#1 Home Improvement Retailer

Internet #303864021

Model #435191

Store SKU #1003322062

1/4 in. PVC Toilet Flange Spacer

$504
  • Rings can be stacked on closet flange to achieve desired height
  • Robust 1/4 in. thick PVC construction
  • Toilet flange spacer comes with 6 holes for secure attachment
  • View More Details
Store
0 in stock
Text to Me
How to Get It

Product Overview

Closed toilet flange

Testable Closet Flanges

Made with a test cap that easily and cleanly breaks out, eliminating the possibility of falling down the DWV line.

Metal toilet flange ring flush with the bathroom floor

Open Closet Flanges

Ring provides a crack-resistant connection between the water closet outlet and plumbing system that is flush with the floor.

ABS toilet flange with metal ring

Spigot Fit Closet Flanges

Spigot fit sits flush with the floor and allows for a quick and easy connection to the piping system.

PVC open toilet flange

Open

The open toilet flange requires a test plug or cap for pressure testing and is primarily used in repair work.

PVC closed toilet flange

Closed

The closed toilet flange with pre-installed ability for pressure testing is primarily used in new construction.

PVC with metal ring flange

Specialty

The 45-degree and offset specialty toilet flanges allow for margin of error in drain/pipe alignment.

ABS repair flange

Repair

The repair toilet flange replaces broken cast iron flanges.

Flange fitting inside pipe

Repair/Remodel Connection

Inside fit. Not code approved.

Flange fitting outside pipe

Inside/Outside Connection

Inside/ouside fit.

Flange fitting outside pipe

Hub Connection

Outside fit.

Flange fitting with spigot connection

Spigot Connection

Same size as pipe. Requires fitting.

Flange fitting pipe offset

Offset Connection

Inside/outside fit.

Flange fitting inside pipe

Twist-N-Set Connection

Inside fit. Not code approved.

Oatey Closet Flange Spacer builds up existing closet flanges when installing new flooring and renders finished floor height below grade. The stackable feature accommodates a wide range of height adjustments. Oatey products have earned the trust of plumbing professionals for over 100 years.
  • Spacer builds up existing toilet flange on below-grade flooring
  • 1/4 in. thick
  • Up to 3 can be stacked together
  • Builds up existing toilet flange when new flooring is installed
  • For use when overlaying, replacing or tiling bathroom floors
  • Can be solvent welded on its horizontal surface using PVC solvent cement or secured using mechanical means
  • Can be stacked to desired height, up to a maximum of 3 rings
  • 1-pack

Additional Resources

From the Manufacturer

You will need Adobe® Acrobat® Reader to view PDF documents. Download a free copy from the Adobe Web site.

Compare Similar Toilet Flanges

7 in. O.D. PVC Water Closet (Toilet) Flange Ring, Fits Over 3 in. PVC DWV Pipe
current product
1/4 in. PVC Toilet Flange Spacer
Fast Set 4 in. PVC Hub Spigot Toilet Flange with Test Cap and Stainless Steel RingFast Set 4 in. PVC Hub Toilet Flange with Test Cap and Stainless Steel Ring
Brand OATEYOATEYOATEY
Name7 in. O.D. PVC Water Closet (Toilet) Flange Ring, Fits Over 3 in. PVC DWV Pipe1/4 in. PVC Toilet Flange SpacerFast Set 4 in. PVC Hub Spigot Toilet Flange with Test Cap and Stainless Steel RingFast Set 4 in. PVC Hub Toilet Flange with Test Cap and Stainless Steel Ring
Price
$395
$630
$1011
$1205
Ratings
(0)
(47)
(61)
(63)
MaterialPVCPVCPVCPVC
Flange TypeFlange repair ringFlange repair ringAnchor flangeAnchor flange
Plumbing Part TypeToilet FlangeToilet FlangeToilet FlangeToilet Flange
Product Depth (in.)7.0 in77.27.2
Product Height (in.)0.50 in.252.72.7
Features No Additional FeaturesNo Additional FeaturesNo Additional Features
View ProductView ProductView ProductView Product

Specifications

Dimensions

Product Depth (in.)
7
Product Height (in.)
.25
Product Width (in.)
7

Details

Color/Finish Family
White
Features
No Additional Features
Flange Included
No
Flange Type
Flange repair ring
Material
PVC
Pack Size
1
Plumbing Part Type
Toilet Flange
Provides Extension
No
Returnable
90-Day
Sleeve Included
No

Warranty / Certifications

Manufacturer Warranty
1 Year Limited

Questions & Answers

Typical questions asked about products:

  • Is the product durable?
  • Is the product easy to use?
  • What are the dimensions of the product?

