Internet #204318424

Model # XG40T06PV40U0

Store SKU #1000035126

Store SO SKU #1000109992

0020352625669

Rheem

Performance 40 Gal. Tall 6 Year 40,000 BTU Natural Gas Power Vent Tank Water Heater

$ 902 31
Loading Options
store icon Loading Buying Options...
package icon Loading Buying Options...
Sorry, but we ran into issues loading these options. Please try refreshing.

Frequently Bought Together

Frequently Bought Together

Product Overview

The Rheem Performance 40 Gal. Natural Gas Tall Power Vent Water Heater comes with a 40,000 BTU/hour environmentally friendly low NOx burner that provides ample hot water for households with 2 to 4 people. The electronic ignition system ensures safe and easy startup. Its maintenance free combustion air intake system means there are no filters to clean and replace. The self-diagnostic gas control valve monitors system performance. A premium grade anode rod provides long lasting tank protection. Factory installed temperature and pressure relief valve and 3/4 in. water connections are included with the water heater for easy installation. This water heater is ENERGY STAR qualified.
  • California & Utah Residents (Utah Effective 7/1/18): THIS WATER HEATER DOES NOT MEET ULTRA LOW NOX (ULN) EMISSIONS REQUIREMENTS. REGULATIONS PROHIBIT THE SALE, SHIPMENT OR INSTALLATION OF THIS WATER HEATER IN ANY AIR QUALITY DISTRICT THAT REQUIRES ULN WATER HEATERS. Please refer to the maps below to confirm if your home is in a district that requires ULN emission water heaters, and if so please select an approved ULN model.
  • Requires standard 110-Volt electrical outlet (3-prong grounded) for installation
  • 40 Gallon tank provides ample hot water for households with 2 to 4 people
  • Natural gas water heater costs less to operate than electric models
  • Delivers 86 Gal. of hot water in the first hour
  • 6-year limited warranty on tank and parts for your convenience
  • 1-year in home labor warranty for peace of mind
  • 0.69 uniform energy factor indicates an ENERGY STAR qualified water heater
  • Maintenance free - no filter to clean or replace
  • Electronic ignition system simplifies the startup process
  • Self-diagnostic gas valve monitors system performance
  • Can be vented vertically or horizontally up to 100 ft. to suit any application
  • Vents with PVC, CPVC or ABS
  • Designed for easy replacement of your existing water heater
  • Call 1-855-400-2552 before noon for same-day service in most areas, or Visit our Water Heater Installation page for more information.
  • Click here to learn more about Eco Options and Energy Efficiency
  • Meets 2015 NAECA standards



  • Click here for more information on Electronic Recycling Programs
  • California residents see Prop 65 WARNINGS

Product Overview

Model #: XG40T06PV40U0
Sku #: 1000035126
Internet #: 204318424

The Rheem Performance 40 Gal. Natural Gas Tall Power Vent Water Heater comes with a 40,000 BTU/hour environmentally friendly low NOx burner that provides ample hot water for households with 2 to 4 people. The electronic ignition system ensures safe and easy startup. Its maintenance free combustion air intake system means there are no filters to clean and replace. The self-diagnostic gas control valve monitors system performance. A premium grade anode rod provides long lasting tank protection. Factory installed temperature and pressure relief valve and 3/4 in. water connections are included with the water heater for easy installation. This water heater is ENERGY STAR qualified.

  • California & Utah Residents (Utah Effective 7/1/18): THIS WATER HEATER DOES NOT MEET ULTRA LOW NOX (ULN) EMISSIONS REQUIREMENTS. REGULATIONS PROHIBIT THE SALE, SHIPMENT OR INSTALLATION OF THIS WATER HEATER IN ANY AIR QUALITY DISTRICT THAT REQUIRES ULN WATER HEATERS. Please refer to the maps below to confirm if your home is in a district that requires ULN emission water heaters, and if so please select an approved ULN model.
  • Requires standard 110-Volt electrical outlet (3-prong grounded) for installation
  • 40 Gallon tank provides ample hot water for households with 2 to 4 people
  • Natural gas water heater costs less to operate than electric models
  • Delivers 86 Gal. of hot water in the first hour
  • 6-year limited warranty on tank and parts for your convenience
  • 1-year in home labor warranty for peace of mind
  • 0.69 uniform energy factor indicates an ENERGY STAR qualified water heater
  • Maintenance free - no filter to clean or replace
  • Electronic ignition system simplifies the startup process
  • Self-diagnostic gas valve monitors system performance
  • Can be vented vertically or horizontally up to 100 ft. to suit any application
  • Vents with PVC, CPVC or ABS
  • Designed for easy replacement of your existing water heater
  • Call 1-855-400-2552 before noon for same-day service in most areas, or Visit our Water Heater Installation page for more information.
  • Click here to learn more about Eco Options and Energy Efficiency
  • Meets 2015 NAECA standards



