250 ft. 1/0 Black Stranded CU SIMpull THHN Wire

  • 1/0 AWG commercial wiring for outlets, switches and other loads
  • 1/0 Gauge THHN wire contains Copper (CU) Conductors
  • 1/0 THHN comes stranded with variety of colors and lengths
  • See More Details

Frequently Bought Together

+
+
Price:

Product Overview

Southwires THHN and THWN is a multi-purpose building wire used in conduit and cable trays for service, feeders and branch circuits in commercial and industrial applications. It is also used as a conductor in NM-B, UF-B, SER, SEU and MC. Southwires THHN is rated for 600-Volt and has a heat capacity of up to 90°C.
  • THWN-2- can be used in wet or dry locations
  • Made with annealed (soft) copper, compressed
  • Insulation is high heat and moisture resistant polyvinyl chloride (PVC)
  • Jacket is abrasion, moisture, gasoline and oil resistant nylon
  • UL listed, CSA certified, RoHS compliant
  • Conductors have multiple ratings, THHN, THWN, and AWM

Info & Guides

You will need Adobe® Acrobat® Reader to view PDF documents. Download a free copy from the Adobe Web site.

Compare Similar Building Wires

current product
250 ft. 1/0 Black Stranded CU SIMpull THHN Wire
250 ft. 2/0 Black Stranded CU SIMpull THHN Wire1000 ft. 4 Black Stranded CU SIMpull THHN Wire500 ft. 1/0 Black Stranded CU SIMpull THHN Wire
BrandSouthwireSouthwireSouthwireSouthwire
Name250 ft. 1/0 Black Stranded CU SIMpull THHN Wire250 ft. 2/0 Black Stranded CU SIMpull THHN Wire1000 ft. 4 Black Stranded CU SIMpull THHN Wire500 ft. 1/0 Black Stranded CU SIMpull THHN Wire
Price
Ratings
(7)
(15)
(49)
(7)
Number of Conductors1111
Total Wire Length (ft.)2502501000500
Cable/Wire TypeTHHNTHHNTHHNTHHN
Stranded or SolidStrandedStrandedStrandedStranded
Max Amps15019595170
FeaturesHeat Resistant,UV Resistant,WaterproofHeat Resistant,UV Resistant,WaterproofHeat Resistant,UV Resistant,WaterproofHeat Resistant,UV Resistant,Waterproof
Conductor MaterialCopperCopperCopperCopper
GroundedNon-GroundedNon-GroundedNon-GroundedNon-Grounded
View ProductView ProductView ProductView Product

Specifications

Dimensions

Product Height (in.)
16
Product Width (in.)
15.75
Total Wire Length (ft.)
250

Details

Cable/Wire Type
THHN
Commercial/Residential
Commercial,Residential
Conductor Material
Copper
Electrical Product Type
Single Conductor Electrical Wire
Features
Heat Resistant,UV Resistant,Waterproof
Gauge
1
Grounded
Non-Grounded
Indoor/Outdoor
Indoor,Outdoor
Jacket Color
Black
Max Amps
150
Number of Conductors
1
Returnable
90-Day
Stranded or Solid
Stranded
Wet Location Use
Dry,Wet
Wire Cut Type
Pre-Cut Length

Warranty / Certifications

Certifications and Listings
CSA Certified,UL Listed
Manufacturer Warranty
N/A

Questions & Answers

11Questions13Answers

Is this the same 1/0 wire I can use for a welder?

Asked by RM February 4, 2020
1
Answer

No. This product (THHN) will be much stiffer than welding cable and is intended for installation in conduit per the NEC. Welding Cable is much more flexible and is specifically designed for that application.

How big is the spool of 500 ft 1/0 then copper wire

Asked by Jl12 October 20, 2019
1
Answer

Our 500 ft. 1/0 Black Stranded CU SIMpull THHN Wire is 19.75 in (length) x 19.75 in (width) x 13.75 (height) and weighs about 195.01 lbs in total.

can I use this for service wire to put in a 400 amp service

Asked by bramdaddy April 23, 2019
1
Answer

No it can't you need a 500kcmil Cu THHN.

Is 1/0 stranded copper residential simpull THHN wire the same as 1/0 stranded copper wire used for 12V auto/car jumper cables?

