Model # 687BWXT 5 SMT CP

Internet #202279372

Store SKU #183589

Kwikset Belleview Antique Brass Single Cylinder Door Handleset with Tylo Knob Featuring SmartKey Security
0883351276498

Kwikset

Belleview Antique Brass Single Cylinder Door Handleset with Tylo Knob Featuring SmartKey Security

  • Universal handing fits both right & left-handed door preparations
  • SmartKey Security re-keying allows you to re-key lock yourself
  • Installs in minutes with just a screwdriver
$ 84 97
store icon Loading Buying Options...
package icon Loading Buying Options...
Sorry, but we ran into issues loading these options. Please try refreshing.

Frequently Bought Together

Frequently Bought Together

Product Overview

Customer using SmartKey Security to re-key lock


Security Made Convenient

SmartKey Security features re-key technology, which allows you to re-key your locks yourself in seconds, because we realize the person who has your key today may not be the same person you want to have your key tomorrow.

Exterior shot of door with SmartKey Security lock


Protects Against Common Break-in Methods

Kwikset's SmartKey Security is designed to protect against common types of break-ins to keep your family safe. SmartKey Security is kick-in resistant, bump proof, pick resistant, drill resistant, and saw resistant. Kwikset SmartKey Security also allows you to re-key the lock yourself in seconds, leaving lost or unreturned keys obsolete.

SmartKey Security re-key tools


Re-Key as Easy as 1-2-3

Before you start re-keying, you must have your functioning key, your new KW1 key, and the SmartKey Learn tool.

Key turning 90 degrees to the right


Step 1

Insert the key that currently operates your lock, and rotate it 90 degrees clockwise.

SmartKey being inserted and withdrawn while key is still in lock


Step 2

A) Insert the SmartKey tool fully and firmly into the SmartKey hole.
B) Remove the SmartKey tool and the current key.

Key turning 180 degrees to the left


Step 3

A) Fully insert your new key into the lock and rotate it 180 degrees.
B) Rotate the new key 90 degrees back to the starting position, and remove it. Your lock is now re-keyed to your new key, and your old key will no longer operate the lock.

Door opening icon

One-Key Convenience

Re-key your locks yourself so all your doors and padlocks share one key.

Magnifying glass icon

Reasons to Re-Key

Your child has lost their key, again.

Keychain icon

Reasons to Re-Key

You have loaned or unreturned keys.

Delivery truck icon

Reasons to Re-Key

You have recently moved or had tenant turnover.

  • Universal handing fits both right & left-handed door preparations
  • SmartKey Security re-keying allows you to re-key lock yourself
  • Installs in minutes with just a screwdriver
As the industry leader, Kwikset has provided trusted security for over 60 years and has become synonymous with security, peace of mind, style and innovation. The beveled design of the Belleview adds elegance to its traditional arched shape The classic design of Tylo is at home in any decor. Its style lends a graceful finish to any door. The complementary Antique Brass finish offers a warm feel with deep accents in the contours of the product. The single cylinder handle set can be locked or unlocked by a key on the outside, or the turn button on the inside. SmartKey Security Re-key Technology allows you to control who has access to your home. Re-key the lock yourself in seconds in 3 easy steps. Have you recently moved or had a child lose a key. It's time to re-key. SmartKey Security provides the highest level of residential security and features BumpGuard to protect against lock bumping.
  • Featuring SmartKey Security, which protects against advanced break-in techniques and allows you to re-key your lock yourself in seconds.
  • SmartKey Security re-key technology is compatible with Kwikset (KW1) keyway
  • Fits door thickness of 1-3/4 in.
  • For use on exterior doors where keyed entry and security is needed
  • Universal handling, fits both right-handed and left-handed doors
  • Antique brass finish
  • Patented side locking bar technology offers improved security by protecting against lock bumping, an attack technique used to defeat conventional pin and tumbler locks
  • 2-keys included
  • Easy installation - installs in minutes with just a screwdriver
  • Features a fully adjustable latch to fit all standard door preparations
  • Not sure what type of lock you need? Check out our helpful buying guide here.