Customer Reviews

  • 4.5
    out of 47 reviews
  • 83%recommend this product
Filter by:
Showing 1-10 of 47 reviews
Holes do not line up with Oatey flange, does not fit underneath
I need a spacer to get flange to tile height. Since I re-did the entire setup, I am using a new flange also. I want to place spacers on the tile backerboard so I can get to tile height without having to screw thru the tile. Drilling pilot holes thru porcelain tiles is not easy, so using the spacer is the preferred option. This also eliminates any concern of a broken PVC spacer when using a flange with SS ring. The PVC spacer will not see any stress other than being pushed straight down. Two issues with this item. I am using an Oatey flange with SS ring which has screw holes, as does the spacer. Except that the holes do not line up at all. Same brand, same # of holes, but only 2 line up. Brilliant job Oatey. Second issue is this will not fit underneath the Oatey flange, only on top. This is not stated anywhere that I can find. I would return, but since my HD has zero other options, I am stuck modifying this flange if I want to get this toilet installed quickly. PVC quality is good and set on top of flange well, but screw holes would still need to be modified.
by
    1 found this review helpful
    Excellent product but check the closet bolt pattern in your existing flange. Toilet flanges have ...
    Excellent product but check the closet bolt pattern in your existing flange. Toilet flanges have cut-outs to accept the head of the closet bolt. You then slide the closet bolt to a narrower portion of the slot in the flange that keeps the head of the closet bolt secure when securing the toilet. Some toilet flanges require the bolts to be moved in a clock wise direction (and this spacer will work quite nicely with those flanges). Other flanges require the bolts to be moved in a counter clock-wise direction which could be problematic if you ever needed to remove your closet bolts. Just line up the space with your flange to make sure everything lines up - especially closet bolt slots before installing. The product itself is strong and well made. I picked this up to use in a bathroom where I removed the old tile floor and laid down under floor heating before installing the new tile floor. This flange gave me the height I needed for the increased height of the new floor.
    by
    • Recommended
    12 found this review helpful
    Working on a home that the toilet flange is lower than the flooring and this spacer did the trick...
    Working on a home that the toilet flange is lower than the flooring and this spacer did the trick. It’s pretty much self explanatory but i did have some difficulty lining up the holes to the actual flange. But in the end it worked out. It was pretty easy to install Just some silicone between the flange and the spacer and screwed it down. The 1/4 inch thickness was exactly what I needed to raise it above the flooring a bit. PVC material it’s made of seems pretty solid and when I screwed it down and finished the install I felt good it held up good to any tightening I did. Good product and i had no leaks. I’d recommend it to anyone with the flooring being higher than the flange.
    by
    • Recommended
    1 found this review helpful
    I needed to raise my toilet flange up because it was sitting below the tiles. When I installed a ...
    I needed to raise my toilet flange up because it was sitting below the tiles. When I installed a new ceramic tile floor. The flange should sit on top of the tiles. I went to Home Depot and picked up a Oatey 1/4 in. PVC flange spacer. The spacer is white in color and 7 in. in circumference and has 6 anchor holes to secure the spacer to your original flange and subfloor. This spacer is really durable PVC and made very well. I cleaned the existing flange and used silicone between the flange and spacer and then I screwed it to the floor. The manufacturer recommends using no more than 3 spacers per application. I want to let you know this spacer is not a toilet flange. If I called a plumber in to fix this, he would have wanted to cut the waste line and extend the pipe and install a new toilet flange. This would have been very expensive. Thanks Oatey I enjoyed using the 1/4 in. Flange spacer. It was a breeze to install. This Oatey spacer will save you time and money. I recommend this product if you run into the same problem I did with the floor.
    by
    • Recommended
    7 found this review helpful
    did the job... for that situation... low cost .. ...
    did the job... for that situation... low cost .. great