  • Click here for more information on Electronic Recycling Programs
  • California residents see Prop 65 WARNINGS

Info & Guides

You will need Adobe® Acrobat® Reader to view PDF documents. Download a free copy from the Adobe Web site.

Key Features

Product Overview
Key Features
The Rheem Performance 40 Gal. Natural Gas Tall Power Vent Water Heater comes with a 40,000 BTU/hour environmentally friendly low NOx burner that provides ample hot water for households with 2 to 4 people. The electronic ignition system ensures safe and easy startup. Its maintenance free combustion air intake system means there are no filters to clean and replace. The self-diagnostic gas control valve monitors system performance. A premium grade anode rod provides long lasting tank protection. Factory installed temperature and pressure relief valve and 3/4 in. water connections are included with the water heater for easy installation. This water heater is ENERGY STAR qualified.
  • California & Utah Residents (Utah Effective 7/1/18): THIS WATER HEATER DOES NOT MEET ULTRA LOW NOX (ULN) EMISSIONS REQUIREMENTS. REGULATIONS PROHIBIT THE SALE, SHIPMENT OR INSTALLATION OF THIS WATER HEATER IN ANY AIR QUALITY DISTRICT THAT REQUIRES ULN WATER HEATERS. Please refer to the maps below to confirm if your home is in a district that requires ULN emission water heaters, and if so please select an approved ULN model.
  • Requires standard 110-Volt electrical outlet (3-prong grounded) for installation
  • 40 Gallon tank provides ample hot water for households with 2 to 4 people
  • Natural gas water heater costs less to operate than electric models
  • Delivers 86 Gal. of hot water in the first hour
  • 6-year limited warranty on tank and parts for your convenience
  • 1-year in home labor warranty for peace of mind
  • 0.69 uniform energy factor indicates an ENERGY STAR qualified water heater
  • Maintenance free - no filter to clean or replace
  • Electronic ignition system simplifies the startup process
  • Self-diagnostic gas valve monitors system performance
  • Can be vented vertically or horizontally up to 100 ft. to suit any application
  • Vents with PVC, CPVC or ABS
  • Designed for easy replacement of your existing water heater
  • Call 1-855-400-2552 before noon for same-day service in most areas, or Visit our Water Heater Installation page for more information.
  • Click here to learn more about Eco Options and Energy Efficiency
  • Meets 2015 NAECA standards



  • Click here for more information on Electronic Recycling Programs
  • California residents see Prop 65 WARNINGS

Product Overview

Model #: XG40T06PV40U0
Sku #: 1000035126
Internet #: 204318424

The Rheem Performance 40 Gal. Natural Gas Tall Power Vent Water Heater comes with a 40,000 BTU/hour environmentally friendly low NOx burner that provides ample hot water for households with 2 to 4 people. The electronic ignition system ensures safe and easy startup. Its maintenance free combustion air intake system means there are no filters to clean and replace. The self-diagnostic gas control valve monitors system performance. A premium grade anode rod provides long lasting tank protection. Factory installed temperature and pressure relief valve and 3/4 in. water connections are included with the water heater for easy installation. This water heater is ENERGY STAR qualified.

