Southwire

14/2 x 50 ft. Solid CU MC (Metal Clad) Armorlite Cable

$ 31 57
Loading Options
store icon Loading Buying Options...
package icon Loading Buying Options...
Sorry, but we ran into issues loading these options. Please try refreshing.

Frequently Bought Together

Frequently Bought Together

Product Overview

Southwire Armorlite Type MC Cable is constructed with soft-drawn copper, Type THHN/THWN conductors rated 90°C dry available in sizes 14 AWG through 2 AWG, and a green insulated grounding conductor. The conductors are cabled together and a binder tape bearing the print legend is wrapped around the assembly. Aluminum interlocking armor is applied over the assembly.
  • Branch, feeder and service power distribution in commercial, industrial, institutional, and multi-residential buildings
  • Power, lighting, control, and signal circuits
  • Fished or embedded in plaster
  • Concealed or exposed installations
  • Environmental air-handling spaces per NEC 300.22 (C)
  • Places of Assembly per NEC 518.4 and theaters per NEC 520
  • Installation in cable tray and approved raceways
  • Under raised floors for information technology equipment conductors and cables per NEC 645.5(D) and 645.5(D)(2)
  • Flame retardant
  • UL listed
  • Note: product may vary by store
  • Click to learn the factors you must consider when wiring your home



Product Overview

Model #: 68579252
Sku #: 368932
Internet #: 100143824

Southwire Armorlite Type MC Cable is constructed with soft-drawn copper, Type THHN/THWN conductors rated 90°C dry available in sizes 14 AWG through 2 AWG, and a green insulated grounding conductor. The conductors are cabled together and a binder tape bearing the print legend is wrapped around the assembly. Aluminum interlocking armor is applied over the assembly.

  • Branch, feeder and service power distribution in commercial, industrial, institutional, and multi-residential buildings
  • Power, lighting, control, and signal circuits
  • Fished or embedded in plaster
  • Concealed or exposed installations
  • Environmental air-handling spaces per NEC 300.22 (C)
  • Places of Assembly per NEC 518.4 and theaters per NEC 520
  • Installation in cable tray and approved raceways
  • Under raised floors for information technology equipment conductors and cables per NEC 645.5(D) and 645.5(D)(2)
  • Flame retardant
  • UL listed
  • Note: product may vary by store
  • Click to learn the factors you must consider when wiring your home



Key Features

Product Overview
Key Features
Southwire Armorlite Type MC Cable is constructed with soft-drawn copper, Type THHN/THWN conductors rated 90°C dry available in sizes 14 AWG through 2 AWG, and a green insulated grounding conductor. The conductors are cabled together and a binder tape bearing the print legend is wrapped around the assembly. Aluminum interlocking armor is applied over the assembly.
  • Branch, feeder and service power distribution in commercial, industrial, institutional, and multi-residential buildings
  • Power, lighting, control, and signal circuits
  • Fished or embedded in plaster
  • Concealed or exposed installations
  • Environmental air-handling spaces per NEC 300.22 (C)
  • Places of Assembly per NEC 518.4 and theaters per NEC 520
  • Installation in cable tray and approved raceways
  • Under raised floors for information technology equipment conductors and cables per NEC 645.5(D) and 645.5(D)(2)
  • Flame retardant
  • UL listed
  • Note: product may vary by store
  • Click to learn the factors you must consider when wiring your home



Product Overview

Model #: 68579252
Sku #: 368932
Internet #: 100143824

Southwire Armorlite Type MC Cable is constructed with soft-drawn copper, Type THHN/THWN conductors rated 90°C dry available in sizes 14 AWG through 2 AWG, and a green insulated grounding conductor. The conductors are cabled together and a binder tape bearing the print legend is wrapped around the assembly. Aluminum interlocking armor is applied over the assembly.

  • Branch, feeder and service power distribution in commercial, industrial, institutional, and multi-residential buildings
  • Power, lighting, control, and signal circuits
  • Fished or embedded in plaster
  • Concealed or exposed installations
  • Environmental air-handling spaces per NEC 300.22 (C)
  • Places of Assembly per NEC 518.4 and theaters per NEC 520
  • Installation in cable tray and approved raceways
  • Under raised floors for information technology equipment conductors and cables per NEC 645.5(D) and 645.5(D)(2)
  • Flame retardant
  • UL listed
  • Note: product may vary by store
  • Click to learn the factors you must consider when wiring your home



Compare Similar

Compare Similar Products
Brand Southwire Southwire Southwire Southwire
Name 14/2 x 25 ft. Solid CU MC (Metal Clad) Armorlite Cable 14/2 x 50 ft. Solid CU MC (Metal Clad) Armorlite Cable 14/2 x 100 ft. Solid CU MC (Metal Clad) Armorlite Cable 14/2 x 250 ft. Solid CU MC (Metal Clad) Armorlite Cable
Price
$15.89
$28.05
$45.09
$91.93
Ratings (27) (27) (27) (27)
Conductor Gauge 14 14 14 14
Total Wire Length (ft.) 25 50 100 250
Max Amps 15 15 15 15
Number of Conductors 2 2 2 2
View Product View Product View Product View Product