Product Overview

  • Universal handing fits both right & left-handed door preparations
  • SmartKey Security re-keying allows you to re-key lock yourself
  • Installs in minutes with just a screwdriver
Model #: 687BWXT 5 SMT CP
Sku #: 183589
Internet #: 202279372

As the industry leader, Kwikset has provided trusted security for over 60 years and has become synonymous with security, peace of mind, style and innovation. The beveled design of the Belleview adds elegance to its traditional arched shape The classic design of Tylo is at home in any decor. Its style lends a graceful finish to any door. The complementary Antique Brass finish offers a warm feel with deep accents in the contours of the product. The single cylinder handle set can be locked or unlocked by a key on the outside, or the turn button on the inside. SmartKey Security Re-key Technology allows you to control who has access to your home. Re-key the lock yourself in seconds in 3 easy steps. Have you recently moved or had a child lose a key. It's time to re-key. SmartKey Security provides the highest level of residential security and features BumpGuard to protect against lock bumping.

  • Featuring SmartKey Security, which protects against advanced break-in techniques and allows you to re-key your lock yourself in seconds.
  • SmartKey Security re-key technology is compatible with Kwikset (KW1) keyway
  • Fits door thickness of 1-3/4 in.
  • For use on exterior doors where keyed entry and security is needed
  • Universal handling, fits both right-handed and left-handed doors
  • Antique brass finish
  • Patented side locking bar technology offers improved security by protecting against lock bumping, an attack technique used to defeat conventional pin and tumbler locks
  • 2-keys included
  • Easy installation - installs in minutes with just a screwdriver
  • Features a fully adjustable latch to fit all standard door preparations
  • Not sure what type of lock you need? Check out our helpful buying guide here.

Info & Guides

You will need Adobe® Acrobat® Reader to view PDF documents. Download a free copy from the Adobe Web site.

Customers Also Compared These

Price
$84.98
$84.98
$99.00
$109.00
Name Belleview Antique Brass Single Cylinder Door Handleset with Tylo Knob Featuring SmartKey Security Dakota Satin Nickel Single Cylinder Door Handleset with Polo Knob Featuring SmartKey Security Belleview Venetian Bronze Single Cylinder Door Handleset with Cove Knob Featuring SmartKey Security Camelot Antique Brass Single Cylinder Deadbolt with Georgian Knob Door Handleset
Brand Kwikset Kwikset Kwikset Schlage
Ratings (80) (163) (128) (177)
Commercial/Residential Residential Residential Residential Residential
Door Handing Universal/Reversible Universal/Reversible Universal/Reversible Universal/Reversible
Hardware Finish Family Brass Nickel Bronze Brass
Security/ANSI Grade ANSI Grade 3 (Good) ANSI Grade 3 (Good) ANSI Grade 3 (Good) ANSI Grade 1 (Best)
Deadbolt Type Single Cylinder Deadbolt Single Cylinder Deadbolt Single Cylinder Deadbolt Single Cylinder Deadbolt
View Product View Product View Product View Product

Specifications

Dimensions

Assembled Depth (in.)
2.15625 in
Assembled Height (in.)
18.06 in
Assembled Width (in.)
2.931 in
Deadbolt bore hole diameter (in.)
1
Deadbolt cross bore diameter (in.)
2.125
Deadbolt strike height (in.)
2.25
Deadbolt strike width (in.)
1.0
Deadbolt throw length (in.)
1.0
Deadbolt trim ring diameter (in.)
3.0
Handle grip length (in.)
1.0
Inside top plate length (in.)
1.0
Inside top plate width (in.)
1.0
Knob Diameter (in.)
1.875
Knob/lever bore hole diameter (in.)
2.125
Knob/lever cross bore diameter (in.)
1.0
Knob/lever housing height (in.)
2.625
Knob/lever housing width (in.)
2.625
Knob/lever strike height (in.)
2.25
Knob/lever strike width (in.)
1.0
Knob/lever throw length (in.)
0.5
Maximum door thickness (in.)
1.75
Outside bottom handle plate length (in.)
1.0
Outside bottom handle plate width (in.)
1.0
Outside key plate length (in.)
1.0
Outside key plate width (in.)
1.0
Outside top handle plate length (in.)
1.0
Outside top handle plate width (in.)
1.0
Projection (in.)
1.875

