50 Amp Plasma Cutter, 200 Amp TIG/Stick Welder 3-in-1 Combo Welding Machine, Dual Voltage 110V/220V

$42309
Apply Now
$undefined.00 /mo* suggested payments with months* financingApply Now
  • Lightweight design
  • Durable and dependable
  • Suitable for a wide range of projects
  • View More Details
Store
0 in stock
Text to Me
How to Get It

Frequently Bought Together

+
+
Price:
$42309

Product Overview

As one of the largest manufacturers of plasma cutting, TIG/stick, arc (MMA) welding equipment in the world, Lotos Technology offers the CT520D multi-purpose unit that provides a variety of welding and cutting functions. It is able to cut all types of metal up to 1/2 in. with the 50 Amp plasma cutting function. With a hand carrying weight at 32 lbs. The unit is portable and reliable featuring a duty cycle of 60% at max amps for all functions.
  • Combines plasma cutting, TIG/stick and arc welding functions in 1 machine
  • Compatible consumables sets for this broen color CT520D plasma cutter are "LCS22" or "LCS33"; please search "Lotos LCS22" or "Lotos LCS33" on Homedepot.com
  • Power efficiency: 85%, input power: 110V/220V dual voltage 50Hz/60Hz single phase
  • Larger TIG welding torch (with long and short caps) (12 ft. x 4 in. )
  • Cuts all types of metal up to 1/2 in. with 50 Amp plasma cutting function
  • Package includes: welding torch (13 ft. long, 3 pin connection); TIG accessory kit TA01 (includes 3 pieces shield cups, 3 collets and 1 collet body); plasma cutting torch (13 ft. long, 3 pin connection); stick welding electrode holder (6 ft. long); ground clamp (6 ft. long) and user manual
  • Hand carrying weight at 32 lbs.
  • Click here for more information on Electronic Recycling Programs

Compare Similar Multi Process Welders

Easy Weld 140 MP, Multi-Process Welder
current product
50 Amp Plasma Cutter, 200 Amp TIG/Stick Welder 3-in-1 Combo Welding Machine, Dual Voltage 110V/220V
Top Rated50 Amp Non-Touch Pilot Arc Plasma Cutter, 200 Amp TIG/Stick Welder 3-in-1 Combo Welding Machine, Dual Voltage 110V/220VTop Rated200 Amp TIG/Stick Square Wave Inverter Welder with Foot Pedal for Aluminum, Dual Voltage 110/220V
BrandForneyLotosLotosLotos
NameEasy Weld 140 MP, Multi-Process Welder50 Amp Plasma Cutter, 200 Amp TIG/Stick Welder 3-in-1 Combo Welding Machine, Dual Voltage 110V/220V50 Amp Non-Touch Pilot Arc Plasma Cutter, 200 Amp TIG/Stick Welder 3-in-1 Combo Welding Machine, Dual Voltage 110V/220V200 Amp TIG/Stick Square Wave Inverter Welder with Foot Pedal for Aluminum, Dual Voltage 110/220V
Price
$40900
$42309
$53584
$63723
Ratings
(42)
(13)
(60)
(66)
View ProductView ProductView ProductView Product

Specifications

Dimensions

Product Depth (in.)8Product Height (in.)14
Product Width (in.)17

Details

Duty Cycle (%)60Engine PowerElectric (AC)
IncludedAdditional Tips,Tips,TorchInput Power (Volts)220
Material Application Thickness (in.)0.5Maximum amperage output (amps)50
Minimum amperage output (amps)10Output Current ModeDC
Rated Output (Volts)100Returnable90-Day
Welder TypeMulti-Process,Plasma Cutter,Stick,TIG

Warranty / Certifications

Manufacturer Warranty1 year parts and labor limited warranty

Questions & Answers

Typical questions asked about products:

  • Is the product durable?
  • Is the product easy to use?
  • What are the dimensions of the product?

