Model #0103600

6 cu. in. New Construction or Remodel Ceiling Fan Saf-T-Pan

  • All the mounting hardware you need to install a ceiling fan
  • Boasts a UL listed design
  • Strong enough to support fans up to 70 pounds
  • See More Details

Frequently Bought Together

+
+
Price:

Product Overview

The Westinghouse Saf-T-Pan allows you to safely install a fan or lighting fixture during construction. Ideal for installation during new construction or remodeling, it can be installed anywhere with attic access. Featuring a heavy-duty, all-metal, 6 cu. in., dual-mount electrical box, the Saf-T-Pan works with any model of ceiling fan. The pan is 1/2 in. deep, and includes 8-32 threads for cover plates and lightweight fixtures and 10-24 threads for ceiling fans and heavier fixtures. The pan supports fans up to 70 lbs. and lighting fixtures up to 150 lbs. It comes with a Saf-T-Cap to protect bolts and wires during drywall installation and painting and everything you need for installation. Product reference number 01036.
  • Safely and easily hang a ceiling fan or lighting fixture
  • Compatible with all fans and fixtures, with both 8-32 and 10-24 threads
  • Features 5 knockouts for conduit or Romex and 1 Romex connector
  • UL listed to support fans up to 70 lbs. and light fixtures up to 150 lbs.
  • Includes Saf-T-Cap to protect bolts and wires and all hardware for installation. Comes with everything you need for installation, including easy-to-follow instructions

Info & Guides

You will need Adobe® Acrobat® Reader to view PDF documents. Download a free copy from the Adobe Web site.

Compare Similar Boxes & Brackets

current product
6 cu. in. New Construction or Remodel Ceiling Fan Saf-T-Pan
1-Gang 3 in. 2-1/2 in. Deep New Work Metal Switch and Outlet Electrical Box with CV Bracket1-1/2 in. Deep 15.3 cu. in. Ceiling Fan Box with Metal Cover
BrandWestinghouseSteel CityCommercial Electric
Name6 cu. in. New Construction or Remodel Ceiling Fan Saf-T-Pan1-Gang 3 in. 2-1/2 in. Deep New Work Metal Switch and Outlet Electrical Box with CV Bracket1-1/2 in. Deep 15.3 cu. in. Ceiling Fan Box with Metal Cover
Price
Ratings
(17)
(1)
(28)
Packaging TypeConsumer PackagingConsumer PackagingConsumer Packaging
Box TypeFan fixture boxWall boxFan fixture box
MaterialMetalSteelSteel
Trade Size (in.)1/21/21-1/2
Number of Gangs111
Number of Knockouts/Pryouts545
MountingOld WorkBracketFlush Mount
Metallic/Non-MetallicMetallicMetallicMetallic
Power Distribution FeaturesFire RatedNo Additional FeaturesFire Rated
View ProductView ProductView Product

Specifications

Dimensions

Product Depth (in.)
0.5
Product Height (in.)
4.0
Product Width (in.)
4.0
Trade Size (in.)
1/2

Details

Box Type
Fan fixture box
Color Family
Metallic
Electrical Product Type
Box
Material
Metal
Metallic/Non-Metallic
Metallic
Mounting
Old Work
Number of Gangs
1
Number of Knockouts/Pryouts
5
Pack Size
1
Packaging Type
Consumer Packaging
Power Distribution Features
Fire Rated
Product Weight (lb.)
0.5
Returnable
90-Day

Warranty / Certifications

Certifications and Listings
UL Listed
Manufacturer Warranty
N/A

Questions & Answers

11Questions27Answers

If this was installed to the ceiling stud directly over the drywall, would the plate be visible when fan is installed?

Asked by Buddy879263 January 22, 2019
3
Answers

Maybe or maybe not. Depends on the way the ceiling fan junction box cap & size attaches to the bracket. If your going to attach to the underside of the ceiling stud I would cut out the 4" diameter needed for the fan mounting box so it sits flush to the ceiling. (Hence the reason the fan support box is 1/2" deep) Good luck with your project.