Details

Application Type
Entry
Backset size (in.)
Adjustable
Commercial/Residential
Residential
Deadbolt Type
Single Cylinder Deadbolt
Deadbolt strike
Round corner
Door Handing
Universal/Reversible
Door Lock Style
Classic
Door Locks & Knobs Product Type
Keyed Handlesets
Features
Easy Installation,Smart Key
Finish
Antique Brass
Handleset Product Type
2 Piece Front & Back
Hardware Finish Family
Brass
Hardware Included
Yes
Included
Hardware,Installation Instructions
Interior/Exterior
Exterior
Knob style
Flat ball
Knob/lever strike
Round corner
Lock Type
Keyed Entry
Material
Metal
Minimum door thickness (in.)
1.75
Product Weight (lb.)
1lb
Returnable
90-Day
Security/ANSI Grade
ANSI Grade 3 (Good)
Tools/Hardware Collections
Kwikset SmartKey
Total number of keys included
2

Warranty / Certifications

Certifications and Listings
No Certifications or Listings
Manufacturer Warranty
Lifetime mechanical and finish warranty

Specifications

Dimensions

Assembled Depth (in.)
2.15625 in
Assembled Height (in.)
18.06 in
Assembled Width (in.)
2.931 in
Deadbolt bore hole diameter (in.)
1
Deadbolt cross bore diameter (in.)
2.125
Deadbolt strike height (in.)
2.25
Deadbolt strike width (in.)
1.0
Deadbolt throw length (in.)
1.0
Deadbolt trim ring diameter (in.)
3.0
Handle grip length (in.)
1.0
Inside top plate length (in.)
1.0
Inside top plate width (in.)
1.0
Knob Diameter (in.)
1.875
Knob/lever bore hole diameter (in.)
2.125
Knob/lever cross bore diameter (in.)
1.0
Knob/lever housing height (in.)
2.625
Knob/lever housing width (in.)
2.625
Knob/lever strike height (in.)
2.25
Knob/lever strike width (in.)
1.0
Knob/lever throw length (in.)
0.5
Maximum door thickness (in.)
1.75
Outside bottom handle plate length (in.)
1.0
Outside bottom handle plate width (in.)
1.0
Outside key plate length (in.)
1.0
Outside key plate width (in.)
1.0
Outside top handle plate length (in.)
1.0
Outside top handle plate width (in.)
1.0
Projection (in.)
1.875

Details

Application Type
Entry
Backset size (in.)
Adjustable
Commercial/Residential
Residential
Deadbolt Type
Single Cylinder Deadbolt
Deadbolt strike
Round corner
Door Handing
Universal/Reversible
Door Lock Style
Classic
Door Locks & Knobs Product Type
Keyed Handlesets
Features
Easy Installation,Smart Key
Finish
Antique Brass
Handleset Product Type
2 Piece Front & Back
Hardware Finish Family
Brass
Hardware Included
Yes
Included
Hardware,Installation Instructions
Interior/Exterior
Exterior
Knob style
Flat ball
Knob/lever strike
Round corner
Lock Type
Keyed Entry
Material
Metal
Minimum door thickness (in.)
1.75
Product Weight (lb.)
1lb
Returnable
90-Day
Security/ANSI Grade
ANSI Grade 3 (Good)
Tools/Hardware Collections
Kwikset SmartKey
Total number of keys included
2

Warranty / Certifications

Certifications and Listings
No Certifications or Listings
Manufacturer Warranty
Lifetime mechanical and finish warranty

Questions & Answers

How far does the handle stick out? I'm installing a storm door and my handle to the front door sticks out too far and close

Asked by: LIZ
About 2 1/8"
Answered by: William
Date published: 2018-11-10

My deadbolt is fine but my exterior handleset sticks and it is hard to open the door. Can I buy ...

My deadbolt is fine but my exterior handleset sticks and it is hard to open the door. Can I buy just the exterior door opener handleset and the knob without buying another lock?
Asked by: jrs
Yes, you can buy a new one.
Answered by: CommunityAnswer
Date published: 2018-04-20

We have double doors, how can I purchase just an additional exterior handle and interior dummy knob?

