- Battery start ignition requires no external power source
- Open burner design for optimum value
- 24 in. wide to fit common cutouts
- View More Details
Free & Easy Returns In Store or Online
Return this item within 90 days of purchase.
Ask about this product
Get an answer now with AI
Magic Apron Assistant is an AI virtual assistant. By proceeding, you consent to the recording and use of your information by The Home Depot (and authorized third parties). More information
Product Details
About This Product
Summit's built-in American-made gas cooktops offer quality performance at great value, with a range of sizes and styles to suit your kitchen needs. The WNL03P is a 24 in. wide cooktop with a scratch resistant porcelain surface in white. Four 9000 BTU open burners run on battery start ignition and natural gas and include durable porcelain enameled steel grates. A recessed top helps to contain spills.
Highlights
- Four 9,000 BTU burners meet all your heating needs
- Side dial controls for easy heating
- Durable construction with porcelain enameled steel grates
- Porcelain surface offers long-lasting durability with a recessed design for easier cleanup
- Battery start ignition offers an alternative to pilot light ignition, ideal for homes without standard electrical access
- Classic white finish suits any kitchen style
- Built-in design for convenience and a sleek look
- Designed to fit 22.63 in. W x 18.63 in. D counter cutouts
- Push-to-turn knobs require a small amount of force to ensure burners are not accidentally turned o
- Product available for home delivery only, Installation is not offered at time of delivery; check with your local The Home Depot store for installation options
- 1 year limited manufacturer's warranty
- Click here for more information on Electronic Recycling Programs
- Return Policy
- California residentssee Prop 65 WARNINGS
Product Information
Specifications
Dimensions: H 3.75, W 24.0, D 20.0
Dimensions
Cooktop Size | 24 in. |
|---|---|
Cut-Out Front to Back Depth (in.) | 18.63 |
Cut-Out Height (in.) | 3.75 |
Cut-Out Left to Right Width (in.) | 22.63 |
Product Depth (in.) | 20.0 |
Product Height (in.) | 3.75 |
Product Width (in.) | 24.0 |
Details
Appliance Category | Cooktop |
|---|---|
Appliance Type | Gas Cooktop |
Color/Finish | White |
Color/Finish Family | White |
Commercial/Residential | Residential |
Control Location | Right |
Cooktop Features | Unit can be installed over a Wall Oven |
Cooktop Surface Type | Recessed |
Fuel Type | Gas |
Included | No Additional Items Included |
Max Burner BTU | 9000 |
Min Burner BTU | 9000 |
Number of Burners | 4 burner |
Returnable | 90-Day |
Warranty / Certifications
Certifications and Listings | UL Listed |
|---|---|
Manufacturer Warranty | 1 year parts & labor |
Questions & Answers
Does this range top include a vent?
This cooktop does not include a vent. It is designed for installation over a wall oven and uses open burners. A separate vent hood or other ventilation system would be needed if desired.
How are these counter top stoves measured
Countertop stoves, or cooktops, are typically measured by their width and depth. The cutout dimensions, which refer to the opening required in your countertop for installation, are also important to consider. You can usually find these measurements listed under "Specifications" or "Dimensions" on the product page.
Is this product certified for a mobile home ?
This cooktop is UL Listed, signifying that it meets safety standards. However, for specific requirements regarding appliance installations in mobile homes, it's best to consult your local building codes and regulations. They can provide definitive guidance on permitted installations in your area.
How do you change the battery?
You need to lift the cover, remove the 4 screws on the panel on the right hand side. The battery is under this cover.
Hi Tina, please contact Tech Support for further assistance at 718.893.3900 ext. 512.
what dimension should counter top be and does 24 inch include the control dials replacing a current cook top
HI Virigina, thank you for your interest in Summit Cooking. The cutout required is 22 5/8" W x 18 5/8" D in accordance with the installation manual available on our website or Home Depot page. The width of the product itself is 24" including the knobs. We hope that helps! Good luck with your project.
Is this just a top portion of the cooktop (as pictured) or a whole unit including in the cabinet hardware?
The whole unit. I had no luck with the cooktop. It broke in less than 1.5 yrs when the warranty expired. I will never buy Summit Appliance again.
Yes, it is the top portion of the cooktop.
Hi Peter, and thank you for your interest in Summit Cooking. The cooktop is as pictured and would not include any cabinet hardware.
Is thiostove white with black burners?
Hi Rita, thank you for your interest in Summit Appliance Cooktops. The burner grates are Porcelain Enameled Steel and the finish would be black. We hope you find the cooktop that fits your needs.
Yes, the stove is white with black burners.
My old cooktop is 24 3/4 by ,21"down. Would this fit
You can order a stainless steel trim kit (sku: TK custom) to fit Summit cooktops to larger openings without having to renovate your space. You can order on our website or contact Home Depot special orders for assistance.
Viewing 1-8 of 22
Customer Reviews
3 out of 5
24 in. Gas Cooktop in White with 4 Burners
