SHOCKWAVE 1/4-20 UNC Steel Impact Rated Drill Tap Bit

  • Ideal for drilling and tapping at the same time
  • 1/4"-20" UNC Impact Drill Tap Bits
  • 20 Threads per inch for use in up to 1/4" metal
  • See More Details

Frequently Bought Together

+
+
Price:

Product Overview

The Milwaukee SHOCKWAVE 1/4 in. - 20 in. UNC Impact Drill Tap Bits tap and drill at the same time. The bits features 24 threads per in. and is intended for use in up to 1/4 in. metal. The drill and tap bits have laser etched sizes for easy size identification. The tap drill bit is design for use in Impact Drivers and Drill Drivers.
  • Ideal for drilling and tapping
  • 1/4-20 UNC
  • 20 threads per inch
  • Laser etched size for easy size identification
  • 1/4 in. quick change hex shank
  • Designed for use in impact drivers and drill drivers
  • For use in up to 1/4 in. metal
  • Shop All Milwaukee Tools

Info & Guides

You will need Adobe® Acrobat® Reader to view PDF documents. Download a free copy from the Adobe Web site.

Specifications

Dimensions

Assembled Depth (in.)
0.25 in
Assembled Height (in.)
2.21 in
Assembled Width (in.)
0.25 in
Bit Length (in.)
2.21
Shank Diameter
1/4 in
Shank Diameter
1/4 in

Details

Bit Material
Steel
Drill Bit Type
Specialty
Drill Bit Type(s) Included
Specialty
Individual/Set
Individual
Material Application
Angle Iron,Duct/Sheet Metal,Steel
Returnable
90-Day
Self-Feeding
Yes
Shank Style
Hex
Tools Product Type
Power Tool

Questions & Answers

1Questions4Answers

Can this be used on stainless steel?

Asked by George June 12, 2020
4
Answers

Yep.

Customer Reviews

  • 4.2
    out of 55 reviews
  • 82% recommend this product
Filter by:
Showing 1-10 of 55 reviews
Snapped on the fourth usage
For the first three holes I drilled in 1/8" aluminum this product worked pretty well, the hardest part always being the reverse; for some reason it's a cutting edge in both directions on the tapping segment, so it has a tendency to catch on the threads you just created rather than going back through smoothly like it should. If you aren't careful you could end up with an injured hand from the drill because it halts every time I used it. On the fourth hole I drilled, I was being careful and coming back out slowly when it suddenly caught and easily snapped the bit, leaving it lodged in my piece. I was able to extract it with some pliers and a lot of finagling, but really disappointed at how little value I got out of the bit. If you buy this, you might want to drill the hole, stop and remove the bit from your chuck, then twist it out by hand. Not sure if that would work better but it might be worth trying.
by Garrett
Broke off in 1st hole!
Using this to tap in 1/8” mild tube steel railing. Broke off in railing and took forever to get out. Never again.
by Cole
Response from Milwaukee ToolMar 10, 2021
Hello, this is Natalie with Milwaukee Tool. Cole, thank you for taking the time to leave your review. I'm sorry to hear about your frustrations with your SHOCKWAVE 1/4-20 UNC Steel Impact Rated Drill Tap Bit. We would value the opportunity to learn more about your experience and provide you with support, so please reach out to us directly at socialmedia@milwaukeetool.com. Thank You
Drill/Tap bit worked out great, now my bike seat post clamp has a stronger stainless steel screw ...
Drill/Tap bit worked out great, now my bike seat post clamp has a stronger stainless steel screw is the new hardware to keep the clamp closed and tight. Now the seat post will not drop down & move, left or right while I riding!!!
by Cavey
I was excited to see this product as a time saver. It was marked as impact ready. The very first ...
I was excited to see this product as a time saver. It was marked as impact ready. The very first use the product shattered leaving a big chunk wedged in the sheet metal creating more work. I was using Ridgid cordless and had to spend time removing the broken bit. See image of product was still in barely used condition.
by SDM
One of the most unique Milwaukee tools for the metal fabricator or hobbyist. Drill Tap Bits tap a...
One of the most unique Milwaukee tools for the metal fabricator or hobbyist. Drill Tap Bits tap and drill at the same time. The bits features 32 threads per inch and is intended for use in up to 1/4" metal. The drill and tap bits have laser etched sizes for easy size identification. The tap drill bit is designed for use in Impact Drivers & Drill Drivers.This one is 1/4" -20 thread and I find it the most useful in my garage. Very neat idea. Sold in sets or individually.
by Bill
I love Milwaukee Tools because of their high quality and overall durability. This drill tap bit a...
I love Milwaukee Tools because of their high quality and overall durability. This drill tap bit and the other 2 I just got will be very welcome additions to my tool collection I you ave ever had to deal with stripped threading you know these babies are sort their weight in gold Everyone who turns a wrench really needs to have some of these in their tool kits.
by Swede
Having a drill bit and tap in the same product is a genius idea, and coupled with the quality of ...
Having a drill bit and tap in the same product is a genius idea, and coupled with the quality of the SHOCKWAVE product line this is a well made, reasonably priced, and very useful addition to my DIY repair arsenal. I do not usually have to drill and tap metal, but recently have had the need to do so more than once and this has been extremely useful and a real time saver. The bit is extremely sharp and cuts thru aluminum like butter. The countersink feature is really nice as well. Did not come with instructions, but was easy to figure out; it did take me a bit to figure out it was 20 threads per inch (TPI), as I am relatively new to tap work. A nice addition to my DIY arsenal!
by profcah
An amazing trick! I used to buy drill and tap bolts when bolting things onto the steel supports o...
An amazing trick! I used to buy drill and tap bolts when bolting things onto the steel supports of my carport, but now that I have this, I can use regular ¼” course thread bolts instead. I use my impact driver to power this bit. It drills through the steel and then the die threads bite in and form a threaded hole. I extract it carefully using a slow speed so that the threads are not harmed as the bit is removed. ¼” course thread bolts and rods thread easily into the holes produced. (There are 20 threads per inch.) The driving end is a standard ¼” hexagonal drive allowing quick changes. The size (1/4”) is laser etched on the shanks for quick identification. A nice touch. Made in China
by Dale
The Milwaukee shockwave steel drill tap bit works well to both drill and immediately tap into met...
The Milwaukee shockwave steel drill tap bit works well to both drill and immediately tap into metal in the same operation. I found it to be well designed and operate as expected. One thing to be aware of when using it is to be mindful of the depth of the thread capacity when working with thin material. Fully running the bit through the stock can cause the bit to run out of threads. This is not a huge problem, but can cause a little grief to get the bit out after the tap process by restarting it in reverse. Just be careful to slowly do the tap portion of the job to save some time getting the tool out of the stock.
by TrussvilleDIYGuy
Milwaukee shockwave 1/4 inch steel drill and tap bit is great for drilling hole and setting threa...
Milwaukee shockwave 1/4 inch steel drill and tap bit is great for drilling hole and setting threads at the same time. It is very strong and stays sharp. We build utility trailers it works great for pre-drilling hole for screw on fenders and bed rails, my son can keep up with me running in the screws as fast as I drill them know, we was having to drill, then tap treads, then screw. Now done all at once. I had to buy a couple. Very nice.
by djbjiffy
Showing 1-10 of 55 reviews