  • California & Utah Residents (Utah Effective 7/1/18): THIS WATER HEATER DOES NOT MEET ULTRA LOW NOX (ULN) EMISSIONS REQUIREMENTS. REGULATIONS PROHIBIT THE SALE, SHIPMENT OR INSTALLATION OF THIS WATER HEATER IN ANY AIR QUALITY DISTRICT THAT REQUIRES ULN WATER HEATERS. Please refer to the maps below to confirm if your home is in a district that requires ULN emission water heaters, and if so please select an approved ULN model.
  • Requires standard 110-Volt electrical outlet (3-prong grounded) for installation
  • 40 Gallon tank provides ample hot water for households with 2 to 4 people
  • Natural gas water heater costs less to operate than electric models
  • Delivers 86 Gal. of hot water in the first hour
  • 6-year limited warranty on tank and parts for your convenience
  • 1-year in home labor warranty for peace of mind
  • 0.69 uniform energy factor indicates an ENERGY STAR qualified water heater
  • Maintenance free - no filter to clean or replace
  • Electronic ignition system simplifies the startup process
  • Self-diagnostic gas valve monitors system performance
  • Can be vented vertically or horizontally up to 100 ft. to suit any application
  • Vents with PVC, CPVC or ABS
  • Designed for easy replacement of your existing water heater
  • Call 1-855-400-2552 before noon for same-day service in most areas, or Visit our Water Heater Installation page for more information.
  • Click here to learn more about Eco Options and Energy Efficiency
  • Meets 2015 NAECA standards



  • Click here for more information on Electronic Recycling Programs
  • California residents see Prop 65 WARNINGS

Info & Guides

You will need Adobe® Acrobat® Reader to view PDF documents. Download a free copy from the Adobe Web site.

Compare Similar

Compare Similar Products
Brand Rheem Rheem Rheem Rheem
Name Performance 29 Gal. Tall 6 Year 32,000 BTU Natural Gas Tank Water Heater Performance 75 Gal. Tall 6 Year 76,000 BTU Natural Gas Tank Water Heater Performance 40 Gal. Tall 6 Year 40,000 BTU Natural Gas Power Vent Tank Water Heater Performance 40 gal. Tall 6-Year 36,000 BTU Ultra Low NOx (ULN) Natural Gas Power Vent Tank Water Heater
Price
$485.94
$859.74
$902.31
$909.68
Ratings (2578) (142) (824) (10)
Water Heater Features LoNox,Overheat Protection,Pilot Light Window,Pilot Reset Button,Temperature Pressure Relief Valve Overheat Protection,Pilot Light Window,Pilot Reset Button,Temperature Pressure Relief Valve LoNox,Overheat Protection,Pilot Light Window,Pilot Reset Button,Temperature Pressure Relief Valve Overheat Protection,Pilot Light Window,Pilot Reset Button,Temperature Pressure Relief Valve,Ultra LoNox
Gas Type Natural Gas Natural Gas Natural Gas Natural Gas
Water Heater Profile Tall Tall Tall Tall
View Product View Product View Product View Product

Specifications

Dimensions

Product Depth (in.)
19.75
Product Height (in.)
59
Product Width (in.)
19.75
Tank Valve Size (in.)
.75
Water Connection Size (in.)
.75

Details

Application Type
Residential
Finish Family
Gray
Fuel Type
Gas
Gas Type
Natural Gas
Indoor/Outdoor
Indoor
Maximum Temperature (F)
160
Minimum Temperature (F)
45
Nominal Tank Capacity (gallons)
40
Product Weight (lb.)
140lb
Rated Tank Capacity (gallons)
38
Recovery Rate at 90F Rise (gallons/hour)
40.4
Returnable
90-Day
Tank Lining Material
Glass
Tank Warranty
6 Year
Uniform Energy Factor
0.69
Water Heater Features
LoNox,Overheat Protection,Pilot Light Window,Pilot Reset Button,Temperature Pressure Relief Valve
Water Heater Profile
Tall
Wattage (watts)
0

Warranty / Certifications

Labor Warranty
1 Year
Part Warranty
6 Year

Specifications

Dimensions

Product Depth (in.)
19.75
Product Height (in.)
59
Product Width (in.)
19.75
Tank Valve Size (in.)
.75
Water Connection Size (in.)
.75

Details

Application Type
Residential
Finish Family
Gray
Fuel Type
Gas
Gas Type
Natural Gas
Indoor/Outdoor
Indoor
Maximum Temperature (F)
160
Minimum Temperature (F)
45
Nominal Tank Capacity (gallons)
40
Product Weight (lb.)
140lb
Rated Tank Capacity (gallons)
38
Recovery Rate at 90F Rise (gallons/hour)
40.4
Returnable
90-Day
Tank Lining Material
Glass
Tank Warranty
6 Year
Uniform Energy Factor
0.69
Water Heater Features
LoNox,Overheat Protection,Pilot Light Window,Pilot Reset Button,Temperature Pressure Relief Valve
Water Heater Profile
Tall
Wattage (watts)
0

Warranty / Certifications

Labor Warranty
1 Year
Part Warranty
6 Year

Questions & Answers

Can this water heater be transported horizontally? (Lying flat in a pickup bed).

