingersoll Rand utilizes over 140 years of experience to bring you the best quality in compressed air. The Ingersoll Rand 80-Gal. two-stage, electric air compressor with 5 HP is designed for heavy shop or industrial use the reliability and performance is ideal for most applications. Applications include automotive services and body shops, fleet maintenance, machine shops, production and manufacturing lines, woodworking shops, dry cleaners, car washes, general maintenance, repair shops and farms.
Highlights
- 230-Volt, single phase, 60 Hz
- Designed for residential power supply requires hardwired electrical installation
- High efficiency stainless steel valves
- Oversized industrial-grade bearings for extended pump life
- High-efficiency intercooler
- 100% cast iron pump, including cylinder head with deep-groove directional cooling fins
- High-efficiency inlet air filter with sound attenuation (lessening) baffles
- Balanced pistons for maximized efficiency and minimized vibration
- Oversized cast iron balanced belt wheel to allow continuous-duty operation
- Mounted magnetic starter included
- 3/4 in. ball valve customer connection
- Don't forget to purchase an Ingersoll Rand 2yr Warranty Startup Kit *Sold Separately* Home Depot # 331959946
- Click here for more information on Electronic Recycling Programs
- Return Policy
- California residentssee Prop 65 WARNINGS
Product Information
Specifications
Dimensions: H 76 in, W 40 in, D 48 in
Dimensions
Product Depth (in.) | 48 in |
|---|---|
Product Height (in.) | 76 in |
Product Width (in.) | 40 in |
Details
Air Delivery SCFM @ 40PSI | 17.8 |
|---|---|
Air Delivery SCFM @ 90PSI | 17.2 |
Amperage (A) | 28 A |
Application Use | Blow Cleaning, Bolting, Brad Nailing, Cutting, Drilling, Finish Nailing, Framing Nailing, Grinding, Hobby Nailing, Inflation, Sanding, Spraying, Stapling, Surface Prep, Wrenching |
Compressor Tank Capacity (gal.) | 80 gal |
Compressor Type | Industrial |
Compressor Volume Rating | Standard |
Compressor/Air Tool Features | Tank Pressure Gauge |
Decibel Rating (Outdoor) | 85 dBA |
Horsepower (hp) | 5 hp |
Lubrication Type | Oil |
Maximum Pressure (PSI) | 175 PSI |
Number of Total Batteries Included | 0 |
Phase Type | 1 Phase |
Portable | No |
Power Source | Electric |
Power Type | Corded Electric |
Product Weight (lb.) | 500 lb |
Returnable | 90-Day |
Stage Count | Two Stage |
Tank Style | Vertical |
Tools Product Type | Air Compressor |
Voltage (V) | 230 V |
Warranty / Certifications
Manufacturer Warranty | 1 year or 2 years with use of Ingersoll Rand All Season Select Synthetic Lubricant |
|---|
Questions & Answers
What is the rpm of the motor?
1775 rpm thank you,
What?s the weight of the compressor
500 lbs
What is the Ingersoll Rand model number for this air compressor?
The model number for this Ingersoll Rand air compressor is 2475N5-V.
Whats the difference be tween 1 phase and 3 phaze
Single phase is what is typical for most houses. You get 2 "HOT" legs, 240volts when measured between the 2 HOT legs or the 2 busses inside the main panel... Typically 3 phase is a commercial or industrial electrical service. 3 phase has 3 "HOT" legs.
The difference is the number of hot power lines the voltage is carried over.
Any ingersol rand compressors that can be outdoors? I.e. Can get rain on them?
Hi Larry, I would advise you visit or contact your local Home Depot store for further assistance from a specialist in your area. Please follow the steps below to localize your Homedepot.com: 1. Localize Homedepot.com using your zip code (My Store Location: Change) 2. Choose the store where you want to pick up the item (Make this my Store) We appreciate your business and look forward to serving you in the future. Thank you for shopping Home Depot!
From what I've read on the warranty and other sites, in order to extend the Manufacturer's warranty you need to buy an Ingersoll Rand Start up kit. You need to buy this at the same time you buy the compressor. This includes their synthetic oil and air filters for this compressor. I don't see where this start up kit is available through Home Depot. Does this start up kit come with the compressor tor the sake of the warranty?
Hi Phatlump, for your convenience I have linked below the PDF file to our manufacturer's limited warranty that we have also provided online with the other assorted manufacturer files which can be found in the box labeled 'Info & Guides' to the right of the 'Product Overview' section of the product page. Hopefully, reviewing the file will be beneficial and help your shopping experience. Unfortunately, we do not offer the Starter Kit for this air compressor and all that is included in with the item is the listed Valve Adaptor and Mounted magnetic starter. We appreciate your business and look forward to serving you in the future. Thank you for shopping Home Depot! http://www.homedepot.com/catalog/pdfImages/99/991ffb8b-ab83-4f37-8881-d8177529947b.pdf
Viewing 1-6 of 6
Customer Reviews
5 out of 5
Loading Recommendations
Compare Key Features
Product Snapshot | |||
|---|---|---|---|
Built for heavy-duty shop/industrial use, this 80-gallon, 5 HP, two-stage air compressor ensures reliable performance. | Built for heavy-duty industrial use, this 80 gallon, 5 HP, two-stage air compressor ensures reliable performance. | Built for heavy-duty use, this 5 HP, two-stage air compressor boasts a large 80-gallon tank and quiet operation, ideal for demanding jobs. | Built for heavy-duty use, this 7.5 HP, 2-stage air compressor offers quiet operation and a large 80-gallon tank, ideal for demanding jobs. |
Air Tank Capacity | |||
80 gal | 80 gal | 80 gal | 80 gal |
CFM Rating | |||
17.8 SCFM @ 40 PSI, 17.2 SCFM @ 90 PSI | 19 CFM @ 40 PSI, 17.1 CFM @ 90 PSI | 31 CFM @ 100 PSI | |
Maximum PSI | |||
175 PSI | 175 PSI | 175 PSI | 175 PSI |
Horsepower | |||
5 HP | 5 HP | 5 HP | 7.5 HP |
Duty Cycle | |||