Asked by Boogle March 14, 2019
2
Answers

Hello. It is not the same wire but similar. (Since ‘but’ means forget the prior and here’s the point) you could use this for jumper cables but I highly Do Not recommend this because jumper cables are made to flex. (There are 2 thoughts I’d like to share in addition to the meaning of ‘but’. One, as a child I learned bigger was better (leverage) yet later learned if the wrench is to big it wouldn’t fit in the area to reach the nut. Two, I learn harder to bend and flex better (stronger) yet later I learned if it’s too strong it would break into pieces more easily. Bonus: ‘yet’ means to keep the prior content knowledge and mix with what follows). Jumper Cables: Either buy 2awg (aka 2 gauge) jumper cables at a local auto store or go new tech and buy a portable NOCO Genius Boost. Lastly: I am seriously considering using this wire above in my engine compartment with red split loom for color and temperature protection because I have increased my alternator from 90amps to 120amps and added deep cycle batteries. Thus, if I use this wire for my situation it will be fine because the wire is not changing it’s Flexed or Bent shape. Flexing and bending rigid (strong) materials is how the strong materials break. Fun Experiment: Find some material that is difficult to bend yet you can bend it. Then bend it and un-bend it, and repeat. The bend location is getting stretched, warm, and brittle. This happens with any material (remember for survival skills). Peace. Sincerely, Don

Just to be sure when i put 850 quantity i will get a 850ft(no splice) wire not 850 Pieces of 1ft ...

Asked by Cast February 10, 2019
1
Answer

That is correct! The above advice is based upon the current edition of the National Electric Code (NEC). Free access to the latest version of the NEC is available online at www.nfpa.org/freeaccess. The NEC and local building codes regulate the types of wire and cable that can be used in specific electrical applications, as well as the manner of installation. Check your local building codes before you start any wiring and cable electrical project and be sure to obtain required permits. When your work is complete, always have it inspected for compliance with local codes to ensure that it has been safely installed.

How much does a 500 ft. roll of 1/0 Str copper wire weigh?

Asked by Boz January 16, 2019
1
Answer

The gross weight of 1 x 500’ 1/0 CU THHN weighs 186.5 lbs. The weight of the reel is 9 lbs. for a total weight of 195.5 lbs.

Can those wire be run exposed on the side of a building or does it need to be run in conduit?

Asked by Jason May 11, 2018
1
Answer

These wires cannot be run exposed. Approved conduit is needed. Please consult a professional license electrician for this kind of work.

Can this 1/0 CU THHN wire be run underground in conduit?

Asked by Jason April 11, 2018
1
Answer

Yes it is code approved if installed in raceway.

can 1/0 black stranded cu thhn wire be used in my 200amp service to a 200amp main breaker in my shop

Asked by amiture March 23, 2017
3
Answers

If your service is for a residential dwelling of less than 400 amperes, and not a commercial structure, according to article 310.15(7)(1) of the National Electrical Code, the service and feeder conductor amperage demand may be de-rated by 83 percent. So 200 amperes becomes a demand amperage of 166 amperes. Therefore, since 1/0 THHN carries up to 170 amperes, it is allowable for a residential service and feeder according to the 2017 NEC.

greetings , is this cable rated for wet locations by nec definitions? I'm actually looking for t...

Asked by rock January 30, 2017
1
Answer

Hello, According to the Spec sheet i have attached our THHN products are moisture resistant.. "600 Volts. Copper Conductor. Thermoplastic Insulation/Nylon Sheath, Heat, Moisture, Gasoline and Oil Resistant II. All Sizes Rated Both THHN and either THWN (sizes 14, 12, and 10 AWG) or THWN-2 (sizes 8AWG and larger). Also Rated MTW and AWM (See Below). SIMpull® Technology for Easier Pulling." I have attached the link below. http://www.southwire.com/ProductCatalog/XTEInterfaceServlet?contentKey=prodcatsheet276The above advice is based upon the current edition of the National Electric Code (NEC). Free access to the latest version of the NEC is available online at www.nfpa.org/freeaccess. The NEC and local building codes regulate the types of wire and cable that can be used in specific electrical applications, as well as the manner of installation. Check your local building codes before you start any wiring and cable electrical project and be sure to obtain required permits. When your work is complete, always have it inspected for compliance with local codes to ensure that it has been safely installed.
