QT Series Very Quiet 110 CFM Ceiling Bathroom Exhaust Fan with Humidity Sensing, ENERGY STAR
- Broan-NuTone humidity sensing bathroom exhaust fan
- Powerful enough for rooms (including bathroom) up to 100 sq. ft.
- Easy to install and/or replace existing product for DIY'ers
- View More Details
Free & Easy Returns In Store or Online
Return this item within 90 days of purchase.
Ask about this product
Get an answer now with AI
Magic Apron Assistant is an AI virtual assistant. By proceeding, you consent to the recording and use of your information by The Home Depot (and authorized third parties). More information
Product Details
About This Product
Enjoy the innovative features of the NuTone QTXEN Series Very Quiet 110 CFM Ceiling Humidity Sensing Bathroom Exhaust Fan, such as its Sensaire technology that automatically turns on after detecting a rapid rise in moisture. The unit is ENERGY STAR certified, helping to cut down utility bills. Operating at a quiet 0.7 sones, it is suitable for ventilating areas up to 100 sq. ft.
Highlights
- Shop all Broan-NuTone Bathroom Exhaust Fans
- 110 CFM, powerful ventilation to remove moisture and reduce the risk of mold or mildew in most full baths
- Operates at a very quiet 0.7 sones for a peaceful environment
- Sensaire humidity sensing technology, senses humidity up to 4X faster than the competition
- Includes hanger bar system for fast, flexible installation for all types of construction
- Fits 2 in. x 8 in. ceiling construction
- UL Listed for use over bathtubs or showers when connected to a GFCI protected branch circuit
- Features 6 in. ducting for superior performance
- ENERGY STAR Certified to meet or exceed federal guidelines for energy efficiency for year-round energy and money savings
- Powerful enough for rooms up to 100 sq. ft.
- Permanently lubricated AC motor engineered for continuous operation
- Comparable to Broan Model QTXE110S
- Click here to learn more about Eco Options and Energy Efficiency
- For any questions regarding product features, installation, or specifications, please call our Technical Services Dept. at 800-637-1453, Monday-Friday, 8:00 am - 7:00 pm EST.
- Return Policy
Product Information
Additional Resources
Shop All Broan-NuToneSpecifications
Dimensions
Housing Length (in.) | 11.375 |
|---|---|
Housing Width (in.) | 10.5 |
Product Height (in.) | 8.625 in |
Product Width (in.) | 12.875 in |
Details
Air Volume (CFM) | 110 |
|---|---|
Amperage (amps) | 0.3 |
Color/Finish | White |
Duct Compatible Sizes | 6 in |
Features | Humidity Sensing, Timer |
Grill Shape | Rectangle |
Housing Material | Galvanized Steel |
Included | No Additional Items Included |
Installation Type | Ceiling |
Maximum Room Size (sq. ft.) | 100 |
Mount Type | Recessed |
Pack Size | 1 |
Product Weight (lb.) | 12.8 lb |
Returnable | 90-Day |
Room Size | Large Room Fan |
Voltage (V) | 120 |
Wattage (watts) | 31.4 |
Warranty / Certifications
Manufacturer Warranty | Limited 3 year |
|---|
Questions & Answers
What kind of switch I has to put on this?
If you are wanting the fan and light to operate separately, use the 68W switch. If you want them to operate together, any single gang switch will work.
I have 3" existing duct work installed. Would it be better to use a fan with a 4" outlet vs this 6" model?
Absolutely! We strongly advise against connecting this fan to 3" duct.
Can this fan be installed vertically on an interior wall and vents through an attic?
No, it cannot. It is ceiling mount only.
No, this unit is for ceiling mounting only.
How much is the exhaust flow reduced if a 4in. x 8 ft. duct is used?
Although we do not recommend using 4 inch duct on this fan, the exhaust flow should remain at 110 CFM’s if using rigid duct with no bends. However, the sone level will louder than the 0.7 sones advertised due to the restricted airflow.
Can this be run without all the timers and humidity sensors? Just as a standard ON/OFF from a wall switch?
My licensed electrician installed it with a standard on/off switch and it works. So, i’d say yes.
Yes, this product may be run manually from a wall switch bypassing the auto function with sensors and timers.
You may want to consider getting a unit that does not have the sensors. You may want to review the Operation sections on the installation instructions (page 1). Or, you should contact our Technical Support Department at 888-336-6151. Thank you.
Yes, you have two switches, both OFF turns it off and both ON turns it on. One on and one off is the automatic sensor.
Does this fan run on a 15A circuit?
Yes, it can.
Can I replace old QT-110N-B with this one?
The QTXEN110H is not a direct replacement for the QT110N-B. You will need to remove the existing metal can/housing and may have to adjust the rough opening. Please contact our Technical Support Department at 888-336-6151 for more detailed installation assistance.
What is the difference between the QTX series fans and QTXEN series? The specs appear to be the same.
These two fans are the same. They are both exhaust fans only, both have humidity sensors, and both have the same housing size. Thank you.