Customer Reviews

  • 3.9
    out of 13 reviews
  • 71%recommend this product
Filter by:
Showing 1-10 of 13 reviews
So far so good!
I purchased this unit because of its capability to do both plasma cutting and TIG welding. I have used other popular name-brand units that were separate TIG and plasma cutter units, and this LOTOS unit is just as capable for less than half the price of the name-brand units! This unit will cut 1/4" steel with no difficulty as long as you are patient and move slowly. I have used the TIG welder functionality and the output is sufficient to weld very thick steel as long as the operator understands how to weld using TIG. Overall I'm very impressed with the value! Highlights: * The plasma cutter consumables (nozzles, electrodes, etc.) are common and found online at affordable prices. * The TIG torch is a standard WP-17 air-cooled torch and cups, collets, electrodes, replacement parts, and consumables are all readily available in your local welding store. * The input power source can be either 110V or 220V. It uses a standard 30-Amp twist-lock plug which I also bought the receptacle from my local Home Depot store. * Changing between TIG/plasma/stick functions is easy and requires only a 3/4 wrench in most cases. * There were many complaints about the user manual, but the recent May 2014 version of the manual appears to be very comprehensive! Observations: * I went ahead and purchased the additional control pedal from the manufacturer for use with the TIG. * The gas line input uses barbed hose fittings and a braided hose line which is not preferred by me. * The hose clamps that come with the unit are insufficient and the additional barbed fittings to use to make a gas/air manifold valve system don't appear to be 1/4"NPT (they leaked when installed). I ended up purchasing new NPT barbed fittings, stainless hose clamps, and 1/4" reinforced hose from my local Home Depot store. * Although the TIG torch is a standard WP-17 torch, the connection to the unit is not standard because it needs to be interchangeable with the connection for the plasma torch. * The ground clamp wire is pretty short compared to the plasma/TIG/stick cables. It does use the standard "Dinse" connector, so a longer one of thicker wire gauge can be made easily. * The plasma/TIG torch connector on the unit is kind of a cheap bulkhead connector and will spin if over-tightened. To prevent this, I have to hold the case with a pair of adjustable pliers and tighten/loosen the fitting with the 3/4" wrench.
by
  • DIY
  • Verified Purchase
  • Recommended
32 found this review helpful
You might go elsewhere...
With plasma, the unit is rated to cut up to 5/8" (severe). I tried ot cut an inch or so of 1/2" steel. The unit will shut down in less than 30 seconds if trying to cut on full power. 1/8" material is doable for durations up to a minute or so before the yellow light comes on (duty cycle max achieved) at which time you have to let the machine cool, shut down and restart to continue. You may consider going with something more substantial if you want to do any moderate amount of plasma cutting with the unit...
by
    This machine is light weight and very user friendly it...
    This machine is light weight and very user friendly it took very little effort to be welding and cutting with it, from box to in use took less than a half hour for the price I’m very. Happy with it
    by
    • Verified Purchase
    There was a dent in my machine....
    There was a dent in my machine.
    by
    • Verified Purchase
    works very well love it
    works very well love it
    by
    • Verified Purchase
    • Recommended
    The lotus has met my expectations.. the unit showed up...
    The lotus has met my expectations.. the unit showed up on time as indicated in shipping status, the unit is quality for the $. It welds well, I do suggest buying upgraded cups and tungsten. Also get the pedal for it. Worth the extra $.
    by
    • Verified Purchase
    1 found this review helpful
    Not very happy with the cutting it said can cut...
    Not very happy with the cutting it said can cut 1/2 in and I could not get it to cut 1/8 in very well
    by
    • Verified Purchase
    3 found this review helpful
    It is a Great welder and plasma cutter, I love...
    It is a Great welder and plasma cutter, I love it well worth the money
    by
    • Verified Purchase
    5 Star Review
    Rating provided by a verified purchaser
    by
    • Verified Purchase
    Works great.
    The Machine Works Great in My case. Just the ticket..would recommend to friends.
    by
      • Recommended
      1 found this review helpful
