1/4 in. x 3/8 in. x 25 ft. Universal Piping Assembly for Ductless Mini-Split

  • Copper refrigeration pipes to connect indoor and outdoor AC units
  • Includes 3/8 in. gas line and 1/4 in. liquid line
  • Pre-flared fittings and insulated, no soldering or brazing needed
$ 164 80

Frequently Bought Together

Frequently Bought Together

Product Overview

  • Copper refrigeration pipes to connect indoor and outdoor AC units
  • Includes 3/8 in. gas line and 1/4 in. liquid line
  • Pre-flared fittings and insulated, no soldering or brazing needed
This universal piping assembly contains everything you need to work with your ductless mini-split system. This particular assembly includes the insulated refrigerant line-set, communication cable and power wires. The line set consist of two semi-flexible copper pipes to connect the outdoor to the indoor evaporator coil. The smaller pipe is called the liquid line (LL). The larger pipe is referred to as the suction line (SL). The tubing is easily connected by the pre-flared fittings without the need to solder. They are manufactured in accordance with the American Society for Testing and Materials (ASTM) Standard Specification B280. This assembly is your one simple solution duct-free accessory – all you need to do is determine the proper size needed for your particular application.
  • Length: 25 ft.
  • Suction line size: 3/8 in.
  • Liquid line size: 1/4 in.
  • Pre-flared fittings and insulated - no soldering or brazing needed
  • 14-4 AWG 600-Volt mini split cable
  • Made to work with all ductless mini-split applications



Product Overview

  • Copper refrigeration pipes to connect indoor and outdoor AC units
  • Includes 3/8 in. gas line and 1/4 in. liquid line
  • Pre-flared fittings and insulated, no soldering or brazing needed
Model #: LS1438FF25W
Sku #: 1001292294
Internet #: 203682340

This universal piping assembly contains everything you need to work with your ductless mini-split system. This particular assembly includes the insulated refrigerant line-set, communication cable and power wires. The line set consist of two semi-flexible copper pipes to connect the outdoor to the indoor evaporator coil. The smaller pipe is called the liquid line (LL). The larger pipe is referred to as the suction line (SL). The tubing is easily connected by the pre-flared fittings without the need to solder. They are manufactured in accordance with the American Society for Testing and Materials (ASTM) Standard Specification B280. This assembly is your one simple solution duct-free accessory – all you need to do is determine the proper size needed for your particular application.

  • Length: 25 ft.
  • Suction line size: 3/8 in.
  • Liquid line size: 1/4 in.
  • Pre-flared fittings and insulated - no soldering or brazing needed
  • 14-4 AWG 600-Volt mini split cable
  • Made to work with all ductless mini-split applications



Info & Guides

You will need Adobe® Acrobat® Reader to view PDF documents. Download a free copy from the Adobe Web site.

Compare Similar

Compare Similar Products
Brand JMF Bosch JMF JMF
Name 1/4 in. x 3/8 in. x 25 ft. Universal Piping Assembly for Ductless Mini-Split 3/8 in. x 5/8 in. x 25 ft. Universal Piping Assembly for Ductless Mini-Split 3/8 in. x 5/8 in. x 25 ft. Universal Piping Assembly for Ductless Mini Split with White Non-Tear Insulation 1/4 in. x 3/8 in. x 50 ft. Universal Piping Assembly for Ductless Mini-Split
Price
$164.80
$258.46
$269.10
$320.50 /box
Ratings (5) (0) (1) (1)
View Product View Product View Product View Product

Specifications

Dimensions

Product Depth (in.)
.5
Product Height (in.)
300
Product Width (in.)
.5

Details

Color
Black
Color Family
Black
Mini Split Accessory/Part Type
Mini Split Line Sets
Part Type
Adapter
Product Weight (lb.)
16lb
Returnable
180-Day

Warranty / Certifications

Manufacturer Warranty
None

Specifications

Dimensions

Product Depth (in.)
.5
Product Height (in.)
300
Product Width (in.)
.5

Details

Color
Black
Color Family
Black
Mini Split Accessory/Part Type
Mini Split Line Sets
Part Type
Adapter
Product Weight (lb.)
16lb
Returnable
180-Day

Warranty / Certifications

Manufacturer Warranty
None

Questions & Answers

do these come pre charged?

do these come pre charged?
Asked by: ryan
No, line sets are not pre-charged. The Gree outdoor units hold enough R410A refrigerant for 25 ft. Mult zone units hold more but you need to check the submittal documents to make sure you don’t need to add refrigerant beyond the unit’s pre-charge pipe length data.
Answered by: Gree Procuct Manager
Date published: 2019-04-17

How do you connect 4 lines to one compressor

How do you connect 4 lines to one compressor
Asked by: Home4now
I don't work for home depot but a multizone system will have connecting points on the side for different heads including the wiring of them. big line is suction, the small line is liquid line, it is also important that the linesets number match up with the control wire numbers (i.e. circuit A linesets go with circuit A wiring).
Answered by: Felix
Date published: 2017-11-12

What does it attach to and how far does it have to go?

Asked by: gigi
the lineset attaches to the condensing unit at one end and the evaporator head at the other end. this is how the cooling is created.
Answered by: Felix
Date published: 2017-11-12

Does this line set include the service port needed to vacuum the line set and evaporator?

Asked by: Clearh2o
