0884005340619

RIDGID

Model # MS255SR

Internet # 203132245

Store SKU # 323986

10 in. Sliding Compound Miter Saw with Dual Laser Guide

$349.00 /each
  • Gravity LED light illuminates the work area in all positions
  • Dual laser lines provide more visible cutting kerf indication
  • Upfront bevel index pin for controlling the blade tilt

Frequently Bought Together

Product Overview

The RIDGID 10 in. Dual Bevel Sliding Miter Saw has a powerful 15Amp motor with a soft start and constant speed control for stable cutting in high load conditions. Make fast and precise adjustments with the upfront bevel lock control and miter lock lever for quick angle adjustments. An innovative gravity LED light illuminates the work area in all positions. It is ideal for the professional user in a wide range of specialties including general contractors, woodworkers, cabinetry and flooring.

  • Powerful 15 Amp motor has a soft start and constant speed control for comfortable use under different load conditions
  • In-line handle for both right and left hand use which eliminates any side force to the blade for seamless cutting
  • Miter detent knob provides quick action releases or bypasses miter detent index points with one simple motion
  • Convenient upfront bevel lock control there's no need to reach behind the saw for lock/release
  • Miter lock lever provides users with easy access to make quick angle adjustments
  • Upper sliding and lower pivot fence provide extreme support to any thin work piece
  • CLICK HERE TO REGISTER YOUR RIDGID PRODUCT.

Info & Guides

You will need Adobe® Acrobat® Reader to view PDF documents.  Download a free copy from the Adobe Web site.

Specifications

Dimensions

Blade Diameter
10 in
Product Depth (in.)
22.52
Product Height (in.)
18.03
Product Width (in.)
34.84
Table Length (in.)
22
Table Width (in.)
12

Details

45 Degree Crosscut Capacity Maximum - Left
1 7/8" X 12"
90 Degree Crosscut Capacity Maximum - Left
3 1/2" X 12"
90 Degree Crosscut Capacity Maximum - Right
3 1/2" X 12"
Amperage (amps)
15
Arbor Size
5/8"
Bench & Stationary Tool Type
Slide Miter Saw
Bench or Stationary
Bench
Bevel Type
Dual
Color Family
Orange
Cord Length (ft.)
10
Cordless/ Corded
Corded
Dust Collection Method
2 in. Dust Port
Maximum Cutting Thickness (in.)
3.5
Maximum Degree Miter Cuts - Left
52
Maximum Degree Miter Cuts - Right
60
Maximum Speed (rpm)
3600
Maximum miter capacity
3.5
Miter Saw Type
Sliding Compound
No Tool Blade Change
No
Power Tool Features
No Additional Features
Power Tool Product Type
Bench & Stationary
Product Weight (lb.)
46.74 lb
Reconditioned
No
Returnable
90-Day
Tools Product Type
Power Tool

Warranty / Certifications

Certifications and Listings
1-UL Listed
Manufacturer Warranty
Lifetime Service Agreement with registration within 90 days of purchase

More Products With These Features

Search

Customer Questions & Answers

47 Questions114 Answers

Customer Questions & Answers

10 in. Sliding Compound Miter Saw with Dual Laser Guide
10 in. Sliding Compound Miter Saw with Dual Laser Guide

Ask your questions. Share your answers.



Clear Search Term


Sort By:

10 answers

Which is better for a beginner to build shelving / bookcase; sliding miter saw or table saw

This question is from 10 in. Sliding Compound Miter Saw with Dual Laser Guide
Asked by
TG
March 2, 2013
0points
0out of 0found this question helpful.
Was this helpful?helpful0unhelpful0

Answers (10)

Asked by
Read all my Q&A
November 15, 2015
Answer:
A difficult question with many answers. There is no substitute for a table saw. Give me a table saw and a router and I can build anything. But for a beginner to cut only to length with angles, The miter saw would be the tool of choice.
+2points
2out of 2found this answer helpful.
Was this helpful?helpful2unhelpful0

Asked by
New Philadelphia, Ohio
Read all my Q&A
December 29, 2014
Answer:
Table saw. It's much easier to cut the dados for the shelves on table saw. You may also be ripping lumber to different widths provided you don't use off the shelf pre-milled lumber which I do not recommend.
+1point
1out of 1found this answer helpful.
Was this helpful?helpful1unhelpful0