Can this water heater be transported horizontally? (Lying flat in a pickup bed).
Asked by: PearlSporty
There should be no issue with transporting the Rheem Hot water heater on its side.
Answered by: Vince
Date published: 2019-04-05

I see that HD sells vent kits. the plumber that we are using to install this tank, suggested we b...

I see that HD sells vent kits. the plumber that we are using to install this tank, suggested we buy the vent kit from HD that "fits" this water heater with the power vent function. which vent kit will work with this heater? our install is in our basement.
Asked by: carl
I just made my own. A few pieces of CPVC to send it out the side wall. I believe the horizontal piece must be at least 3 feet long. The specs are in the instructions.
Answered by: chas
Date published: 2019-01-28

If you have a water heater with power vent - do you need to replace it with same one?

Our water heater is going, apparently making strange noises from the power vent, also has crystals on top of water heater. Do you need to replace it with exact same kind or can we get normal water heater?
Asked by: Chrissy
No, you can get a cheaper one probably 40k btu will do. Just need to get reducer to connect b vent pipe to PVC pipe and you'll be set.
Answered by: Terry
Date published: 2018-12-19

If the power vent STOP working, will that make the water heater not work wright ??? this is a Loc...

If the power vent STOP working, will that make the water heater not work wright ??? this is a Lochinvar 40 gal. standing unit LVN041
Asked by: Snitch
Power vent has to work otherwise water will not heat up
Answered by: Wc
Date published: 2019-07-12
  • y_2019, m_8, d_20, h_8CST
  • bvseo_bulk, prod_bvqa, vn_bulk_2.0.13
  • cp_1, bvpage1
  • co_hasquestionsanswers, tq_158
  • loc_, sid_204318424, prod, sort_[SortEntry(order=NUM_ANSWERS, direction=DESCENDING), SortEntry(order=SUBMISSION_TIME, direction=DESCENDING), SortEntry(order=LAST_APPROVED_ANSWER_SUBMISSION_TIME, direction=DESCENDING), SortEntry(order=LAST_APPROVED_ANSWER_SUBMISSION_TIME, direction=DESCENDING), SortEntry(order=BEST_ANSWER_FEEDBACK_COUNT, direction=DESCENDING), SortEntry(order=POSITIVE_ANSWER_FEEDBACK_COUNT, direction=DESCENDING), SortEntry(order=NUM_ANSWERS, direction=DESCENDING)]
  • clientName_homedepot
  • bvseo_sdk, java_sdk, bvseo-3.1.1
  • CLOUD, getContent, 55ms
  • QUESTIONS, PRODUCT