We have double doors, how can I purchase just an additional exterior handle and interior dummy knob?
Asked by: swarner2222
I had to purchase both however I was in a rush and did not do any research online.
Answered by: mattyaz
Date published: 2018-04-24

I'm replacing an existing lockset and need to know the distance between the centerline of the han...

I'm replacing an existing lockset and need to know the distance between the centerline of the handle latchset hole (hole @ the top of handle) and the hole in the door for the bottom of the handle bolt (See attachment). For my existing lockset, this distance is 9.25-Inches. The diagram shows 9.125-Inches +/- 0.75-Inches. Can you please provide the exact distance? Second Question - What is the distance from centerline of the bottom handle bolt hole to the very bottom of the handle plate? I need to know if the handle plate may possibly cover the existing bolt hole if the distance in my first question is less than 9.25-Inches.
Asked by: Mark
The Belleview is 8 13/32 from the center of the latch to the bottom screw hole. The trim of the deadbolt is 3x4 1/2. The trim of the bottom plate is 2x3. Please contact or visit your local Home Depot special order counter for alternate options, pricing, and availability.
Answered by: Kwikset
Date published: 2018-09-06
  • y_2019, m_2, d_20, h_18CST
  • bvseo_bulk, prod_bvqa, vn_bulk_2.0.11
  • cp_1, bvpage1
  • co_hasquestionsanswers, tq_9
  • loc_, sid_202279372, prod, sort_[SortEntry(order=NUM_ANSWERS, direction=DESCENDING), SortEntry(order=SUBMISSION_TIME, direction=DESCENDING), SortEntry(order=LAST_APPROVED_ANSWER_SUBMISSION_TIME, direction=DESCENDING), SortEntry(order=LAST_APPROVED_ANSWER_SUBMISSION_TIME, direction=DESCENDING), SortEntry(order=BEST_ANSWER_FEEDBACK_COUNT, direction=DESCENDING), SortEntry(order=POSITIVE_ANSWER_FEEDBACK_COUNT, direction=DESCENDING), SortEntry(order=NUM_ANSWERS, direction=DESCENDING)]
  • clientName_homedepot
  • bvseo_sdk, java_sdk, bvseo-3.1.1
  • CLOUD, getContent, 135ms
  • QUESTIONS, PRODUCT

Customer Reviews

Belleview Antique Brass Single Cylinder Door Handleset with Tylo Knob Featuring SmartKey Security is rated 4.3 out of 5 by 80.
Rated 5 out of 5 by from Easy to install and looks nice on our front door.... Easy to install and looks nice on our front door. The SmartKey feature is nice. We have been able to easily rekey all of the locks in our new home to one key.
Date published: 2019-01-02
Rated 5 out of 5 by from Excellent high quality product. Perfect fit. Excellent high quality product. Perfect fit.
Date published: 2018-12-18
Rated 5 out of 5 by from 5 Star Review Rating provided by a verified purchaser
Date published: 2019-02-05
Rated 4 out of 5 by from 4 Star Review Rating provided by a verified purchaser
Date published: 2019-02-07
Rated 4 out of 5 by from 4 Star Review Rating provided by a verified purchaser
Date published: 2019-02-06
Rated 5 out of 5 by from 5 Star Review Rating provided by a verified purchaser
Date published: 2019-02-06
Rated 4 out of 5 by from 4 Star Review Rating provided by a verified purchaser
Date published: 2019-02-06
Rated 5 out of 5 by from 5 Star Review Rating provided by a verified purchaser
Date published: 2019-02-07
  • y_2019, m_2, d_20, h_18
  • bvseo_bulk, prod_bvrr, vn_bulk_2.0.11
  • cp_1, bvpage1
  • co_hasreviews, tv_0, tr_80
  • loc_, sid_202279372, prod, sort_[SortEntry(order=RELEVANCE, direction=DESCENDING)]
  • clientName_homedepot
  • bvseo_sdk, java_sdk, bvseo-3.1.1
  • CLOUD, getContent, 114ms
  • REVIEWS, PRODUCT