Asked by
Syracuse
Read all my Q&A
November 13, 2014
Answer:
A sliding Miter saw is a specialty tool, in that you can do everything it can do with a skill saw and a table saw. The miter saw just does some tasks much more easily and more accurately. My opinion on this matter is that you will get more mileage out of a table saw especially if you are ripping stock.
I will warn however that if you are new to using tools, you need to learn how to use a table saw Read More
A sliding Miter saw is a specialty tool, in that you can do everything it can do with a skill saw and a table saw. The miter saw just does some tasks much more easily and more accurately. My opinion on this matter is that you will get more mileage out of a table saw especially if you are ripping stock.
I will warn however that if you are new to using tools, you need to learn how to use a table saw safely. A miter saw is potentially much safer than a table saw, but it will not replace all of the functions that a table saw will do. If you are cross cutting on table saw, you need to do it correctly to avoid kickback. If you are ripping, you have to feed the stock correctly and keep your hands out of the blade. A table saw is a better bet especially for shelving and especially if you need to rip. A table saw is more useful for more tasks. My vote would be for the Table Saw. Read Less
+4points
4out of 4found this answer helpful.
Was this helpful?helpful4unhelpful0

Asked by
College Place, WA
Read all my Q&A
Home Improvement Profile: Professional
November 10, 2013
Answer:
Table saw. With a CSMS(Compound sliding miter saw) you are limited to 12 to 14 inch cuts. With a table saw you can make any length of rip needed. The CSMS is ideal for cross cutting so if you expect that to be your primary type of cut then the CSMS is idea. Though you can do almost anything with a table saw that you can do with a CSMS. It just takes a higher skill level to do.
+2points
3out of 4found this answer helpful.
Was this helpful?helpful3unhelpful1

Asked by
SW Ohio
Read all my Q&A
June 16, 2013
Answer:
Tough question to answer. If you are cutting lengths of shelving narrow enough to be cut on a sliding miter, then it will suffice. A miter saw makes short work of accurate cross cuts, but cannot make any rip cuts. You will have problems making accurate miter cuts on an inexpensive, portable table saw. They are two really different tools.
+4points
4out of 4found this answer helpful.
Was this helpful?helpful4unhelpful0

Asked by
karl
May 8, 2013
Answer:
I advise you buy a table saw so that you can cut the any width wood what you want.Although for a beginer,the miter saw maybe preformance better when you use it than the table saw.This is only for your reference.
+1point
1out of 1found this answer helpful.
Was this helpful?helpful1unhelpful0

Asked by
Read all my Q&A
April 2, 2013
Answer:
A sliding miter saw would be better as long as you don't plan to make the shelves more than 12" deep.
+1point
1out of 1found this answer helpful.
Was this helpful?helpful1unhelpful0

Asked by
New York, NY, USA
Read all my Q&A
March 16, 2013
Answer:
If the wood you are using is already cut to width. Say 1x12 for example you would not need a table saw. A table saw is used for cutting down the width of a board a miter saw is used for cutting the length of a board. If you are using premade trim to finish off your bookcase you NEED the miter saw
+3points
3out of 3found this answer helpful.
Was this helpful?helpful3unhelpful0

Asked by
Placentia, CA 92870, USA
Read all my Q&A
March 5, 2013
Answer:
There is no right or wrong answer to this question; it is a matter of personal preference. Factors to consider include the design of the bookcase and type of joints you intend to use. Generally speaking the slidder will handle long stock cross cuts better and safer than a table saw so for a less intricate design with simple joints most would probably be more comfortable with the slidder.
+3points
3out of 3found this answer helpful.
Was this helpful?helpful3unhelpful0

Asked by
San Diego, CA, USA
Read all my Q&A
March 3, 2013
Answer:
Without any doubt at all - a table saw. The 10" sliding miter saw can only cut up to a width of 12", and a 12" is only a little more than that - 13.5". You will usually need to be able to cut a much higher width than that, and often you'll need to trim a piece lengthways too.
The table saw is your only option for those sorts of uses.
+1point
2out of 3found this answer helpful.
Was this helpful?helpful2unhelpful1

10 answers

Does this saw have a stop and depth setting for dado cuts?