How deep is the box? I need to come down 5/8ths to 7/8ths.

Asked by voodoo17 September 17, 2018
1
Answer

The box depth for item 0103600 is 1/2". We also have a item 0103000 which box depth is 5/8".

ceiling joist mount

Asked by jimbo August 3, 2018
5
Answers

Yes - that is the typical mount for a ceiling fan.

Is this box galvanized?

Asked by SpyderTech02 June 15, 2018
3
Answers

No, the Saf-T-Pan is not is not galvanized.

Can this box be installed on a concrete ceiling? If yes, then will it require masonry screws to f...

Asked by SteveDIY March 27, 2018
3
Answers

Yes, this box can be mounted to a concrete ceiling, using the appropriate fasteners as determined by your local building code.

Can this box be used for a fan installed on a screened porch (outdoor)?

Asked by Peter August 19, 2017
3
Answers

Yes. Providing there is a substantial support member to screw it to. Many screened porches the roofing area is just a thin sheet of metal with only a Styrofoam backing. This is not adequate. Make sure to secure it to a good support. Good luck.

What is the diameter of the box?

Asked by Erika June 6, 2017
2
Answers

4". Not sure why it is listed as a 6". I never seen a 6" fan support box.

Can the box be installed on the metal joist part of a metal porch roof and if so what size, type ...

Asked by Slowpoke May 21, 2017
1
Answer

No, this cannot be installed on any part of a metal joist.

Can be used in wall?

Asked by Dhk July 23, 2016
3
Answers

I don't see any reason why not - but be aware that as a shallow box there's little room for the wires coming in. Fortunately, for me, there was room withing the fan housing but even then it was very tight.

Drill Bit Size

Asked by MrEd July 15, 2015
3
Answers

I would start with the 1/8" size. You want it to be a guide to help the screw into the wood. If it's tight, try soaping the threads first.

6 cu. in. New Construction or Remodel Ceiling Fan Saf-T-Pan - page 2

Customer Reviews

  • 4.2
    out of 17 reviews
  • 86% recommend this product
Filter by:
Showing 1-10 of 17 reviews
We use Westinghouse pancake boxes for all our ceiling fans...
We use Westinghouse pancake boxes for all our ceiling fans and most light fixtures installations.
by HomeDepotCustomer
Perfect for what I needed them for would recommend...
Perfect for what I needed them for would recommend
by Jason
Great design and rapid delivery...
Great design and rapid delivery
by Arnold
Excellent ...
Excellent
by Aamir
Could not snap in romex connector into knockout hole as it was blocked by edge of joist, and grou...
Could not snap in romex connector into knockout hole as it was blocked by edge of joist, and ground screw comes into contact with edge of joist after being screwed in - would not buy this model again
by user841963
1 Star Review
Rating provided by a verified purchaser
by HomeDepotCustomer
My daughter easily replaced her bathroom fixture by using this box. And by using Google hangouts...
My daughter easily replaced her bathroom fixture by using this box. And by using Google hangouts and I talking her through it.
by Dave
1 person found this helpful
Replaced ordinary non-conforming item installed by a previous homeowner with this unit. Needed sh...
Replaced ordinary non-conforming item installed by a previous homeowner with this unit. Needed shallow unit approved for fan. This met requirements. I like the included cover - made patching, painting easier by protecting the wires from material and paint before hanging fan. Screws and wire clamp were included as well.
by M1
1 person found this helpful
Great Ceiling Fan Saf-T-Pan...
Great Ceiling Fan Saf-T-Pan
by Robert
1 person found this helpful
Perfect for Heavy-Duty fans...
Perfect for Heavy-Duty fans
by Jimmie
1 person found this helpful
Showing 1-10 of 17 reviews