Customer Reviews

Performance 40 Gal. Tall 6 Year 40,000 BTU Natural Gas Power Vent Tank Water Heater is rated 4.2 out of 5 by 824.
Rated 1 out of 5 by from I installed the Rheem 40 gallon power vent unit in 2013. It started leaking in June of 2019. Be... I installed the Rheem 40 gallon power vent unit in 2013. It started leaking in June of 2019. Because it failed on Sunday, I was forced to get another Rheem this time the 50gal. as selection is non existent for power vent units. I was floored the 6 year old 40 gallon had leaked all over my basement. I probably would have held out until the weekday for a different brand, but I am selling my house and this was the most convenient. I will never buy another Rheem product again in a house I plan on keeping.
Date published: 2019-06-03
Rated 3 out of 5 by from This Rheem Power Vent Water Heater has a tech design defect. There is a fuel vapor sensor that is... This Rheem Power Vent Water Heater has a tech design defect. There is a fuel vapor sensor that is wrongly placed at the very bottom about one inch from the ground. Any vapor even water vapor sets off this sensor and shuts down the water heater. Once the sensor has been set off, resetting is only temporary as in a few weeks it will set off again and will need to be replaced. Home Depot does not carry this part and it needs to be ordered from Rheem and they try their very best not to send you one and delay it till you keep calling again and again. A O Smith had relocated this vapor sensor to the side about a foot higher as it sets off due to false positive. Unless Rheem redesigns this water heater like A O Smith did with the fuel vapor sensor much higher and to the side, this is a DO NOT BUY this product
Date published: 2019-08-06
Rated 1 out of 5 by from I installed the water heater and it would not fire.... I installed the water heater and it would not fire. 6 days later Rheem sent a technician out and got it going. Bad control valve from the factory. Home Depot wanted me to uninstall the water heater and bring it back for exchange. Carry some parts for appliances that you sell !!!
Date published: 2019-06-08
Rated 1 out of 5 by from Failures I recently purchased a rental property. The existing water heater was serviceable, but old. I didn't want to be inconvenienced when the residence moved in by having a problem with the water heater so I had a new unit from home Depot installed. It failed a month after the residents moved in. I asked Rheem to authorize a replacement, but they refused and instead asked me to install replacement parts. After waiting a week for Rheem to send me new parts and spending a day replacing the power vent, I realized the control unit had failed. Rheem wanted to mail me a new control unit, but I again asked for them to authorize the replacement and they agreed. Except their contractor was only available for scheduling between the hours of 8am and noon on weekdays. It took about week to get it replaced. I needed to give my residents a break on their rent for the month. It was very disappointing. Go to Lowe's and get an AO Smith, don't waste your time with the Rheem, poor quality and they don't stand behind their work.
Date published: 2018-12-09
Rated 5 out of 5 by from I installed this to replace a 25 year old power vent water heater that was leaking. The new unit... I installed this to replace a 25 year old power vent water heater that was leaking. The new unit was approximately the same size so it fit into the existing space. As expected the water lines did not line up so plan for some plumbing work. The gas line lined up perfectly so that was simple. The PVC flu is very easy to install, but it would be greatly improved with some type of through wall fitting. It's been running for 2 weeks now and it working great. The exhaust blower is much quieter than my old one. Take care that the vent pipe is not vibrating against anything. The one issue found during installation is that the exhaust pipe is very close to the cold water inlet. This problem was not evident until all of the water plumbing was in place and I went to install the flue and the vent pipe interfered with the knob on the water valve. I had to either remove the knob or rework the plumbing to solve the issue. See pictures for more detail. Since the blower is installed after the plumping has been completed this is something that should be noted in the manual.
Date published: 2019-04-23
Rated 1 out of 5 by from Flammable Vapor Sensor This hot water heater would be awesome were it not for its use of a flammable vapor sensor (FVS). I had no clue what this sensor was prior to buying this unit. It is a super sensitive control that prevents the gas valve from working when it senses flammable vapors. My unit is in the basement of a 28-year old house with no vapors present. I’ve had to reset the gas control at least 6 times since installing the tank 4-days ago. I’m sure this sensor is a byproduct of our litigious society but it’s ruining my faith in this Rheem hot water tank.
Date published: 2019-07-09
Rated 2 out of 5 by from Generally OK.This is the 3rd one I have installed. Life of tank isn't very good.For no good reaso... Generally OK.This is the 3rd one I have installed. Life of tank isn't very good.For no good reason Rheem changed the location of the vent which required completely new running of the PVC vent pipe. I did a request for installation from Home Depot and the price was ridiculous. $800 to drain tank, unscrew two water fittings, a gas fitting and vent. Remove tank and then reverse procedure. I declined. It took me 1.5 hours to do the entire job.I will NEVER ask Home Depot to do any type of service work
Date published: 2019-08-13
Rated 4 out of 5 by from I selected this Rheem unit to replace a 22 year-old Bradford-White model. The Rheem unit seems w... I selected this Rheem unit to replace a 22 year-old Bradford-White model. The Rheem unit seems well made, but the exhaust blower does not fit well. The placement of the exhaust blower is a bit odd as it is very close to the water inlet and outlet pipes. Other than that, it has been working well. It heats water quickly and the blower is reasonably quiet.
Date published: 2019-08-06