This question is from 10 in. Sliding Compound Miter Saw with Dual Laser Guide
Asked by
Undone
Clayton, iN
February 26, 2013
+1point
1out of 1found this question helpful.
Was this helpful?helpful1unhelpful0

Answers (10)

Asked by
Houston, Texas
Read all my Q&A
Home Improvement Profile: DIYer
March 3, 2016
Answer:
It does but it appears worthless. The depth adjustment is very minor and you need to be careful not to hit the bottom under the table. The non-sliding miter saw has a much deeper cut and I never had to worry about depth. I just upgraded from a Ridged 10" non-slider to a 10" slider and I am disappointed at how shallow the cut goes. Not sure what I'll do now. Maybe go back and check out a DeWalt slider.
+2points
2out of 2found this answer helpful.
Was this helpful?helpful2unhelpful0

Asked by
New Philadelphia, Ohio
Read all my Q&A
December 29, 2014
Answer:
Yes. However I feel a table saw is much more dependable for this task.
+1point
1out of 1found this answer helpful.
Was this helpful?helpful1unhelpful0

Asked by
Syracuse
Read all my Q&A
November 13, 2014
Answer:
Yes. It's not exactly great. You have to be careful to apply the same down pressure every time and avoid the inclination to press down harder over time. The stop mechanism flexes under pressure and can give you cuts of varying depths if you are not careful. I would have preferred something a bit more substantial. But it does have one and if you pay attention it does work.
+3points
3out of 3found this answer helpful.
Was this helpful?helpful3unhelpful0

Asked by
Guam
Read all my Q&A
March 8, 2014
Answer:
Yes it does. I used mine the other day; worked great. Use a straight piece of scrap wood between your wood and the fence so the blade can go through the entire length of your piece.
+1point
1out of 1found this answer helpful.
Was this helpful?helpful1unhelpful0

Asked by
Read all my Q&A
Home Improvement Profile: DIYer
January 2, 2014
Answer:
Yes, it has a stop depth setting. But there is no scale with it. To determine the depth you need to measure from the base to the bottom of the blade to get the correct adjustment. Awkward, but it has the capability.
+2points
2out of 2found this answer helpful.
Was this helpful?helpful2unhelpful0

Asked by
SW Ohio
Read all my Q&A
June 16, 2013
Answer:
Yes there is a depth stop setting.
+1point
1out of 1found this answer helpful.
Was this helpful?helpful1unhelpful0

Asked by
Read all my Q&A
April 2, 2013
Answer:
Yes
+2points
2out of 2found this answer helpful.
Was this helpful?helpful2unhelpful0

Asked by
New York, NY, USA
Read all my Q&A
March 16, 2013
Answer:
Yes it can be set with the bolt on the right side of the saw.
+2points
2out of 2found this answer helpful.
Was this helpful?helpful2unhelpful0

Asked by
Placentia, CA 92870, USA
Read all my Q&A
February 27, 2013
Answer:
Slidding compounds are not really designed for dado cuts or dado blades and personally I would not recommend it for that purpose; a radial arm saw is a much better choice for that application. That said this saw does have an adjustable depth stop that might enable it to be used for that purpose though clearance with the saw blade guard should be very carefully inspected before attempting to run the saw Read More
Slidding compounds are not really designed for dado cuts or dado blades and personally I would not recommend it for that purpose; a radial arm saw is a much better choice for that application. That said this saw does have an adjustable depth stop that might enable it to be used for that purpose though clearance with the saw blade guard should be very carefully inspected before attempting to run the saw with a dado blade otherwise there could be injury due to contact of the blade and saw guards. Read Less
-2points
3out of 8found this answer helpful.
Was this helpful?helpful3unhelpful5

Asked by
Read all my Q&A
February 27, 2013
Answer:
We do not make or support this model, please contact the manufacturer, Chevron 866-974-3443
-29points
2out of 33found this answer helpful.
Was this helpful?helpful2unhelpful31

7 answers

Does this 10" saw fit a specific Ridgid stand? If so, which stand accomodates this saw?

