30 in. Electric Downdraft Cooktop in Black with 4 Burner Elements
Buy More Save More
- Downdraft ventilation captures smoke/odors at the surface
- 10" EVEN-HEAT Ultra Element w/ EVEN-HEAT Simmer adds versatility
- EVEN-HEAT with a low setting that can melt, not scorch, chocolate
- View More Details
Ask about this product
Get an answer now with AI
AI-generated from the text of manufacturer documentation. To verify or get additional information, please contact The Home Depot customer service.
Product Details
About This Product
This 30" electric cooktop features Downdraft, an integrated ventilation system that doesn't require a separate hood. A 10-inch Even-Heat Ultra element provides versatility for both high- and low-temperature cooking, and has multiple simmer settings. And with a 3-speed fan with 300 CFM exhaust rating, the venting can keep up with your culinary feats.
Highlights
- Integrates the ventilation system into the cooking surface so that a separate hood is not needed. Smoke and odors can be removed and taken outside or filtered and recirculated inside. A duct-free kit is available for purchase separately.
- Provides more versatility for high and low temperature cooking techniques. Even-Heat Technology maintains a constant supply of power and delivers a range of simmer settings.
- Combines the benefits of Even-Heat Technology with a dedicated setting that reaches the low temperatures needed to melt chocolate or butter without scorching.
- Handles the venting requirements of high temperature cooking techniques like pan searing and stir-frying.
- Can be precisely matched to cooking needs, effectively removing steam, grease, and odors from the air.
- Two element sizes in one provide the ability to use it for large stock pots or six-inch saute pans and handle tasks ranging from rapid boiling and searing to wok cooking.
- Allows a downdraft cooktop to be placed nearly anywhere in the kitchen using a duct-free conversion kit (not included). This filters and recirculates the air without running ductwork, ideal for kitchens with installation restrictions or ducting limitations.
- Power Indicator light lets you know at a glance when an element is on
- Provides a clear indication that lets you know if any cooking surface is on or still hot.
- Comes in saturated colors with stainless steel control knobs for a sophisticated, easy-to-clean appearance.
- Enhance the look of the cooktop surface with sturdy construction that adds to their premium feel.
- Can reach a power output of up to 1200 watts to handle your daily cooking needs.
- 10''/6'' ULTRA POWER Double-Ring round element provides the ability to use it for large stock pots or six-inch saute pans and handle tasks ranging from rapid boiling and searing to wok cooking
- Please call your local store with your Order # to schedule installation for this item
- Click here to shop more Kitchenaid appliances
- Click here for more information on Electronic Recycling Programs
- California residentssee Prop 65 WARNINGS
Product Information
Specifications
Dimensions: H 3.62 in, W 30.88 in, D 22.06 in
Dimensions
Cooktop Size | 30 in. |
|---|---|
Cut-Out Front to Back Depth (in.) | 21.13 |
Cut-Out Height (in.) | 3.75 |
Cut-Out Left to Right Width (in.) | 28.75 |
Product Depth (in.) | 22.06 in |
Product Height (in.) | 3.62 in |
Product Width (in.) | 30.88 in |
Details
Appliance Category | Cooktop |
|---|---|
Appliance Series | Not Applicable |
Appliance Type | Electric Cooktop |
Color/Finish | Black |
Color/Finish Family | Black |
Commercial/Residential | Residential |
Control Location | Right |
Cooktop Features | Downdraft, Indicator Light- Heating Element On, Indicator Light- Hot Surface Indicator Light, Radiant |
Cooktop Surface Type | Smooth Top |
Fuel Type | Electric |
Max Element Size (in.) | 10 in |
Max Element Wattage | 3200 |
Min Element Size (in.) | 6 in |
Min Element Wattage | 1200 |
Number of Elements | 4 element |
Returnable | Non-Returnable |
Warranty / Certifications
Certifications and Listings | UL Listed |
|---|---|
Manufacturer Warranty | 1 Year Limited |
Questions & Answers
What are the dimensions of the downdraft into the cabinet?
Hello! Please see the link to the dimension guide for the complete dimensions of this model. https://tinyurl.com/yc4tmjvx Thank you for your inquiry about our KitchenAid appliances.
Location of downdraft from side
Hello! The downdraft is located in the middle. We hope this helps.
Why do I need to PURCHASE a "protection plan"? Does nothing have a warranty anymore? What exactly are my odds of my product being repaired or replaced after spending more money during purchase for something that should already be honored?
How do you stop the cold air from coming in during the winter from the downdraft? I have cold air seeping through in the winter? Should I cover the vent from the outside?
Is this cooktop ceramic?
Thank you for your inquiry about our KitchenAid appliances. Model KCED600GBL is a Ceramic Glass.
What is the amperage rating?
Thank you for your inquiry about our KitchenAid appliances. Model KCED600GBL has a 40 amp.
which side is the down draft, left or right
Hello! The downdraft is in the middle. Thank you for your inquiry about our KitchenAid appliances.
WHAT IS THE LRC/LRA RATING
Hello! We greatly apologize as we do not having these ratings available. Thank you for your inquiry about our KitchenAid appliances.
