Model # TLM812RCU2P

Internet #100155884

Store SKU #368940

GE PowerMark Gold 125 Amp 8-Space 16-Circuit Outdoor Main Lug Load Center
0783164296181

GE

PowerMark Gold 125 Amp 8-Space 16-Circuit Outdoor Main Lug Load Center

  • Outdoor NEMA 3R enclosure
  • Main lugs are factory installed; convertible to main breaker
  • Use with equipment ground kit TGK12 (order separately)
$3987 /each
store icon Loading Buying Options...
package icon Loading Buying Options...
Sorry, but we ran into issues loading these options. Please try refreshing.

Frequently Bought Together

Product Overview

  • Outdoor NEMA 3R enclosure
  • Main lugs are factory installed; convertible to main breaker
  • Use with equipment ground kit TGK12 (order separately)
The load center includes a sturdy tin-plated copper buss bar and a galvanized box for increased durability and reliability. The 1-piece interior removes and re-installs easily. Outdoor NEMA 3R enclosure. This load center is UL listed and ANSI Certified.

Product Overview

The load center includes a sturdy tin-plated copper buss bar and a galvanized box for increased durability and reliability. The 1-piece interior removes and re-installs easily. Outdoor NEMA 3R enclosure. This load center is UL listed and ANSI Certified.

Info & Guides

You will need Adobe® Acrobat® Reader to view PDF documents.  Download a free copy from the Adobe Web site.

Compare Similar

Price
$37.97 /each
$39.87 /each
$39.97 /each
$77.74 /each
Name PowerMark Gold 125 Amp 6-Space 12-Circuit Outdoor Main Lug Circuit Breaker Panel PowerMark Gold 125 Amp 8-Space 16-Circuit Outdoor Main Lug Load Center PowerMark Gold 125 Amp 8-Space 16-Circuit Outdoor Main Lug Circuit Breaker Panel PowerMark Gold 200 Amp 16-Space 32-Circuit Outdoor Main Lug Circuit Breaker Panel
Brand GE GE GE GE
Ratings (2) (0) (3) (1)
Indoor/Outdoor Outdoor Outdoor Outdoor Outdoor
Number of Phases 1 1 1 1
Mounting type Plug In Plug In Plug In Plug In
Maximum Amperage (amps) 125 125 125 200
Number of Spaces 6 8 8 16
View Product View Product View Product View Product

Specifications

Dimensions

Load center depth (in.)
3.25
Load center height (in.)
11.125
Load center width (in.)
11.25

Details

Electrical Product Type
Load Center
Indoor/Outdoor
Outdoor
Load Center Type
Main Lug
Maximum Amperage (amps)
125
Mounting type
Plug In
Number of Phases
1
Number of Spaces
8
Product Weight (lb.)
19.3lb
Returnable
90-Day
Voltage (volts)
240

Warranty / Certifications

Certifications and Listings
1-UL Listed
Manufacturer Warranty
One year after first use.

Specifications

Dimensions

Load center depth (in.)
3.25
Load center height (in.)
11.125
Load center width (in.)
11.25

Details

Electrical Product Type
Load Center
Indoor/Outdoor
Outdoor
Load Center Type
Main Lug
Maximum Amperage (amps)
125
Mounting type
Plug In
Number of Phases
1
Number of Spaces
8
Product Weight (lb.)
19.3lb
Returnable
90-Day
Voltage (volts)
240

Warranty / Certifications

Certifications and Listings
1-UL Listed
Manufacturer Warranty
One year after first use.

More Products With These Features

Search

Questions & Answers

Can you purchase just the dead-front for this load center

Can you purchase just the dead-front for this load center
Asked by: RWLake
Thank you for your recent inquiry with The Home Depot, RWLake. The dead-front cover is not available separately. We appreciate your business and look forward to serving you in the future. Thank you for shopping Home Depot.
Answered by: THDSupport
Date published: 2017-01-18

What ground bar kit for this load center?

I have the TLM812RCU2P panel being installed as a subpanel in a detached building. As such I need separate neutral and ground bars. What ground kit will fit this panel? I purchased the suggested TGK12CP ground bar but it doesn't fit. It seems to be too short and the mounting screws don't fit anything in the panel. Is there another ground kit for this panel? Thanks
Asked by: Brandon
there's a GE 24 hole ground bar i bought for this box that fits.
Answered by: raker
Date published: 2016-10-24

Will this load center accept type GAB and/or type THQL breakers?

Asked by: Bob
The load center accepts GE, GFCI and AFCI breakers.
Answered by: CommunityAnswer
Date published: 2016-03-31

im looking for a ge 125 main with 8 space breaker box, model number tlm812r, there is one on the home depot site but i need to know what the model

i guess the question would be is that the same box that im looking for before i pay it online.the box that i see online is the model number tlm812rcuzp. is that the same box.
Asked by: crystal
Hi Crystal, Thank you for your question. I did reach out to the MFG on this and below is their response to you. The TLM812RCUP is a smaller outdoor enclosure that, if converted to a main breaker load center, would require a back-fed breaker and a THQLRK2CP clip to meet code. Dimensions are 11-1/4”W x 11-1/8”H x 3-1/4”D The TLM812RCU2P is a larger outdoor enclosure that, if converted to a main breaker load center, would require a breaker mounted on a TQMH000 that is mounted at the top of the load center. Dimensions are 12-1/2”W x 21-3/16”H x 4-5/8”D Other than that they both function as a main lug outdoor load center 125A with room for 8- 1“ frame breakers (THQL) or 16- ½”frame breakers (THQP) Hope this information helps.
Answered by: Sushma
Date published: 2015-11-04