This question is from 10 in. Sliding Compound Miter Saw with Dual Laser Guide
Asked by
Don
June 21, 2012
0points
0out of 0found this question helpful.
Was this helpful?helpful0unhelpful0

Answers (7)

Asked by
Syracuse
Read all my Q&A
November 13, 2014
Answer:
There are very few stands built specifically for one chop saw. Most, and including the ridged stand, are "Universal" and will work with any chop saw given the right length bolts. The Ridged stand comes with two sets of different length bots that will work in most applications. I noted though that the 10" sliding compound miter saw has threaded holes right next to the bolt holes. If you found a bolt to Read More
There are very few stands built specifically for one chop saw. Most, and including the ridged stand, are "Universal" and will work with any chop saw given the right length bolts. The Ridged stand comes with two sets of different length bots that will work in most applications. I noted though that the 10" sliding compound miter saw has threaded holes right next to the bolt holes. If you found a bolt to fit the threads, you could screw it in to the stand brackets without any bolts sticking up through. There are normally many ways to mount a saw on these stands. You can mount a piece of ply wood to the brackets for example, and then mount the chop saw to the wood. The saw mounts nicely to the 150 foldable stand Ridged makes. Read Less
+2points
2out of 2found this answer helpful.
Was this helpful?helpful2unhelpful0

Asked by
Rocklin, CA
Read all my Q&A
August 30, 2013
Answer:
Buy the Ridgid Mitre Saw Utility Vehicle. It's simple, portable and heavy duty. A great value.
+1point
1out of 1found this answer helpful.
Was this helpful?helpful1unhelpful0

Asked by
New York, NY, USA
Read all my Q&A
May 5, 2013
Answer:
It will work on any stand. They are all universal. Including the ridgid stand
+2points
2out of 2found this answer helpful.
Was this helpful?helpful2unhelpful0

Asked by
Placentia, CA 92870, USA
Read all my Q&A
February 19, 2013
Answer:
See related products below, an excellent stand that makes the saw more mobile, provide support for long stock and allows the saw to be store vertically.
+2points
2out of 2found this answer helpful.
Was this helpful?helpful2unhelpful0

Asked by
Staten Island, NY, USA
Read all my Q&A
July 30, 2012
Answer:
I know this will fit right on the new AC9945 folding stand and I ma sure the older Ac9944. The dewalt DWX723 and DW725 will handle this as well.
+3points
3out of 3found this answer helpful.
Was this helpful?helpful3unhelpful0

Asked by
Sacramento Ca
Read all my Q&A
June 26, 2012
Answer:
I bought the RIDGID Mobile Miter Saw Stand
Model # AC9945 for this saw. It was worth the investment.
+4points
4out of 4found this answer helpful.
Was this helpful?helpful4unhelpful0

Asked by
Read all my Q&A
June 22, 2012
Answer:
This saw does fit a specific Ridgid stand. It’s the Ridgid mobile miter saw stand (Home Depot sku 984-386).
Thank you
Miter Saw Customer Service
0points
3out of 6found this answer helpful.
Was this helpful?helpful3unhelpful3

5 answers

Does the saw have soft start?

This question is from 10 in. Sliding Compound Miter Saw with Dual Laser Guide
Asked by
Read all my Q&A
March 4, 2016
0points
0out of 0found this question helpful.
Was this helpful?helpful0unhelpful0

Answers (5)

Asked by
Narberth,PA
Read all my Q&A
July 2, 2016
Answer:
Yes.
0points
0out of 0found this answer helpful.
Was this helpful?helpful0unhelpful0

Asked by
Hawthorne ,California
Read all my Q&A
June 10, 2016
Answer:
Yes.
0points
0out of 0found this answer helpful.
Was this helpful?helpful0unhelpful0

Asked by
Bradenton FL
Read all my Q&A
May 24, 2016
Answer:
Yes it has a soft start. Takes a little time to get use to
0points
0out of 0found this answer helpful.
Was this helpful?helpful0unhelpful0

Asked by
Montgomery, AL
Read all my Q&A
Home Improvement Profile: DIYer
April 12, 2016
Answer:
Yes.
0points
0out of 0found this answer helpful.
Was this helpful?helpful0unhelpful0

Asked by
Read all my Q&A
March 9, 2016
Answer:
Thank you for your interest in RIDGID.
Yes the Ridgid MS255SR has a soft start.
Regards,
RIDGID
0points
0out of 0found this answer helpful.
Was this helpful?helpful0unhelpful0
2 3 4 »
  • 2016-07-20 T13:15:54.333-05:00
  • bvseo_lps, prod_bvqa, vn_prr_5.6
  • cp-1, bvpage1
  • co_hasquestionsanswers
  • loc_en_US, sid_203132245, prod, sort_default
2 3 4 »
  • bvseo_sdk, java_sdk, bvseo-3.1.1
  • CLOUD, getContent, 765ms
  • QUESTIONS, PRODUCT

