Model #R30-05206-S10

Store SKU #1002623092

50 Amp 125/250-Volt Shallow Flush Mounted Single Outlet, Black

  • Design - fits wallplates with 2.15 in. Dia center hole
  • Durable - equipped with heavy-gauge, double-wire alloy contacts
  • Easy - terminal markings for easy identification and fast wiring
  • See More Details

Frequently Bought Together

+
+
Price:

Product Overview

Built of durable thermoplastic, Leviton Power Receptacles come equipped with heavy-gauge, double-wire copper alloy contacts. To ensure correct and speedy wiring, terminals have ID markings. Flush mount receptacles fit Leviton's wide range of 2.15 in. dia. wallplates and mounting hardware is included.
  • Use 2-gang wallplate (2.15 in. opening) to complete installation
  • Terminals marked for easy identification and fast wiring
  • All mounting hardware included
  • Warning: do not use with single-gang wall boxes, single-gang mud rings or single-gang box extenders

Compare Similar Electrical Outlets & Receptacles

15 Amp 125-Volt 2-Pole 3-Wire Grounding Cord Outlet, Black
current product
50 Amp 125/250-Volt Shallow Flush Mounted Single Outlet, Black
50 Amp Thermoplastic Power Single Outlet, Black15 Amp Tamper-Resistant Duplex Outlet, White (10-Pack)
BrandLevitonLevitonLevitonLeviton
Name15 Amp 125-Volt 2-Pole 3-Wire Grounding Cord Outlet, Black50 Amp 125/250-Volt Shallow Flush Mounted Single Outlet, Black50 Amp Thermoplastic Power Single Outlet, Black15 Amp Tamper-Resistant Duplex Outlet, White (10-Pack)
Price
Ratings
(50)
(117)
(59)
(722)
Number of Outlets1112
RatingGeneral PurposeGeneral PurposeGeneral PurposeTamper Resistant
Outlet TypeStandardStandardStandardStandard
Electrical FeaturesNo Additional FeaturesNo Additional FeaturesNo Additional FeaturesNo Additional Features
Indoor/OutdoorIndoorIndoorIndoorIndoor
Outlet ConfigurationSingleSingleSingleDuplex
Mounting TypeIn-WallIn-WallPlug-InIn-Wall
NEMA ConfigurationNEMA 5NEMA 10NEMA 10NEMA 5
GroundingSelf-GroundingUngroundedUngroundedUngrounded
Outlet LocationFloorWallFloor,WallWall
View ProductView ProductView ProductView Product

Specifications

Dimensions

Outlet Depth (in.)
2.3
Outlet Height (in.)
6.4
Outlet Width (in.)
4.3

Details

Color Family
Black
Color/Finish
Black
Electrical Features
No Additional Features
Electrical Product Type
Outlet
Grounding
Ungrounded
Indoor/Outdoor
Indoor
Maximum Amperage (amps)
50
Mounting Type
In-Wall
NEMA Configuration
NEMA 10
NEMA Configuration Receptacle
5-50
Number of Outlets
1
Number of Poles
3
Outlet Configuration
Single
Outlet Location
Wall
Outlet Material
Thermoplastic
Outlet Type
Standard
Package Quantity
1
Rating
General Purpose
Returnable
90-Day
Voltage
125 volt,250 volt
Wired or Wireless
Wired

Warranty / Certifications

Certifications and Listings
CSA Listed,UL Listed
Manufacturer Warranty
10 Year Limited

Questions & Answers

8Questions14Answers

Hey what box do I use with this outlet

Asked by Ferg1 December 28, 2020
2
Answers

I have two in my shop. One is in a 4 in. x 2 in. Drawn Handy Box SKU#299839 and the other is in a 4" x 2 1/8" Steel City Deep Metal Utility Box SKU#321532. In practice you can put it in any box for which you can find a cover plate with a 1 9/16" hole (actual diameter 1.548").

Can this be used in a circuit with a 40 amp breaker?

Asked by FredM September 22, 2020
1
Answer

Yes you must not exceed 50 ampers circuit breaker, Just use the right gage wire for the distance and you'll be fine, keep in mind you can lower the amperage on a circuit breaker but never exceed it

Can I use this for a 3-prong 40 amp rated electric stove cord?

Asked by patrick September 20, 2020
2
Answers

It may work since most stoves are 220 VAC and this NEMA-10-50 receptacle is designed for single phase 125/250 VAC. Look on the plug attached to the stove to find the NEMA Number. Since 40 Amp fixtures are not manufactured you will need a 50 Amp plug and receptacle to be safe. Make sure that the stove plug reads NEMA-10-50 and not NEMA-5-50, NEMA-6-50 nor NEMA-7-50. If the plug on the stove does read NEMA-10-50, the associate in the electrical department at HD can help you find a match.

I have a 8-2 wire I plugged the hot wire to x and y I have a ground wire left can I plug it into the w terminal?

Asked by Rob March 13, 2020
1
Answer

On a 220 VAC circuit using a NEMA 10-50 Plug or Jack, X and Y are hot and W is ground. On a 110 VAC Circuit the NEMA 10-50 plug and jack are not recomended, but the X should be hot, Y is neutral and W is ground.

I have 6-3 wire with ground going to this. Where do I put the ground?

Asked by JB May 5, 2019
2
Answers

The white wire goes to either of the diagonal slots and the black wire goes to the other diagonal slot. The green ground wire goes to the vertical bottom slot.

Can this outlet be used with aluminum wire ?

Asked by jv August 17, 2018
2
Answers

I would not recommend it unless the aluminum wire is at least 4 awg and better yet 2 awg.

Is It For This Pkug?

Asked by Rick August 8, 2018
2
Answers

Yes it is.

need someone to explain why this outlet cannot or should not be used with electric dryer? Is using a range cord (40amp) up to

Asked by theresa July 18, 2018
2
Answers

"Current code" is a 4 prong providing the 2 hots, a return neutral line and a ground for strays... It sounds like your goal is to have an outlet that matches your current cord... Any handy person can change the receptacle to match your cord, it's only 3 wires, then change it back when you move...