Specifications

Dimensions

Product Depth (in.)
10.75
Product Height (in.)
3.5
Product Length (ft.)
50
Product Width (in.)
11.75
Total Wire Length (ft.)
50

Details

Armor Material
Aluminum
Cable/Wire Type
MC
Commercial/Residential
Commercial,Residential
Conductor Gauge
14
Conductor Material
Copper
Direct Burial
No
Electrical Product Type
Armored Electrical Cable
Features
No Features
Flame retardant
No
Gauge
14
Grounded
Grounded
Indoor/Outdoor
Indoor,Outdoor
Jacketed
No
Max Amps
15
Number of Conductors
2
Returnable
90-Day
Stranded or Solid
Solid
Wet Location Use
Dry
Wire Cut Type
Pre-Cut Length

Warranty / Certifications

Certifications and Listings
1-UL Listed
Manufacturer Warranty
N/A

Specifications

Dimensions

Product Depth (in.)
10.75
Product Height (in.)
3.5
Product Length (ft.)
50
Product Width (in.)
11.75
Total Wire Length (ft.)
50

Details

Armor Material
Aluminum
Cable/Wire Type
MC
Commercial/Residential
Commercial,Residential
Conductor Gauge
14
Conductor Material
Copper
Direct Burial
No
Electrical Product Type
Armored Electrical Cable
Features
No Features
Flame retardant
No
Gauge
14
Grounded
Grounded
Indoor/Outdoor
Indoor,Outdoor
Jacketed
No
Max Amps
15
Number of Conductors
2
Returnable
90-Day
Stranded or Solid
Solid
Wet Location Use
Dry
Wire Cut Type
Pre-Cut Length

Warranty / Certifications

Certifications and Listings
1-UL Listed
Manufacturer Warranty
N/A

Questions & Answers

Can this product be buried underground?

Asked by: Mike
According to the specifications further up on this page, it does say it is ok for wet locations and direct burial. But Southwire says different. To avoid confusion, one or the other needs to get on the same sheet of music here.
Answered by: Zavallajack
Date published: 2019-06-13

Are the 3/8 flexible strap too large to secure this 14/2 MC?

Asked by: Farmerjohn
14/2 MC Cable has an OD range of 0.425”-0.450”. 3/8” flexible straps generally work with cables ranging from 0.475”-0.580”. These would be too large for 14/2 MC.
Answered by: Southwire Tools Support
Date published: 2017-02-28

I am going to use this southwire MC cable for the damp location. What kind of connector I have to use for connect it to bell boxes?

Asked by: Mark
This product is only rated for dry location and should not be used in a damp location.
Answered by: RJ
Date published: 2017-12-01

is there some wire inside

Asked by: alex
there are 14 awg THHN black, white, and green wires under the armor.
Answered by: RJ
Date published: 2017-12-01
  • y_2019, m_8, d_23, h_5CST
  • bvseo_bulk, prod_bvqa, vn_bulk_2.0.13
  • cp_1, bvpage1
  • co_hasquestionsanswers, tq_8
  • loc_, sid_100143824, prod, sort_[SortEntry(order=NUM_ANSWERS, direction=DESCENDING), SortEntry(order=SUBMISSION_TIME, direction=DESCENDING), SortEntry(order=LAST_APPROVED_ANSWER_SUBMISSION_TIME, direction=DESCENDING), SortEntry(order=LAST_APPROVED_ANSWER_SUBMISSION_TIME, direction=DESCENDING), SortEntry(order=BEST_ANSWER_FEEDBACK_COUNT, direction=DESCENDING), SortEntry(order=POSITIVE_ANSWER_FEEDBACK_COUNT, direction=DESCENDING), SortEntry(order=NUM_ANSWERS, direction=DESCENDING)]
  • clientName_homedepot
  • bvseo_sdk, java_sdk, bvseo-3.1.1
  • CLOUD, getContent, 15ms
  • QUESTIONS, PRODUCT

Customer Reviews

14/2 x 50 ft. Solid CU MC (Metal Clad) Armorlite Cable is rated 4.8 out of 5 by 27.
Rated 5 out of 5 by from Easy to use, and it can be used in places... Easy to use, and it can be used in places not acceptable for romex.
Date published: 2019-07-02
Rated 4 out of 5 by from Easy to work with, able to size to any length... Easy to work with, able to size to any length you need.
Date published: 2019-07-09
Rated 5 out of 5 by from Wire was ez to use meets code for use in... Wire was ez to use meets code for use in condo walls
Date published: 2019-07-02
Rated 5 out of 5 by from Nice cable did what it was intended to do. Nice cable did what it was intended to do.
Date published: 2019-06-11
Rated 4 out of 5 by from Good product. Would buy again. ... Good product. Would buy again.
Date published: 2019-07-23
Rated 5 out of 5 by from Worked perfectly ... Worked perfectly
Date published: 2019-06-20
Rated 4 out of 5 by from The wire is fine. You should really consider changing your... The wire is fine. You should really consider changing your selection process for rating product. With name vendors, wire is wire. Dont ask for a review on something like this. Last week it was toilet paper you asked about. Seriously? Ask about The ship lap I bought or t&g those items could be rated
Date published: 2019-03-19
Rated 5 out of 5 by from 5 Star Review Rating provided by a verified purchaser
Date published: 2019-05-22