Customer Reviews

Rated 4.4 out of 5 by 143 reviewers.
Rated 5.0 out of 5.0 by Very Well Thought Out Design I have used many many miter saws and use them daily (as a hardwood flooring installer, among many other carpentry tasks) over the last 12 years or so. Some cheap, some expensive (including Festool Kapex) and everything in between. I won't go into deep thought or detail about this $349 saw, because I don't think it's necessary. instead I will say this, it is solid and heavy, it is presise, has every feature as a saw costing much more(and alot they don't have i.e. the front bevel lock is just so sweet, you never have to reach behind the saw, led gravity light, crown stop on the slide, brilliant). Don't procrastinate like I did for the last 5mo just order it now before they sell out of them....again . Can't wait to get the Ridgid Miter saw stand too ..... July 16, 2016
Rated 5.0 out of 5.0 by Well built sturdy saw So far so good ridgid makes good tools I haven't found anything to complain about July 19, 2016
Rated 5.0 out of 5.0 by Great value in sliders I've been In the trades and a serious diy'er for 30+ years. I had not seen this saw in person because my local HD do not stock it. About .5 hours away to pick it up-- no problem. First of all, I think that Rigid has come a long way as a brand in general the last few years. IMO, 10" slide is the sweet spot on miter saws. It was packaged very well. I followed the manual as per set up, and to my surprise, it did not need even a single adjustment. Spot on perfect. Fence, miter angles, bevels, laser, all perfect. My first trim board cuts were equally impressive. Not even a chip in my paint coat. No tear out. Not even 1 splinter. Granted, I use quality blades, but the saw is smooth. Also, I like the large platform, lower rpm motor, soft start, and the up front adjustments and locks. Yeah, I like this saw. It is a good value, and exceeded my expectations. No comparison to my previous 10" slide (m*****), which was light blue. The Rigid miter saw stand (if you need portability) is very nice too. Plus, it matches the saw color. I'm that way. I have NO affiliation withRigid or HD. Highly recommended. June 28, 2016
Rated 5.0 out of 5.0 by esr saw for the money Saw has up front control, double laser and dual tilt. What more do you need. June 28, 2016
Rated 5.0 out of 5.0 by Good Deal for the money I am happy with the saw overall. The laser needs an auto shut off, or only come on when a person depresses the safety lock. In the daylight laser is hard to see and is easy to leave on. I Like all of the angle adjustments in the front of the saw. July 7, 2016
Rated 4.0 out of 5.0 by Nice Saw I find that this saw is well built and properly aligned right out of the box. All I had to do is mount it, plug it in. and go. With one exception. I based my decision to buy this saw on a tool review from "Popular Woodworking" magazine. One of the features that came out was it's dust collection ability through the dust port on the back of the saw head when connected to a shop vac. The rating was outstanding. So I figured that since it is a Ridgid tool that there should be no problem attaching my Ridgid shop vac to it. Not so. I can just barely get the vac hose into the port by pushing and twisting hard. And then it fell out when the saw was used. I tried use a connector designed to hook two shop vac hoses together but the connector would not go over or into the saw port. I'll be going to my local Home Depot to find something that does work. Another feature I know I will use that I didn't know it had is the capability to cut slots across a board at a consistent depth (not a through crosscut). Two slots and some router or chisel work and you have a dado. Nice. Other than the dust port issue, I like the saw a lot. I have not had much time to use it much, but so far I am pretty impressed. June 28, 2016
Rated 4.0 out of 5.0 by Great 10 in Sliding Saw! For the money, you cannot go wrong. I've used this saw everyday and have not had a problem with this saw. The Diablo blade that it comes with is super sharp. The only reason it didn't get 5 stars was the Laser. The Double laser is very hard to use. I wish it would of had the single laser. May 24, 2016
Rated 5.0 out of 5.0 by Excellent Tool My first miter saw I have bought. Well built and everything was square right out of the box. Would purchase another Rigid product. June 7, 2016
  • 2016-07-24 T19:11:39.164-05:00
  • bvseo_lps, prod_bvrr, vn_prr_5.6
  • cp-1, bvpage1
  • co_hasreviews, tv_143, tr_143
  • loc_en_US, sid_203132245, prod, sort_default
2 3 4 5 6 >>
  • bvseo_sdk, java_sdk, bvseo-3.1.1
  • CLOUD, getContent, 294ms
  • REVIEWS, PRODUCT
